M54HC166K1 Overview

RAD-HARD 8 BIT PISO SHIFT REGISTER

M54HC166K1 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	STMicroelectronics
Parts packaging code	DFP
package instruction	DFP, FL16,.3
Contacts	16
Reach Compliance Code	_compli
Counting direction	RIGHT
series	HC/UH
JESD-30 code	R-CDFP-F16
JESD-609 code	e0
length	9.94 mm
Logic integrated circuit type	PARALLEL IN SERIAL OUT
Maximum Frequency@Nom-Su	21000000 Hz
Number of digits	8
Number of functions	1
Number of terminals	16
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Output polarity	TRUE
Package body material	CERAMIC, METAL-SEALED COFIRED
encapsulated code	DFP
Encapsulate equivalent code	FL16,.3
Package shape	RECTANGULAR
Package form	FLATPACK
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
power supply	2/6 V
propagation delay (tpd)	225 ns
Certification status	Not Qualified
Maximum seat height	2.38 mm
Maximum supply voltage (Vsup)	6 V
Minimum supply voltage (Vsup)	2 V
Nominal supply voltage (Vsup)	4.5 V
surface mount	YES
technology	CMOS
Temperature level	MILITARY
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	FLAT
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Trigger type	POSITIVE EDGE
width	6.91 mm
minfmax	25 MHz
Base Number Matches	1

Preview

Download Datasheet

View All

M54HC166

RAD-HARD 8 BIT PISO SHIFT REGISTER

HIGH SPEED:

MAX

= 63 MHz (TYP.) at V

= 6V

LOW POWER DISSIPATION:

=4µA(MAX.) at T

=25°C

HIGH NOISE IMMUNITY:

NIH

= V

NIL

= 28% V

(MIN.)

SYMMETRICAL OUTPUT IMPEDANCE:

| = I

= 4mA (MIN)

BALANCED PROPAGATION DELAYS:

PLH

≅

PHL

WIDE OPERATING VOLTAGE RANGE:

(OPR) = 2V to 6V

PIN AND FUNCTION COMPATIBLE WITH

54 SERIES 166

SPACE GRADE-1: ESA SCC QUALIFIED

50 krad QUALIFIED, 100 krad AVAILABLE ON

REQUEST

NO SEL UNDER HIGH LET HEAVY IONS

IRRADIATION

DEVICE FULLY COMPLIANT WITH

SCC-9306-043

DILC-16

FPC-16

ORDER CODES

PACKAGE

DILC

FPC

M54HC166D

M54HC166K

M54HC166D1

M54HC166K1

DESCRIPTION

The M54HC166 is an high speed CMOS 8 BIT

PISO SHIFT REGISTER fabricated with silicon

gate C

MOS technology.

It consists of parallel or serial inputs and a

serial-out 8 bit shift register with gated clock inputs

and an overriding clear input. The parallel-in or

serial-in modes are controlled by the SHIFT/LOAD

PIN CONNECTION

input. When the SHIFT/LOAD input is held high,

the serial data input is enabled and the eight

flip-flops perform serial shifting with each clock

pulse; when held low, the parallel data inputs are

enabled and synchronous loading occurs on the

next clock pulse. Clocking is accomplished on the

low-to-high level edge of the clock pulse. The

CLOCK-INHIBIT input should be changed to the

high only while the clock input is held high. A direct

clear input overrides all other inputs, including the

clock, and sets all flip-flops to zero. Functional

details are shown in the truth table and the timing

chart. All inputs are equipped with protection

circuits against static discharge and transient

excess voltage.

March 2004

1/11

M54HC166K1 Related Products

	M54HC166K1	M54HC166D	M54HC166	M54HC166K	M54HC166_04	M54HC166D1
Description	RAD-HARD 8 BIT PISO SHIFT REGISTER	RAD-HARD 8 BIT PISO SHIFT REGISTER	RAD-HARD 8 BIT PISO SHIFT REGISTER	RAD-HARD 8 BIT PISO SHIFT REGISTER	RAD-HARD 8 BIT PISO SHIFT REGISTER	RAD-HARD 8 BIT PISO SHIFT REGISTER
Is it lead-free?	Contains lead	Contains lead	-	Contains lead	-	Contains lead
Is it Rohs certified?	incompatible	incompatible	-	incompatible	-	incompatible
Maker	STMicroelectronics	STMicroelectronics	-	STMicroelectronics	-	STMicroelectronics
Parts packaging code	DFP	DIP	-	DFP	-	DIP
package instruction	DFP, FL16,.3	DIP, DIP16,.3	-	DFP, FL16,.3	-	DIP, DIP16,.3
Contacts	16	16	-	16	-	16
Reach Compliance Code	_compli	_compli	-	_compli	-	_compli
Counting direction	RIGHT	RIGHT	-	RIGHT	-	RIGHT
series	HC/UH	HC/UH	-	HC/UH	-	HC/UH
JESD-30 code	R-CDFP-F16	R-CDIP-T16	-	R-CDFP-F16	-	R-CDIP-T16
JESD-609 code	e0	e0	-	e0	-	e0
length	9.94 mm	20.32 mm	-	9.94 mm	-	20.32 mm
Logic integrated circuit type	PARALLEL IN SERIAL OUT	PARALLEL IN SERIAL OUT	-	PARALLEL IN SERIAL OUT	-	PARALLEL IN SERIAL OUT
Maximum Frequency@Nom-Su	21000000 Hz	21000000 Hz	-	21000000 Hz	-	21000000 Hz
Number of digits	8	8	-	8	-	8
Number of functions	1	1	-	1	-	1
Number of terminals	16	16	-	16	-	16
Maximum operating temperature	125 °C	125 °C	-	125 °C	-	125 °C
Minimum operating temperature	-55 °C	-55 °C	-	-55 °C	-	-55 °C
Output polarity	TRUE	TRUE	-	TRUE	-	TRUE
Package body material	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED	-	CERAMIC, METAL-SEALED COFIRED	-	CERAMIC, METAL-SEALED COFIRED
encapsulated code	DFP	DIP	-	DFP	-	DIP
Encapsulate equivalent code	FL16,.3	DIP16,.3	-	FL16,.3	-	DIP16,.3
Package shape	RECTANGULAR	RECTANGULAR	-	RECTANGULAR	-	RECTANGULAR
Package form	FLATPACK	IN-LINE	-	FLATPACK	-	IN-LINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	NOT SPECIFIED	-	NOT SPECIFIED	-	NOT SPECIFIED
power supply	2/6 V	2/6 V	-	2/6 V	-	2/6 V
propagation delay (tpd)	225 ns	225 ns	-	225 ns	-	225 ns
Certification status	Not Qualified	Not Qualified	-	Not Qualified	-	Not Qualified
Maximum seat height	2.38 mm	3.83 mm	-	2.38 mm	-	3.83 mm
Maximum supply voltage (Vsup)	6 V	6 V	-	6 V	-	6 V
Minimum supply voltage (Vsup)	2 V	2 V	-	2 V	-	2 V
Nominal supply voltage (Vsup)	4.5 V	4.5 V	-	4.5 V	-	4.5 V
surface mount	YES	NO	-	YES	-	NO
technology	CMOS	CMOS	-	CMOS	-	CMOS
Temperature level	MILITARY	MILITARY	-	MILITARY	-	MILITARY
Terminal surface	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	-	Tin/Lead (Sn/Pb)	-	Tin/Lead (Sn/Pb)
Terminal form	FLAT	THROUGH-HOLE	-	FLAT	-	THROUGH-HOLE
Terminal pitch	1.27 mm	2.54 mm	-	1.27 mm	-	2.54 mm
Terminal location	DUAL	DUAL	-	DUAL	-	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED	NOT SPECIFIED	-	NOT SPECIFIED	-	NOT SPECIFIED
Trigger type	POSITIVE EDGE	POSITIVE EDGE	-	POSITIVE EDGE	-	POSITIVE EDGE
width	6.91 mm	7.62 mm	-	6.91 mm	-	7.62 mm
minfmax	25 MHz	25 MHz	-	25 MHz	-	25 MHz
