DESCRIPTION
ECN3007: REMOVED REFS TO SHLD PLUG
2
REVISIONS
DATE
1
APPROVED
R.POLUBINSKI
D. PARHAM
D. PARHAM
D. PARHAM
09/20/07
08/11/08
10/20/08
06/16/09
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE
PROPERTY OF L-COM, INC. ANY REPRODUCTION IN PART OR WHOLE
WITHOUT THE WRITTEN PERMISSION OF L-COM, INC. IS PROHIBITED.
ECN3498: ADDED 2, 20,30,40,60,80&90 FT PARTS. ADDED GRAY & WHT COLORS.
ECN99999: CHANGED TOLERANCE FOR CABLES ≤60
ECN4060: CHANGED TO "SHARK FIN" STYLE BOOT. UPDATED FORMAT.
D
D
PIN 1
LENGTH
SEE SHEET 2
PIN 1
C
"P1"
"P2"
C
NOTES:
MATERIAL:
PLUG HOUSING: POLYCARBONATE, CLEAR, UL94V-0
CONTACTS: PHOSPHOR BRONZE
CABLE JACKET: PVC (SEE SHEET 2 FOR COLORS)
SNAGLESS BOOT: CLEAR PVC
FINISH:
CONTACTS: 50
µ
INCHES GOLD IN CONTACT AREA
OVER 100
µ
INCHES NICKEL PLATE OVERALL
CABLE CHARACTERISTICS:
UNSHIELDED, FOUR TWISTED PAIR, CAT 6 MODULAR CABLE
CONDUCTORS: 24 AWG (7/32) STRANDED COPPER
MISCELLANEOUS:
ASSEMBLY WIRED PER TIA/EIA 568B SEQUENCE
PLUG CONFORMS TO TIA-1096
OPERATING TEMPERATURE RANGE: -20°C TO +75°C
CABLES TO BE TESTED FOR CONTINUITY
CABLES TO BE INDIVIDUALLY PACKAGED IN A POLYBAG
B
B
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES [mm]
OVERALL CABLE LENGTH TOLERANCE:
≤12 [305] = +1 [25] / -0
>12 [305] ≤60 [1524] = +2 [51] / -0
>60 [1524] ≤120 [3048] = +4 [102] / -0
>120 [3048] ≤300 [7620] = +6 [152] / -0
>300 [7620] = +5% / -0%
ALL OTHER DIMENSIONAL TOLERANCES:
.X = ± .2
.XX = ± .02
.XXX = ±.005
PROJECTION
APPROVALS
DRAWN BY
DATE
07/18/2006
07/18/2006
07/18/2006
PRODUCT DESCRIPTION
CATEGORY
C.MCCORMICK
CHECKED BY
A
45 BEECHWOOD DRIVE
NORTH ANDOVER, MA
01845
ENG
APPROVED BY
J.ROBERTS
MODULAR
CATEGORY 6 PATCH CORD
SIZE
A
CONFIGURATION DETAILS OF
UNDIMENSIONED FEATURES
MAY VARY
COLOR VARIATIONS
MAY OCCUR
REF
A
43321
2
FSCM NO.
DWG. NO.
TRD695
1
REV.
SHEET 1 OF 2
SCALE: NONE
CAD FILE:
TRD695.SLDDRW
