Pin strip |
Spacing 3.81 mm
STLZ1570/..G-3.81-V-GREEN
Technical Data
Wire Sizes
Solid min
solid max
Stranded (flexible)
min
Stranded (flexible)
max
-
-
-
-
Insulating Material
Material
Flammability Class
Temperatures
Operating Temperature
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Reflow Process
Soldering Temperature,
recommended
1.2 mm
Copper Alloy
Peak Soldering Time,
recommended
Leere Zeile
-
-
265 °C
3-4 s
-30 °C - 105 °C
PBT
UL 94 V-0
Order Data (Spacing mm)
Poles
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Width (mm)
9.01
12.82
16.63
20.44
24.25
28.06
31.87
35.68
39.49
43.30
47.11
50.92
54.73
58.54
62.35
66.16
69.97
73.78
77.59
Article Designation
STLZ1570/2G-3.81-V-GREEN
STLZ1570/3G-3.81-V-GREEN
STLZ1570/4G-3.81-V-GREEN
STLZ1570/5G-3.81-V-GREEN
STLZ1570/6G-3.81-V-GREEN
STLZ1570/7G-3.81-V-GREEN
STLZ1570/8G-3.81-V-GREEN
STLZ1570/9G-3.81-V-GREEN
STLZ1570/10G-3.81-V-GREEN
STLZ1570/11G-3.81-V-GREEN
STLZ1570/12G-3.81-V-GREEN
STLZ1570/13G-3.81-V-GREEN
STLZ1570/14G-3.81-V-GREEN
STLZ1570/15G-3.81-V-GREEN
STLZ1570/16G-3.81-V-GREEN
STLZ1570/17G-3.81-V-GREEN
STLZ1570/18G-3.81-V-GREEN
STLZ1570/19G-3.81-V-GREEN
STLZ1570/20G-3.81-V-GREEN
Article Number
51570025121E
51570035121E
51570045121E
51570055121E
51570065121E
51570075121D
51570085121D
51570095121D
51570105121D
51570115121D
51570125121D
51570135121D
51570145121D
51570155121D
51570165121D
51570175121D
51570185121D
51570195121D
51570205121D
PU
100
100
100
100
100
50
50
50
50
50
50
50
50
50
50
50
50
50
50
Stranded with Ferrule -
min
Stranded with Ferrule -
max
Dimensions
Stripped Length
PCB Hole Diameter
Materials
Contact Pin
Colours
GREEN
LIGHT GREEN
RAL6018
similar RAL 6018
RAL6018
similar RAL 6018
Accessories
Figure
Designation
Coding star CS1-3.5/3.81-RED
Article Number
50000000023
Colours according to RAL, there may be variations on colour due to production conditions.
Special colours on request.
Counterparts (Spacing 3.81 mm)
Pin Strip/Terminal Blocks
AKZ1550
AKZ4551
AKZ1710
AKZ1700
Ratings
Usegroup
Rated Voltage
Rated Current
Overvoltage Category
Test Voltage
Pollution Degree
B
300 V
8A
1.6 kV
C
-
-
-
D
300 V
8A
1.6 kV
160 V
9A
III
2.5 kV
3
