SUCOTEST 18A - the outdoor TEST+MEASUREMENT cable assembly
Part no.:
Item no.:
SUCOTEST 18A/11N468/11N468/3000 mm
84013031
Electrical specifications
Impedance
Operating frequency
Velocity of propagation
Capacitance
Time delay
Insulation resistance
Dielectric withstand voltage
Screening effectiveness @ 1 GHz
50 Ohms
18 GHz
77%
87 pF/m
4.3 ns/m
> 5 × 103 MΩ
1'500 V rms
> 100 dB
Electrical table
up to
2 GHz
Min. return loss
Max. insertion loss at 25°C
Max. insertion loss vs. shaking
Max. insertion loss vs. bending
Max. insertion loss vs. torsion
Phase stability vs. bending
(dB)
(dB)
(dB)
(dB)
(dB)
(degree)
30
< 1.53
< 0.03
< 0.03
< 0.03
+/- 2.0
2.01 to
4 GHz
28
< 2.24
< 0.03
< 0.04
< 0.04
+/- 4.0
4.01 to
6 GHz
25
< 2.80
< 0.03
< 0.04
< 0.04
+/-4.0
6.01 to
12 GHz
21
< 4.17
< 0.03
< 0.05
< 0.05
+/- 6.0
12.01 to
18 GHz
19
< 5.30
< 0.03
< 0.05
< 0.05
+/- 6.0
Mechanical specifications
Armoured cable diameter
Min. bending radius dynamic
Flex life (cycles)
Connector retention force (N)
Crush resistance (kN/m)
Recommended mating torque
Connector interface
10.3 mm
50 mm
100'000
> 230
> 80
0.68 Nm... 1.13 Nm
MIL-STD-348A/304
Materials and finishes
Armour jacket
Cable dielectric
Taper sleeves
Marking sleeve
Connector contacts
Connector insulation
Connector body
Connector nut
PUR, blue
LDPTFE
Santoprene, black
Crosslinked polyolefin
Copper alloy
PTFE
Stainless steel, passivated
Stainless steel, passivated
Environmental specifications
Temperature range
Humidity range
Water tightness
-55 °C to +85 °C
10 to 95 °C RH
IP 68
Excellence in connectivity solutions
Care and handling instructions for HUBER+SUHNER microwave cables
HUBER+SUHNER microwave cable assemblies of all types
offer a long service life providing they are treated with the
appropriate care and attention. Microwave cable assem-
blies are high precision system components and require
proper handling in order to ensure that measuring perfor-
mance values are maintained.
To achieve the maximum measuring performance the follo-
wing guidelines should be followed:
1. Assemblies should remain in their original packaging
for delivery and storage. Storage temperature should be
between +13 °C and +80 °C and the relative humidity
should not exceed 85%.
6. Choose the measurement routing using the largest bend
radii possible. Small bend radii may affect electrical per-
formance. Exceeding the specified limits during the measu-
rement process could cause a permanent degradation.
7. Avoid twisting microwave cable assemblies. Torsion
of this type of assembly can alter the relative diameters
of cable layers and affects the electrical characteristics.
Exceeding the limit of 10° per metre during measuring
process could cause a permanent degradation.
8. Examine interfaces for damage and/or contamination
before mating.
2. Carefully unpack assemblies before measurement.
Avoid kinking cables when straightening from a coil or
reel.
9. Discharge connectors before mating or ensure that they
are connected to a suitable ground.
3. Ensure that the surroundings are clean and free of dust,
dirt and any other particles that could enter unsealed con-
nector interfaces.
10. When mating connectors with a screwed interface
always hold the connector bodies and turn only the cou-
pling nut. This avoids twisting the cable and ensures mini-
mum wear on the connector pins.
4. Use protective caps to prevent contamination whenever
connectors are unmated.
11. Do not exceed the torque specified.
5. Where interfaces are contaminated, particles can be
removed with dry, oil-free compressed air. Please use
eye-protection. Interfaces can be cleaned with dry cotton
swabs. Do not use hard hand-tools or solvents. Do not
blow into interfaces or use normal compressed-air.
HUBER+SUHNER is certified according
to ISO 9001 and ISO 14001.
WAIVER
It is exclusively in written agreements that we provide our customers with warrants and representa-
tions as to the technical specifications and/or the fitness for any particular purpose. The facts
and figures contained herein are carefully compiled to the best of our knowledge, but they are
intended for general informational purposes only.
HUBER+SUHNER AG
RF Industrial
9100 Herisau/Switzerland
Tel. +41 (71) 353 41 11
Fax+41 (71) 353 45 90
www.hubersuhner.com
Excellence in connectivity solutions
XXXXXXXX/08.2005, 4511Teg/st
