High Frequency
Adapters
RLC Electronics now offers high frequency
between series adapters in a variety of
configurations for your test needs. Computer
design and the latest in RF techniques coupled
with precision assembly ensure optimal electrical
performance in the recommended frequency
ranges.
Part #
AD-1.85M-2.9M
AD-1.85M-2.9F
AD-1.85F-2.9M
AD-1.85F-2.9F
AD-2.4M-2.9M
AD-2.4M-2.9F
AD-2.4F-2.9M
AD-2.4F-2.9F
AD-1.85M-RM
AD-1.85M-RF
AD-1.85F-RM
AD-1.85F-RF
AD-2.4M-RM
AD-2.4M-RF
AD-2.4F-RM
AD-2.4F-RF
Input
V Male
V Male
V Female
V Female
2.4 Male
2.4 Male
2.4 Female
2.4 Female
V Male
V Male
V Female
V Female
2.4 Male
2.4 Male
2.4 Female
2.4 Female
Output
K Male
K Female
K Male
K Female
K Male
K Female
K Male
K Female
SMA Male
SMA Female
SMA Male
SMA Female
SMA Male
SMA Female
SMA Male
SMA Female
VSWR DC-26.5GHz
1.1:1
1.1:1
1.1:1
1.1:1
1.1:1
1.1:1
1.1:1
1.1:1
1.1:1
1.1:1
1.1:1
1.1:1
1.1:1
1.1:1
1.1:1
1.1:1
VSWR 26.5-40GHz
1.3:1
1.3:1
1.3:1
1.3:1
1.3:1
1.3:1
1.3:1
1.3:1
NA
NA
NA
NA
NA
NA
NA
NA
*Other input and output configurations available upon request
L= input length+ output length.
Example: AD-1.85M-2.9f , L=.605+.41=1.015
Connector Lengths
Type
Male Female
K (2.9) .625
.410
V (1.85) .605
.449
2.4
.665
.455
SMA
.500
.425
OUTLINE DRAWING
Specifications subject to change without notification.
Tolerances unless otherwise specified are .xx +/- .02, xxx +/- .005
Specials requiring closer tolerances, different frequency ranges, special connectors
different materials, finishes, etc. can be furnished upon request.
RLC ELECTRONICS, INC.
83 Radio Circle, Mount Kisco, New York 10549 Telephone 914-241-1334 Fax 914-241-1753
e-mail:
sales@rlcelectronics.com
www.rlcelectronics.com
