MwT-1789
DC-4 GHz Packaged FET
Preliminary Data Sheet April 2005
Features
Ideal for DC –4000 MHz High Linearity / High Dynamic Range Applications
Excellent RF Performance:
46 dBm IP3
70 dBc ACPR
28 dBm P1dB
14 dB SSG @ 2000 MHz
1.3 dB NF @ 2000 MHz
MTTF > 100 years @ channel temperature 150ºC
Lead Free RoHS Compliant Surface-Mount SOT-89 Package
Download MwT-1789 SPARAM Files
(zipped file)
Product Description
The MwT-1789 is a high linearity GaAs MESFET device in low cost SOT89 package that is ideally suited for high linearity
driver, PA (Power Amplifier), and high dynamic range LNA applications. The applications include 2G, 2.5G, and 3G
wireless infrastructure standards, such as GSM, TDMA, cdma, Edge, cdma2000, WCDMA, TD-SCDMA, and UMTS base
stations. This product is also idea for high data rate wireless LAN infrastructure applications, such as high QAM rate 802.11
WiFi and 802.16 WiMax base stations and APs (Access Points). In additional, the product can be used for point-to-point
microwave communications links. The third order intercept performance of the MwT-1789 is excellent, typically 18 dB
above the 1 dB power gain compression point. The noise figure is as low as 0.8 dB at 900 MHz. The chip is produced
using MwT's proprietary high linearity device design. It also uses MwT reliable metallization process. All chips are
passivated using MwT's patented "Diamond-Like Carbon" process for increased durability.
Typical RF Performance
(1)
Target for Driver and PA applications (Vds=6.5V, Ids=200mA, Ta=25
°C)
Parameter
Test Frequency
Gain
Input Return Loss
Output Return Loss
Output P1dB
Output IP3
Noise Figure
Parameter
Test Frequency
Gain
Output IP3
Noise Figure
1.
2.
(2)
Units
MHz
dB
dB
dB
dBm
dBm
dB
Units
MHz
dB
dBm
dB
900
18
43
0.8
900
18
10
10
28.5
46
3
Typical Data
1950
14
10
8
28.5
46
3
Typical Data
1950
16
43
1.3
2500
13
46
1.5
3500
10
46
2.2
2500
11
10
10
28.5
46
4
3500
10
10
10
28.5
46
4
Target for High Dynamic Range and Low Noise Applications (Vds=5V, Ids=200mA, Ta=25
°C)
RF data is taken from an application circuit. See application notes for details of RF performance and configuration of application circuit.
Noise Figure is taken at Ids=100mA.
MicroWave Technology, Inc. an IXYS Company, 4268 Solar Way, Fremont, CA 94538
510-651-6700
FAX
510-651-2208
EMAIL
info@mwtinc.com
Data contained herein is subject to change without notice. All rights reserved © 2005
MwT-1789
DC-4 GHz Packaged FET
DC Specifications (Ta = 25ºC)
SYMBOL
IDSS
Gm
Vp
BVGSO
BVGDO
Rth
PARAMETERS & CONDITIONS
Saturated Drain Current
Vds=3.0 V Vgs=0.0 V
Transconductance
sVds=2.0 V Vgs=0.0 V
Pinch-off Voltage
Vds=3.0 V Ids=16.0 mA
Gate-to-Source Breakdown Voltage
Igs= -2.4 mA
Gate-to-Drain Breakdown Voltage
Igd= -2.4 mA
Thermal Resistance
UNITS
mA
mS
V
V
V
°C/W
-6.0
-9.0
MIN
440
380
-2.5
-12.0
-12.0
30
-5.0
TYP
MAX
680
Freq.
MHz
910
2000
2500
3000
3500
Fmin
dB
0.8
1.2
1.3
1.5
1.7
Γo
Mag.
Ang
0.18
0.3
0.25
0.27
0.29
75
138
164
175
180
MwT-1789 dB(S21) & MSG
R/50
0.14
0.13
0.12
0.12
0.11
Gain (dB)
35.0
30.0
25.0
20.0
15.0
10.0
5.0
0.0
0
1
2
3
Freq (GHz)
4
dB(S21)
MSG
MwT-1789 Noise Parameters
(Ids=100mA, Vds=5V)
5
6
Outline Diagram
1: Gate; 2,4: Source; 3: Drain
Dimensions in mm/inch
MicroWave Technology, Inc. an IXYS Company, 4268 Solar Way, Fremont, CA 94538
510-651-6700
FAX
510-651-2208
EMAIL
info@mwtinc.com
Data contained herein is subject to change without notice. All rights reserved © 2005
MwT-1789
DC-4 GHz Packaged FET
Typical Scattering Parameters
(Vds=6.5V, Ids=200mA, Ta =25°C Reference Planes at Leads)
F [GHz]
S11
S21
S12
Mag
Ang
Mag
Ang
Mag
Ang
0.250
0.883 -62.592
13.372 145.807
0.030 54.281
0.500
0.822 -101.770 9.977 124.388
0.042 42.491
0.750
0.788 -125.905 7.610 111.294
0.049 36.904
1.000
0.772 -141.758 6.104 102.405
0.051 35.628
1.250
0.765 -153.729
5.130 95.579
0.056 35.655
1.500
0.762 -163.638
4.378 88.965
0.056 35.370
1.750
0.762 -172.772
3.909 84.423
0.060 38.592
2.000
0.760 178.628
3.503 77.228
0.063 35.009
2.250
0.761 170.294
3.103 72.602
0.063 38.580
2.500
0.765 162.141
2.867 67.380
0.067 37.582
2.750
0.768 154.540
2.561 61.985
0.067 38.516
3.000
0.772 147.101
2.384 57.569
0.068 38.547
3.250
0.779 140.309
2.140 51.937
0.069 41.708
3.500
0.781 133.919
1.966 49.164
0.072 41.931
3.750
0.781 128.561
1.859 45.298
0.072 42.125
4.000
0.782 123.650
1.687 40.539
0.075 45.268
4.250
0.788 119.391
1.576 38.185
0.072 45.630
4.500
0.792 114.854
1.477 35.447
0.080 51.701
4.750
0.796 110.082
1.413 30.992
0.086 49.126
5.000
0.795 105.529
1.291 28.392
0.088 51.114
5.250
0.792 100.361
1.271 24.881
0.096 49.424
5.500
0.796
95.934
1.170 19.496
0.096 45.481
5.750
0.799
90.277
1.125 18.186
0.105 48.822
6.000
0.804
84.180
1.088 13.075
0.112 46.367
S22
Mag
0.199
0.205
0.207
0.207
0.205
0.201
0.198
0.196
0.201
0.210
0.224
0.238
0.257
0.276
0.295
0.313
0.332
0.358
0.378
0.394
0.403
0.410
0.426
0.446
Ang
-61.148
-99.716
-120.156
-132.755
-141.214
-149.045
-156.773
-165.448
-175.051
174.935
165.112
156.386
148.369
141.018
134.092
128.716
125.490
122.346
118.908
114.941
110.320
104.083
98.804
91.560
Absolute Maximum Ratings
SYMBOL
Vds
Vgs
Ids
Igs
Pdiss
Pin max
Tch
Tstg
PARAMETERS
Drain-Source Voltage
Gate-Source Voltage
Drain Current
Gate Current
DC Power Dissipation
RF Inputer Power
Channel Temperature
Storage Temperature
(Ta= 25
°C)*
UNITS
V
V
mA
mA
W
dBm
ºC
ºC
ABSOLUTE MAXIMUM
8
-6 to +0.8
400
3
2.5
+28
150
-60 to 150
*Operation
of this device above any one of these parameters may cause permanent damage.
