SMD Type Crystal Resonators
DSX151G SERIES
The DSX151G is a compact, highly reliable product with excellent
environmental resistance and stability, consisting of a crystal
resonator-mounted ceramic base and a ceramic cap sealed by low-
temperature-melt glass. This product can be packaged on emboss
carier tape for automatic mounting.
Features
Miniature SMD crystal resonators.
Reliable ceramic package provides high resistance
against extreme environment.
Good for automatic mounting and reflow soldering.
Generic Specification
TYPE1
TYPE2
Frequency Range
Vibration Mode
Load Capacitance
Drive Level
Frequency Tolerance
Series Resistance
DSX151GA
DSX151GS
5∼12MHz 12∼20MHz 20∼26MHz 26∼33MHz 26∼55MHz
3.5∼5MHz
3rd overtone
Fundamental
Series, 12pF, 16pF, 20pF, 32pF
8pF, 10pF, 12pF, 16pF
10μW（300μW max.）
50μW
（1mW max.）
-6
-6
±50×10 , ±100×10 （at 25℃）
100Ωmax.
80Ωmax. 60Ωmax. 40Ωmax. 60Ωmax. 100Ωmax.
-6
±30×10
-6
/−10∼＋60℃（Ref. to 25℃）
±40×10 /−10∼＋60℃
（Ref. to 25℃）
Frequency
±60×10
-6
/−20∼＋70℃
（Ref. to 25℃）
±50×10
-6
/−20∼＋70℃（Ref. to 25℃）
Characteristics
over Temperature
±100×10
-6
/−30∼＋80℃
±100×10
-6
/−30∼＋80℃（Ref. to 25℃）
（Ref. to 25℃）
Storage Temperature Range
−40∼＋85℃
Packing Unit : 1000pcs./reel
Consult our sales representative for other specifications or special specifications.
Dimensions[mm]
Internal Connections
〈Top View〉
11.8±0.2
1.5
Lot.No.
5.5±0.2
Logo
Frequency
A
DSX151GA:A=2.5±0.2
DSX151GS:A=2.1±0.2
Recommended Land Pattern
2.40
[mm]
1.2
2.0
1.90
R0.2
4.0
2.5
5.08
5.08
※
The DSX151G Crystal Resonator can be used for video applications.
Specifications shown above are part of the standard specifications.
For more details, please contact our sales representative.
