PIN
RECEPTACLES
FOR .015” - .025” DIAMETER PINS
0385
0385-0-15-XX-43-XX-10-0
Press-fit in .046 mounting hole
4001
4001-0-15-XX-43-XX-04-0
Press-fit in .057 mounting hole
1782
1782-0-15-XX-43-XX-04-0
Press-fit in .045 mounting hole
5960
5960-0-15-XX-43-XX-04-0
Hex press-fit in .057 plated through-hole
1401/3185
XXXX-0-15-XX-30-XX-10-0
Solder mount in .055 min. mounting hole
Also available on 16mm wide carrier tape:
1,700 parts per 13” reel
Order as: XXXX-0-57-XX-30-XX-10-0
4310
Basic Part
Number
Length
L
Depth
N
4310-0-31-XX-43-XX-04-0
Compliant press-fit in .040 ± .003 plated
through-hole. For .090”
.130”
thick board
1385
1385-0-15-XX-43-XX-10-0
Surface mount
1401-0
3185-0
.165
.130
.145
.109
3018
3018-0-15-XX-30-XX-04-0
Press-fit in .057 mounting hole
8852
8852-0-15-XX-30-XX-04-0
Press-fit in .056 mounting hole
3907
3907-0-18-XX-30-XX-10-0
Surface mount
Also available on 12mm wide carrier tape:
4,000 parts per 13” reel
Order as: 3907-0-58-XX-30-XX-10-0
.100 DIA.
.020
.083
.115
.043 DIA.
.010
.095
.060
.059
.080
.084 DIA.
P.C.B. Layout
.069
PAGE 170 | PIN RECEPTACLES
P.C.B. PAD
.095
SPECIFICATIONS:
Shell Material:
Brass Alloy 360, 1/2 Hard
Contact Material:
Beryllium Copper Alloy 172, HT
Dimensions: Inches
Tolerances On:
Lengths:
± .005
RoHS - 2
2011/65/EU
ORDER CODE: XXXX - X - XX - XX -
XX
- XX - XX - 0
BASIC PART #
SPECIFY SHELL FINISH:
01
200
”
TIN/LEAD OVER NICKEL
80
200
”
TIN OVER NICKEL (RoHS)
15
10
”
GOLD OVER NICKEL (RoHS)
SPECIFY CONTACT FINISH:
02
100
”
TIN/LEAD OVER NICKEL
84
100
”
TIN OVER NICKEL (RoHS)
27
30
”
GOLD OVER NICKEL (RoHS)
Diameters: ± .002
Angles:
±2°
SELECT CONTACT:
#30, #35 or #43
CONTACT (DATA ON PAGE 253 & 254)
(For alternate contact choices, see groups B and C on page 248)
