MUR1600 – MUR1660
16A GLASS PASSIVATED SUPERFAST RECTIFIER
WON-TOP ELECTRONICS
Pb
Features
Glass Passivated Die Construction
Superfast 35nS and 50nS Recovery Time
Low Forward Voltage Drop
Low Reverse Leakage Current
Soft Recovery Characteristics
Epoxy Meets UL 94V-0 Classification
Ideally Suited for Use in High Frequency
SMPS, Inverters and As Free Wheeling Diodes
C
G
PIN1
3
B
Dim
A
TO-220A
Min
13.90
9.80
2.54
3.56
12.70
0.51
3.55 Ø
5.75
4.16
2.03
0.30
1.14
4.83
Max
15.90
10.70
3.43
4.56
14.73
0.96
4.09 Ø
6.85
5.00
2.92
0.65
1.40
5.33
A
B
C
D
E
F
D
F
P
I
H
L
E
Mechanical Data
Case: TO-220A, Molded Plastic
Terminals: Plated Leads Solderable per
MIL-STD-202, Method 208
Polarity: See Diagram
Weight: 1.9 grams (approx.)
Mounting Position: Any
Mounting Torque: 0.6 N.m Max.
Lead Free: For RoHS / Lead Free Version,
Add “-LF” Suffix to Part Number, See Page 4
G
H
I
J
K
L
P
All Dimensions in mm
PIN 1
J
K
PIN 3
Case
Maximum Ratings and Electrical Characteristics
@T
A
=25°C unless otherwise specified
Single Phase, half wave, 60Hz, resistive or inductive load. For capacitive load, derate current by 20%.
MUR
1600
50
35
MUR
1610
100
70
MUR
1615
150
105
MUR
1620
200
140
16
250
0.975
10
500
35
175
73
1.2
-65 to +175
50
145
1.3
1.5
MUR
1630
300
210
MUR
1640
400
280
MUR
1660
600
420
Characteristic
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
Average Rectified Output Current
@T
C
= 100°C
Symbol
V
RRM
V
RWM
V
R
V
R(RMS)
I
O
I
FSM
V
FM
I
RM
t
rr
C
J
R
θJA
R
θJC
T
J
, T
STG
Unit
V
V
A
A
V
µA
nS
pF
°C/W
°C
Non-Repetitive Peak Forward Surge Current
8.3ms Single Half Sine-Wave Superimposed
on Rated Load (JEDEC Method)
Forward Voltage
Peak Reverse Current
At Rated DC Blocking Voltage
Reverse Recovery Time (Note 1)
Typical Junction Capacitance (Note 2)
Thermal Resistance Junction to Ambient
Thermal Resistance Junction to Case
Operating and Storage Temperature Range
@I
F
= 16A
@T
C
= 25°C
@T
C
= 100°C
Note: 1. Measured with I
F
= 0.5A, I
R
= 1.0A, I
RR
= 0.25A.
2. Measured at 1.0 MHz and applied reverse voltage of 4.0V D.C.
© Won-Top Electronics Co., Ltd.
Revision: March, 2014
www.wontop.com
1
®
MUR1600 – MUR1660
I
(AV)
, AVERAGE FORWARD RECTIFIED CURRENT (A)
WON-TOP ELECTRONICS
I
F
, INSTANTANEOUS FORWARD CURRENT (A)
20
100
MUR1630
MUR1640
16
MUR1600 – MUR1620
10
12
8
MUR1660
1.0
4
Resistive or
Inductive Load
0
0
20
40 60 80 100 120 140 160 180 200
T
C
, CASE TEMPERATURE (°C)
Fig. 1 Forward Current Derating Curve
I
R
, INSTANTANEOUS REVERSE CURRENT (µA)
0.1
0
0.4
0.8
1.2
1.6
2.0
V
F
, INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 2 Typical Forward Characteristics
I
FSM
, PEAK FORWARD SURGE CURRENT (A)
250
Single Half-Sine-Wave
JEDEC Method
1000
200
100
T
C
= 125°C
T
C
= 100°C
150
10
100
1.0
T
C
= 25°C
50
0.1
0
1
10
100
NUMBER OF CYCLES AT 60Hz
Fig. 3 Forward Surge Current Derating Curve
0.01
0
20
40
60
80
100
120
140
PERCENT OF RATED PEAK REVERSE VOLTAGE (%)
Fig. 4 Typical Reverse Characteristics
500
DC, T
J
= 150°C
20
C
J
, JUNCTION CAPACITANCE (pF)
P
D
, POWER DISSIPATION (W)
16
MUR1630
MUR1640
400
f = 1MHz
12
MUR1660
300
MUR1600 – MUR1640
8
200
4
MUR1600 – MUR1620
100
MUR1660
0
0
8
12
16
4
20
I
F(AV)
, AVERAGE FORWARD CURRENT (A)
Fig. 5 Forward Power Dissipation
0
0.1
1
10
V
R
, DC REVERSE VOLTAGE (V)
Fig. 6 Typical Junction Capacitance
100
www.wontop.com
2
© Won-Top Electronics Co., Ltd.
Revision: March, 2014
®
MUR1600 – MUR1660
WON-TOP ELECTRONICS
MARKING INFORMATION
MUR16xx
MUR16xx
xx
Polarity
= Device Number
= 00, 10, 15, 20, 30, 40 or 60
= As Marked on Body
PACKAGING INFORMATION
BULK
Tube Size
L x W x H (mm)
525 x 31 x 6
Quantity
(PCS)
50
Inner Box Size
L x W x H (mm)
555 x 145 x 95
Quantity
(PCS)
2,000
Carton Size
L x W x H (mm)
572 x 306 x 218
Quantity
(PCS)
8,000
Approx. Gross Weight
(KG)
19.0
Note:
1. Anti-static tube, water clear color.
RECOMMENDED SCREW MOUNTING ARRANGEMENT
Recommended isolated mounting when
screw is at heatsink potential. 4-40
hardware is used.
Screw should not be tightened with any
type of air-forced torque or equipment
that may cause high impact on device
package. The insulating bushing inside
the mounting hole will insure the screw
threads do not contact the metal base.
The interface should apply a layer of
thermal grease or a highly conductive
thermal pad for better heat dissipation.
4-40 PAN or HEX Head Screw
Plain Washer
Insulating Bushing
Rectifier
Insulator
Heatsink
Compression Washer
4-40 HEX Nut
© Won-Top Electronics Co., Ltd.
Revision: March, 2014
www.wontop.com
3
®
MUR1600 – MUR1660
WON-TOP ELECTRONICS
ORDERING INFORMATION
Product No.
MUR1600
MUR1610
MUR1615
MUR1620
MUR1630
MUR1640
MUR1660
1.
2.
Package Type
TO-220A
TO-220A
TO-220A
TO-220A
TO-220A
TO-220A
TO-220A
Shipping Quantity
50 Units/Tube
50 Units/Tube
50 Units/Tube
50 Units/Tube
50 Units/Tube
50 Units/Tube
50 Units/Tube
Shipping quantity given is for minimum packing quantity only. For minimum
order quantity, please consult the Sales Department.
To order RoHS / Lead Free version (with Lead Free finish), add “-LF”
suffix to part number above. For example, MUR1600-LF.
WON-TOP ELECTRONICS and
are registered trademarks of Won-Top Electronics Co., Ltd (WTE). WTE has checked all information carefully and
believes it to be correct and accurate. However, WTE cannot assume any responsibility for inaccuracies. Furthermore, this information does not give the
purchaser of semiconductor devices any license under patent rights to manufacturer. WTE reserves the right to change any or all information herein
without further notice.
WARNING:
DO NOT USE IN LIFE SUPPORT EQUIPMENT. WTE power semiconductor products are not authorized for use as critical components in life
support devices or systems without the express written approval.
Won-Top Electronics Co., Ltd.
No. 44 Yu Kang North 3rd Road,
Chine Chen Dist., Kaohsiung 806, Taiwan
Phone:
886-7-822-5408 or 886-7-822-5410
Fax:
886-7-822-5417
Email:
sales@wontop.com
Internet:
http://www.wontop.com
We power your everyday.
www.wontop.com
4
© Won-Top Electronics Co., Ltd.
Revision: March, 2014
