13
12
11
10
9
8
7
6
5
4
3
2
1
PART NUMBER DATA
J
A
A IN mm
B IN mm
.394
.787
1.181
1.575
1.969
2.362
2.756
3.150
3.543
3.937
4.331
10.00
20.00
30.00
40.00
50.00
60.00
70.00
80.00
90.00
100.00
110.00
CIRCUITS
2
3
4
5
6
7
8
9
10
11
12
I
H
PART
NUMBER
391002102
391002103
391002104
391002105
391002106
391002107
391002108
391002109
391002110
391002111
391002112
ENGINEERING
NUMBER
M800-02-02-5
M800-02-03-5
M800-02-04-5
M800-02-05-5
M800-02-06-5
M800-02-07-5
M800-02-08-5
M800-02-09-5
M800-02-10-5
M800-02-11-5
M800-02-12-5
COLOR
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
B
.394
J
.67
1.06
1.46
1.85
2.24
2.64
3.03
3.43
3.82
4.21
4.61
17.0
27.0
37.0
47.0
57.0
67.0
77.0
87.0
97.0
107.0
117.0
I
.74
H
REF. LAST 2 DIGITS OF PART NUMBER EQUAL CIRCUIT COUNT
.394
NOTE: IF THIS PRODUCT IS STORED IN AN
ENVIRONMENT WITH A RELATIVE HUMIDITY
OF LESS THAN 50%, MOISTURE MUST BE
ADDED. REFER TO TECHNICAL ADVISORY
AS 45499-001 FOR INSTRUCTIONS.
.284
.23
A
G
C
G
C
.62
.31
F
F
D
B
E
E
CONTACT FACTORY FOR OPTIONAL COLORS
V
D E
V
D E
V
D E
3910021
300V 30A
D
SPECIFICATIONS:
1.Material:
(A) Screw: Steel, Zinc plated
(B) Body: PA66 UL94 V-0
(C) Cage: Brass, Nickel plated
(D) Terminal: Stainless Steel
2.Rating: 300V, 30amps
3.Wire range: 18-10 AWG
4.Max torque: 7.0 in lbs.
5.Dielectric voltage withstand: DC 3000V for 1 minute.
DESCRIPTION
3910021
300V 30A
D
C
C
B
GENERAL TOLERANCES
(UNLESS SPECIFIED)
DIMENSION STYLE
SCALE
DESIGN UNITS
IN/MM
DRAWN BY
DATE
TITLE
CHECKED BY
DATE
---
METRIC
THIRD ANGLE
PROJECTION
B
7.Rated Impulse Voltage: 4000V, Plus and Minus 5 times each
8.Strip Length: .24 in. (6.0mm)
A
=
0
C
mm
4 PLACES
3 PLACES
2 PLACES
1 PLACE
---
---
---
---
---
INCH
---
---
---
---
=
0
APPROVED BY
DATE
molex
TERMINAL STRIP 10MM
LOW PROFILE 300V
----
MOLEX INCORPORATED
SHEET NO.
11.All dims. shown are for reference only
C1
13
12
11
10
9
8
REV
DRAFT WHERE
APPLICABLE
MUST REMAIN
WITHIN DIMENSIONS
7
6
5
MATERIAL NO.
DOCUMENT NO.
SEE CHART
SIZE
A
SD-39100-014
3
2
1
C
THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX
INCORPORATED AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION
4
