REVISION Y
DO NOT
SCALE FROM
THIS PRINT
8.7 .34
DESIGNED & DIMENSIONED IN MILLIMETERS [INCHES]
"A" REF
5.75 .226 REF
(TYP)
ERF8-XXX-XX-X-D-RA-XXX-TR
OPTION
-TR: TAPE & REEL
(STANDARD PACKAGING)
(SEE NOTE 4)
OPTION
-L: LATCHES (SEE FIG 2, SHT 2)
-EGP: EXTENDED GUIDE POSTS
(NOT AVAILABLE WITH -L OPTION)
(SEE NOTE 9)
No OF POSITIONS (PER ROW)
-010, -011, -013, -020, -025, -030, -037
-040,-049, -050, **-053, -060, -070, -075,
**-053 MATES WITH ERCDA
LEAD STYLE
-01: 1.58 [.062] BOARD
-03: 2.36 [.093] BOARD
"K" REF
"C" 0.25
(SEE DETAIL 'B')
"B"
C
PLATING SPECIFICATION
-S: 30µ" SELECTIVE GOLD IN CONTACT AREA,
-RA: RIGHT ANGLE
MATTE TIN ON TAIL
(USE C-231-02-S, C-231-03-S)
ROW SPECIFICATION
-L: 10µ" SELECTIVE GOLD IN CONTACT AREA,
-D: DOUBLE (USE ERF8-XXX-01-D-RA)
MATTE TIN ON TAIL
(USE C-231-02-L, C-231-03-L)
** NOT RELEASED FOR PRODUCTION
ERF8-XXX-01-D-RA
PIN 60
11.35 .447
PIN 02
"A"
'B'
0.80 .031
REF
WT-33-XX-F
(SEE TABLE 4, SHT 2)
C
2.50 .098
REF
6.25 .246
REF
WT-33-XX-X
(SEE TABLE 4,
SHT2)
PIN 01
6.12 .241
REF
C
0.800 .0315
(TOL NON-ACCUM)
C
"D"
"A"
PIN 59
"H"
(SEE NOTE 11)
0.25 .010 REF
0.35 .014
REF
"J"
C
1.00 .039 REF
1.57 .062 REF
"E" REF (ALIGNMENT PIN CTRS.)
01
59
ERF8-030-01-X-D-RA SHOWN
NOTES:
4.00 .157 REF
8.35 .329
REF
1.32 .052
REF
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. MAXIMUM BURR ALLOWANCE: 0.02[.001]
3. MINIMUM PUSHOUT /PULLOUT FORCE: SIGNAL: 2.22 N[.5 LB.],
LATCH AND COUNTERWEIGHT: 4.45 N [1.0 LB.]
4. FOR QUANTITIES UP TO 49 PIECES, NO LEADER, TRAILER, OR
EIA-481-D REEL WILL BE SUPPLIED. FOR QUANTITIES FROM 50-124
PIECES, NO LEADER OR TRAILER WILL BE SUPPLIED.
5. MEASURE AT BEND TANGENCY.
6. MEASURED ON PINS ONLY, INSULATOR NOT INCLUDED IN
MEASUREMENT.
7. ALL DIMENSIONS SYMMETRIC ABOUT C EXCEPT AS SHOWN.
L
8. DELETED
9. BOTH NON AND -EGP OPTION PARTS ARE IDENTICAL, THUS
INTERCHANGEABLE
10. DIMENSIONS MUST BE MEASURED BOTH ENDS OF COMB OR
CONNECTOR.
11. USE -Z- DATUM ZONE FOR MEASUREMENTS ONLY.
12. SEE PTL SYSTEM FOR REQUIRED INSPECTION FIXTURE TO CHECK TAIL
CRITICALS.
PROPRIETARY NOTE
*
FIG 1
1.32 .052 REF
"C"
REF
0.800 .0315
C
(TOL NON-ACCUM)
C
02
60
1.10 .043 REF
DETAIL 'B'
SCALE 5 : 1
"B"
"F"
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN
MILLIMETERS [INCHES].
*
C
TOLERANCES ARE:
DECIMALS
.X: 0.3 [.01]
.XX: 0.13 [.005]
.XXX: 0.050 [.0020]
MATERIAL:
ANGLES
2
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
INSULATOR: LCP UL94V-0, COLOR BLACK
CONTACTS: BeCu
COUNTERWEIGHT: BRASS
LATCHES: BeCu
F:\DWG\MISC\MKTG\ERF8-XXX-XX-X-D-RA-XXX-TR-MKT.SLDDRW
0.8mm DUAL ROW RIGHT ANGLE SOCKET ASSEMBLY
DWG. NO.
ERF8-XXX-XX-X-D-RA-XXX-TR
08-10-2010
SHEET
1
OF
6
BY:
D BOYCE
REVISION Y
WT-33-XX-X
(SEE TABLE 4)
WT-33-XX-X
(SEE TABLE 4)
C
"G" 0.25
ERF8-030-01-X-D-RA-L SHOWN
(DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG 1)
7.95 .313
3.70 .146 REF
1.22 .048 REF
C-231-02-X
'J'
C
2.58±0.12 .101±.005
'K'
T-1R37-XX-T
(SEE TABLE 4)
ERF8-RA-XXX
**NOT RELEASED FOR PRODUCTION
FIG 2
3.55 .140 REF
C-231-03-X
WT-33-XX-X
(SEE TABLE 4)
C
C
0.10±0.08 .004±.003
(SEE NOTE 5 & 11)
SEE TABLE 2
TOP ROW, BOTTOM ROW
(LOCATE ASSY ON DATUM -C- FOR MEASURMENT)
BOTTOM ROW TAIL
(LOCATE ASSY ON DATUM -C- FOR MEASUREMENT)
DETAIL 'J'
0.35 .014 (REF)
C
2.22 .087
C
6.95±0.12 .274±.005
C
8.35 .329
C
8.70±0.12 .34±.005
-C-
0.90±0.08 .036±.003 (TYP)
C
C
0.10±0.08 .004±.003
(SEE NOTE 5 & 11)
TOP ROW TAIL
(LOCATE ASSY ON DATUM -C- FOR MEASUREMENT)
C
L
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
DETAIL 'K'
*
PROPRIETARY NOTE
*
SECTION "A"-"A"
SCALE 8 : 1
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DO NOT SCALE DRAWING
SHEET SCALE: 6:1
0.8mm DUAL ROW RIGHT ANGLE SOCKET ASSEMBLY
DWG. NO.
ERF8-XXX-XX-X-D-RA-XXX-TR
08-10-2010
SHEET
2
OF
6
F:\DWG\MISC\MKTG\ERF8-XXX-XX-X-D-RA-XXX-TR-MKT.SLDDRW
BY:
D BOYCE
REVISION Y
R0.35 .014
-D-
0.35 .014
MEASUREMENT
LOCATION FOR C18
C
1.351 .0532
(SEE NOTE 10)
0.70 .028
SKEW MEASUREMENT
POINT FOR C25
E1
2.30 .091
SKEW DATUM
POINT FOR C25
E2
-E-
D2
D1
90°
+0°
- 3°
C
90°
- 3°
(SEE NOTE 10)
C
+0°
0.50 .020
MEASUREMENT
LOCATION FOR C25
0.70 .028
SKEW MEASUREMENT
POINT FOR C18/
R0.35 .014
0.25±0.08 .010±.003
(BOTH ENDS)
C
3.051 .1201
(SEE NOTE 10)
C
0.55 .022
SKEW DATUM
POINT FOR C18
(FORM 1 CONTACT C-231-02-X)
IN-PROCESS 8
"L" REF
(FORM 1 CONTACT C-231-03-X)
IN-PROCESS 2
C
90°
- 3°
(SEE NOTE 11)
2°
- 1°
(SEE NOTE 10)
+2°
+0°
E1
0.70 .028
SKEW MEASUREMENT
POINT FOR C28
C
R0.35 .014
3.051 .1201
(SEE NOTE 11)
C
C
1.351 .0532
(SEE NOTE 10)
D1
0.70 .028
SKEW MEASUREMENT
POINT FOR C21
E2
C
2.30 .091
SKEW DATUM
POINT FOR C28
R0.35 .014
0.50 .020
MEASUREMENT
LOCATION FOR C25
C
D2
1.70±0.10 .067±.004
(SEE NOTE 10)
R0.35 .014
(2 PLCS)
0.35 .014
MEASUREMENT
LOCATION FOR C18
1.555 .0612
(SEE NOTE 5 & 10)
-D-
C
0.55 .022
SKEW DATUM
POINT FOR C21
5.545 .2183
(SEE NOTE 4 & 11)
C
+2°
-E-
C
2°
- 1°
(SEE NOTE 11)
(COMB CUT CONTACT
C-231-03-X & C-231-02-X)
IN PROCESS 1 & 7
(FORM 2 CONTACT C-231-02-X)
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
IN PROCESS-9
*
*
PROPRIETARY NOTE
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
0.8mm DUAL ROW RIGHT ANGLE SOCKET ASSEMBLY
(FORM 2 CONTACT C-231-03-X)
F:\DWG\MISC\MKTG\ERF8-XXX-XX-X-D-RA-XXX-TR-MKT.SLDDRW
IN-PROCESS 3
SHEET SCALE: 4:1
ERF8-XXX-XX-X-D-RA-XXX-TR
08-10-2010
SHEET
3
OF
6
BY:
D BOYCE
REVISION Y
SHEAR CARRIER
C-231-03-X
SEE TABLE 2, SHT 2
0.10 .004 REF
6.05 .238 REF
-C-
0.10 .004 REF
6.95 .274 REF
-C-
0.90 .036 REF
(FILL BOTTOM ROW)
(SEE INSPECTION VIEW 1 FOR ASSEMBLY ORIENTATION AND CPC'S)
IN-PROCESS 4
(CUTOFF OF CARRIER)
(SEE INSPECTION VIEW 1 FOR ASSEMBLY ORIENTATION AND CPC'S)
IN-PROCESS 5
INSPECTION VIEW 1
(SEE NOTE 12)
Z1
-C-
Z2
ERF8-RA-XXX
C
6.95±0.10 .274±.004
(SEE NOTE 10)
0.90±0.08 .036±.003
(SEE NOTE 10)
C
Z1
Z2
C
SEE TABLE 2, SHT 2
C
0.10±0.08 .004±.003
(SEE NOTE 5,10 & 11)
-C-
7.80 .307
C
C
6.05±0.08 .238±.003
(SEE NOTE 10)
0.65 .026
REF
DETAIL 'C'
SCALE 8 : 1
'C'
DETAIL 'D'
SCALE 8 : 1
'D'
C
0.10±0.08 .004±.003
(SEE NOTE 5,10 & 11)
(FILL ERF8-RA-XXX)
IN-PROCESS 6
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
*
PROPRIETARY NOTE
*
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
(CARRIER NOT SHOWN FOR IN PROCESS 4 INSPECTIONS)
F:\DWG\MISC\MKTG\ERF8-XXX-XX-X-D-RA-XXX-TR-MKT.SLDDRW
INSPECTION FOR IN-PROCESS 4 & 5
0.8mm DUAL ROW RIGHT ANGLE SOCKET ASSEMBLY
SHEET SCALE: 4:1
ERF8-XXX-XX-X-D-RA-XXX-TR
08-10-2010
SHEET
4
OF
6
BY:
D BOYCE
REVISION Y
2.58
- 0.25
.101
- .010
C
0.00
+.000
C-231-02-X
HEAT STAKE
TOP ROW TAILS
C
0.10 .004 REF
7.80 .307 REF
-C-
0.10 .004 REF
7.80 .307 REF
-C-
(FILL TOP ROW)
(SEE INSPECTION VIEW 2 FOR ASSEMBLY ORIENTATION AND CPC'S)
IN-PROCESS 10
(HEAT STAKE TOP ROW CONTACTS)
(SEE INSPECTION VIEW 2 FOR ASSEMBLY ORIENTATION AND CPC'S)
IN-PROCESS 11
INSPECTION VIEW 2
(SEE NOTE 12)
Z1
Z2
C
7.80±0.08 .307±.003
(SEE NOTE 10)
C
8.70±0.10 .343±.004
(SEE NOTE 10)
0.90±0.08 .036±.003
(SEE NOTE 10)
C
C
Z1
0.14±0.14 .006±.006
Z2
C
SEE TABLE 2, SHT 2
0.10±0.08 .004±.003
(SEE NOTE 5, 10 & 11)
C
C
0.10±0.08 .004±.003
(SEE NOTE 5,10 & 11)
-C-
SHEAR CARRIER
-C-
0.28
+0.04
.011
+.002
- 0.02
- .001
C
SEE TABLE 2, SHT 2
0.10 .004
REF
0.90 .036 REF
8.70 .343 REF
DETAIL 'E'
SCALE 8 : 1
'E'
DETAIL 'F'
SCALE 8 : 1
'F'
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
*
PROPRIETARY NOTE
*
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
(CARRIER NOT SHOWN FOR IN PROCESS 10 & 11 INSPECTIONS)
F:\DWG\MISC\MKTG\ERF8-XXX-XX-X-D-RA-XXX-TR-MKT.SLDDRW
INSPECTION FOR IN-PROCESS 10, 11 & 12
0.8mm DUAL ROW RIGHT ANGLE SOCKET ASSEMBLY
SHEET SCALE: 4:1
ERF8-XXX-XX-X-D-RA-XXX-TR
08-10-2010
SHEET
5
OF
6
BY:
D BOYCE
京公网安备 11010802033920号
EEWORLD
