Conduit
Systems
Basic Part No.
Stuffing Tube Size Code
Conduit Size Code
H
L
A Dia
A Thread
Q
© 6/1999 Glenair, Inc.
M24758/15 Adapter for
MIL-C-24235 Stuffing Tubes
M24758/15-B-04-A
Material Designator:
A = Aluminum
B = Brass
C = CRES 316
P
K Dia
C Thread
J
1. The M24758/15 adapter couples MIL-S-24235/9 through MIL-S-24235/17 stuffing
tubes to M24758/2, M24758/3, or M24758/4 fittings.
2. Any combination of conduit and stuffing tube sizes may be used by identifying the
appropriate conduit size and stuffing tube size in the part number configuration.
3. Metric dimensions (mm) are indicated in parentheses.
4. For complete dimensions see applicable Military Specification.
CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912
74
M24758/15 Adapter for
MIL-C-24235 Stuffing Tubes
TABLE I
Conduit
Size
Code
02
03
04
05
06
08
10
12
16
20
24
C
Thread
(Class 2A)
0.438 - 28 UNEF
0.563 - 24 UNEF
0.688 - 24 UNEF
0.813 - 20 UNEF
0.938 - 20 UNEF
1.250 - 18 UNEF
1.563 - 18 UNEF
1.875 - 16 UN
2.375 - 16 UN
2.875 - 16 UN
3.375 - 16 UN
±
.02
.210
.250
.250
.310
.310
.370
.370
.430
.430
.430
.430
L
(.5)
(5.3)
(6.4)
(6.4)
(7.9)
(7.9)
(9.4)
(9.4)
(10.9)
(10.9)
(10.9)
(10.9)
K
Dia
Min.
.250 (6.4)
.370 (9.4)
.500 (12.7)
.620 (15.7)
.750 (19.1)
1.000 (25.4)
1.250 (31.8)
1.500 (38.1)
2.000 (50.8)
2.500 (63.5)
3.000 (76.2)
TABLE II
MIL-S-24235 Conduit
Size
Stuffing
Code
Tube Size
03
A
04
B
04,05,06
C
06
D
06
E
08
F
08
G
10
J
10
K
10
L
10,12
M
12
N
16
P
16
R
16
S
16
T
16
V
16,20
W
20
X
20
Y
20
Z
20,24
AA
24
BB
A
Thread
(Class 2A)
0.875 - 12 UN
1.000 - 12 UN
1.125 - 12 UN
1.250 - 12 UN
1.250 - 12 UN
1.313 - 12 UN
1.500 - 12 UN
1.625 - 12 UN
1.750 - 12 UN
1.813 - 12 UN
2.000 - 12 UN
2.063 - 12 UN
2.188 - 12 UN
2.313 - 12 UN
2.688 - 12 UN
2.875 - 12 UN
3.000 - 12 UN
3.125 - 12 UN
3.250 - 12 UN
3.375 - 12 UN
3.563 - 12 UN
3.750 - 12 UN
4.000 - 12 UN
A
Dia
.406 (10.3)
.515 (13.1)
.640 (16.3)
.750 (19.1)
.812 (20.6)
.843 (21.4)
.935 (23.7)
1.062 (27.0)
1.171 (29.7)
1.265 (32.1)
1.406 (35.7)
1.515 (38.5)
1.625 (41.3)
1.750 (44.5)
1.875 (47.6)
2.062 (52.4)
2.187 (55.5)
2.312 (58.7)
2.500 (63.5)
2.609 (66.3)
2.781 (70.6)
2.875 (73.0)
3.157 (80.2)
±
.02
1.063
1.063
1.063
1.063
1.063
1.188
1.188
1.188
1.500
1.500
1.500
1.563
1.563
1.563
2.188
2.188
2.188
2.188
2.188
2.188
2.188
3.125
3.125
H
(.5)
±
.02
(.5)
(27.0) .188 (4.8)
(27.0) .188 (4.8)
(27.0) .188 (4.8)
(27.0) .188 (4.8)
(27.0) .188 (4.8)
(30.2) .188 (4.8)
(30.2) .188 (4.8)
(30.2) .188 (4.8)
(38.1) .188 (4.8)
(38.1) .188 (4.8)
(38.1) .250 (6.4)
(39.7) .250 (6.4)
(39.7) .250 (6.4)
(39.7) .250 (6.4)
(55.6) .313 (8.0)
(55.6) .313 (8.0)
(55.6) .313 (8.0)
(55.6) .313 (8.0)
(55.6) .313 (8.0)
(55.6) .313 (8.0)
(55.6) .313 (8.0)
(79.4) .438 (11.1)
(79.4) .438 (11.1)
J
P
Dim
(Minimum)
1.031 (26.2)
1.125 (28.6)
1.250 (31.8)
1.375 (34.9)
1.375 (34.9)
1.438 (36.5)
1.656 (42.1)
1.781 (45.2)
1.875 (47.6)
1.938 (49.2)
2.188 (55.6)
2.250 (57.2)
2.344 (59.5)
2.469 (62.7)
2.813 (71.5)
2.969 (75.4)
3.094 (78.6)
3.281 (83.3)
3.438 (87.3)
3.563 (90.5)
3.750 (95.3)
3.875 (98.4)
4.125 (104.8)
±
.02
Q
(.5)
(4.8)
(4.8)
(4.8)
(4.8)
(4.8)
(4.8)
(4.8)
(4.8)
(4.8)
(4.8)
(4.8)
(4.8)
(4.8)
(4.8)
(6.4)
(6.4)
(6.4)
(6.4)
(6.4)
(6.4)
(6.4)
(6.4)
(6.4)
.188
.188
.188
.188
.188
.188
.188
.188
.188
.188
.188
.188
.188
.188
.250
.250
.250
.250
.250
.250
.250
.250
.250
© 6/1999 Glenair, Inc.
CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912
75
