souriau
Quick Release
845
Series
8810
Applications
- Sub marine battery quick
disconnection
- Release for subsea weapon systems
Description
These special plugs can be screw coupled in
the normal way, but have the extra facility to
be quick released by pulling on the coupling
nut. Various types of lanyard for diver opera-
tion can be used, or direct uncoupling
by remote actuator achieved with fork
mechanisms. These quick release plugs are
available with all receptacle types.
Nota : Adaptor for non standard OD cables
can’t be used.
Standard
Quick release plug (76 H series)
STEP 1
Fully mated step
Ordering information
shell
size
1
2
2
2
3
4
4
4
.no.
of
contacts
4
7
4
1
12
19
12
4
38
37
1
68
plug
ring
8810-76H-1-04SA 8810-1062
8810-76H-2-07SA
8810-76H-2-04S 8810-1063
8810-76H-2-01SA
8810-76H-3-12SA 8810-1064
8810-76H-4-19SA
8810-76H-4-12SA 8810-1065
8810-76H-4-04SA
8810-76H-7-38SA 8810-3718
8810-76H-5-37SA 8810-1649
8810-76H-5-01SA
8810-76H-6-68SA
8810-2596
A
7
Loop delivered on
special request
STEP 2
Flexible clutched system during release operation
B
ØC
5
5
6
6
4 + 2 8810-76H-6-04SA
Nota : the plug part number includes
the quick release ring
Dimensions
shell
size
1
Quick release ring
A
64.4
2.535
Dimensions
B
91
3.583
Ø C Max
45.6
1.795
2
64.4
2.535
91
3.583
50.6
1.992
3
pull off force (decanewtons)
pressure
in bars shell size
1
1
170
20
30
40
60
80
77
117
159
212
57.5
88
106
160
240
320
120
245
325
485
645
350
500
700
900
200
393
509
786
1178
1571
5
shell size
2
shell size
3
shell size
4
shell size
7
shell size
5
shell size
6
200
7
4
64.4
2.536
92
3.622
57.6
2.268
64.4
2.54
93
3.661
61.6
2.425
71.8
2.827
123
4.863
78.6
3.094
117.4
4.622
184
7.244
105.6
4.157
6
117.4
4.622
184
7.244
126.6
4.984
Nota : For the other dimensions,
see the 8810 series
468
