the following alphabet shall be put in the underlined part.
For availability, delivery and minimum order quantity, contact JST.
ex.
ex.
B10B-PHDSS-
S…natural (ivory)
B10B-PHDSS-B-
S…natural (white)
K…black Y…yellow E…blue R…red
2.0
(.079)
Circuit
No.1
1.5
Circuit
No.2
7.0(.276)
H
JST
33
PHD
CONNECTOR
PC board layout
(viewed from soldering side)
and Assembly layout –––––––––––––––––––
Top entry type
2.0±0.05 1.95
0.1
(.079±.002) (.077)
min.
0.7
+ 0
.004
(.028
+ 0
)dia.
Even number
circuits
Side entry type
1.5
(.059)
min.
5.0(.197)
2.0±0.05
1.95
(.079±.002) (.077)
min.
7.0(.276)
min.
11.8(.465)
5.0(.197)
8.8(.346)
Circuit No.1
2.0±0.05
(.079±.002)
Odd number
circuits
0.7
(.028
Even number
circuits
+ 0.1
0
+ .004
0
)dia.
Circuit No.1
Note:
1. Tolerances are non-cumulative: ±0.05mm(±.002") for all centers.
2. Hole dimensions differ according to the kind of PC board and piercing method. If printed circuit boards made of hard material such as FR-4 are used, the hole
dimensions should be larger. The dimensions above should serve as a guideline. Contact JST for details.
Applicator for the semi-automatic press AP-K2N –––––––––––––––––––––––––––––––
