DATA SHEET
GaAs INTEGRATED CIRCUIT
µ
PG2160T5K
L, S-BAND SPDT SWITCH
DESCRIPTION
The
µ
PG2160T5K is a GaAs MMIC for L, S-band SPDT (Single Pole Double Throw) switch which was developed
for mobile phone and another L, S-band applications.
This device can operate frequency from 0.5 to 3.0 GHz, having the low insertion loss and high isolation.
This device is housed in a 6-pin plastic TSSON (Thin Shrink Small Out-line Non-leaded) package. And this
package is able to high-density surface mounting.
FEATURES
• Supply voltage
• Switch control voltage
•
: V
DD
= 2.4 to 2.8 V (2.6 V TYP.)
: V
cont (H)
= 2.4 to V
DD
(2.6 V TYP.)
: V
cont (L)
=
−0.2
to 0.2 V (0 V TYP.)
Low insertion loss
: L
ins
1 = 0.30 dB TYP. @ f = 0.5 to 1.0 GHz, V
DD
= 2.6 V, V
cont (H)
= 2.6 V, V
cont (L)
= 0 V
: L
ins
2 = 0.35 dB TYP. @ f = 1.0 to 2.0 GHz, V
DD
= 2.6 V, V
cont (H)
= 2.6 V, V
cont (L)
= 0 V
: L
ins
3 = 0.40 dB TYP. @ f = 2.0 to 2.5 GHz, V
DD
= 2.6 V, V
cont (H)
= 2.6 V, V
cont (L)
= 0 V
: L
ins
4 = 0.50 dB TYP. @ f = 2.5 to 3.0 GHz, V
DD
= 2.6 V, V
cont (H)
= 2.6 V, V
cont (L)
= 0 V
High isolation
: ISL1 = 25 dB TYP. @ f = 0.5 to 1.0 GHz, V
DD
= 2.6 V, V
cont (H)
= 2.6 V, V
cont (L)
= 0 V
: ISL2 = 18 dB TYP. @ f = 1.0 to 2.0 GHz, V
DD
= 2.6 V, V
cont (H)
= 2.6 V, V
cont (L)
= 0 V
: ISL3 = 17 dB TYP. @ f = 2.0 to 2.5 GHz, V
DD
= 2.6 V, V
cont (H)
= 2.6 V, V
cont (L)
= 0 V
: ISL4 = 13 dB TYP. @ f = 2.5 to 3.0 GHz, V
DD
= 2.6 V, V
cont (H)
= 2.6 V, V
cont (L)
= 0 V
Handling power
: P
in (0.1 dB)
= +21.0 dBm TYP. @ f = 2.0/2.5 GHz, V
DD
= 2.6 V, V
cont (H)
= 2.6 V, V
cont (L)
= 0 V
High-density surface mounting : 6-pin plastic TSSON package (1.0
×
1.0
×
0.37 mm)
•
•
•
APPLICATIONS
• L, S-band digital cellular or cordless telephone
TM
• W-LAN, WLL and Bluetooth etc.
ORDERING INFORMATION
Part Number
Order Number
Package
6-pin plastic TSSON
(Pb-Free)
Note
Marking
G4
Supplying Form
•
Embossed tape 8 mm wide
•
Pin 1, 6 face the perforation side of the tape
•
Qty 5 kpcs/reel
µ
PG2160T5K-E2
µ
PG2160T5K-E2-A
Note
With regards to terminal solder (the solder contains lead) plated products (conventionally plated), contact
your nearby sales office.
Remark
To order evaluation samples, contact your nearby sales office.
Part number for sample order:
µ
PG2160T5K
Caution Observe precautions when handling because these devices are sensitive to electrostatic discharge.
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all products and/or types are available in every country. Please check with an NEC Electronics
sales representative for availability and additional information.
Document No. PG10635EJ01V0DS (1st edition)
Date Published September 2006 NS CP(K)
Printed in Japan
2006
µ
PG2160T5K
PIN CONNECTIONS AND INTERNAL BLOCK DIAGRAM
(Top View)
1
6
1
(Top View)
6
6
(Bottom View)
1
Pin No.
1
2
3
Pin Name
OUTPUT1
GND
OUTPUT2
V
cont
INPUT
V
DD
G4
V
cont
High
Low
Parameter
Parameter
Note
Note
2
5
2
5
5
2
4
5
6
3
4
3
4
4
3
TRUTH TABLE
INPUT−OUTPUT1
OFF
ON
INPUT−OUTPUT2
ON
OFF
ABSOLUTE MAXIMUM RATINGS (T
A
= +25°C, unless otherwise specified)
Symbol
V
DD
V
cont
P
in
T
A
T
stg
Ratings
+6.0
+6.0
+26
−45
to +85
−55
to +135
Unit
V
V
dBm
°C
°C
Supply Voltage
Switch Control Voltage
Input Power
Operating Ambient Temperature
Storage Temperature
RECOMMENDED OPERATING RANGE (T
A
= +25°C, unless otherwise specified)
Symbol
V
DD
V
cont (H)
V
cont (L)
MIN.
2.4
2.4
−0.2
TYP.
2.6
2.6
0
MAX.
2.8
V
DD
0.2
Unit
V
V
V
Supply Voltage
Switch Control Voltage (H)
Switch Control Voltage (L)
Note
V
cont (H)
≤
V
DD
2
Data Sheet PG10635EJ01V0DS
