PIN RECEPTACLES
for 0,56 - 0,86 diameter pins
and 0,64 square pins
PR
E
CI
M
ON
S
I
CHI
A
PINS
NE
D
9808
1,96 DIA.
1,78 DIA.
1,57 DIA.
0,76
0,71 2,29
9101
1,91 DIA.
2,11
2,67
3,94
5650
2,16 DIA.
1,78 DIA.
0,79
0,71 2,49
3,18
8679
2,54 DIA.
1,68
3,18
3,94
2,18 DIA.
1,78 DIA.
0,71
8,38
9,53
1,55 DIA.
7,49
2,39
5,33
6,35
1,75 DIA.
0,51 DIA.
2,54
1,57 DIA.
0,89 DIA.
HOLE
9808-0-15-XX-16-XX-04-0
Press-fit in 1,70 mounting hole
9101-0-15-XX-16-XX-10-0
Press-fit in 1,70 mounting hole
5650-0-19-XX-16-XX-10-0
Press-fit in 1,70 mounting hole
8679-0-15-XX-16-XX-10-0
Solder mount in 1,80 min.
mounting hole
8827
1,83 DIA.
1,63 DIA.
0,81
0,71 2,34
5,84
1,52 DIA.
6,6
6021
0,46
1,98 DIA.
2,11
1,52 DIA.
4,19
4,83
1873
2,18 DIA.
1,75 DIA.
0,79
0,71 2,39
5,59
1,57 DIA.
7,29
0,76 DIA.
5,84
0,51 DIA.
3,3
8827-0-15-XX-16-XX-04-0
Press-fit in 1,55 mounting hole
6021-0-15-XX-16-XX-10-0
Solder mount in 1,57 min.
mounting hole
1873-0-15-XX-16-XX-04-0
Press-fit in 1,68 mounting hole
SPECIFICATIONS
SHELL MATERIAL:
Brass Alloy 360, 1/2 Hard
CONTACT MATERIAL:
Beryllium Copper Alloy 172, HT
DIMENSION IN INCHES
TOLERANCES ON:
LENGTHS:
±0,13
DIAMETERS: ±0,05
ANGLES:
± 2°
ORDER CODE: XXXX - X - 1X - XX - 16 - XX - XX - 0
BASIC PART #
SPECIFY SHELL FINISH:
01
5,08μm TIN/LEAD OVER NICKEL
80
5,08μmTIN OVER NICKEL (RoHS)
15
0,25μm GOLD OVER NICKEL (RoHS)
2002/95/EC
SPECIFY CONTACT FINISH:
01
5,08μm TIN/LEAD OVER NICKEL
80
5,08μm TIN OVER NICKEL (RoHS)
27
0,76μm GOLD OVER NICKEL (RoHS)
RoHS
CONTACT
#16
CONTACT (DATA ON PAGE 222)
