• coupling variation with temperature, from -55°C to
100°C is very small, ±0.1 dB typ.
• useable over 1400-2700 MHz
• DC current through input to output 2A Max. at 40
watt RF output power
Maximum Ratings
Operating Temperature
Storage Temperature
DC Current
Permanent damage may occur if any of these limits are exceeded.
+RoHS Compliant
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications
Coaxial Connections
INPUT
OUTPUT
COUPLED
1
S
2
Applications
• PCS
• GPS
• PCN
Electrical Specifications at 25°C
Parameter
Condition (MHz)
1400 - 1700
1700 - 2000
2000 - 2300
2300 - 2700
1400 - 1700
Min.
1400
—
—
—
—
—
—
—
—
—
—
—
—
20
20
18
15
—
—
—
—
—
—
—
—
—
—
—
—
—
Typ.
—
0.15
0.17
0.19
0.22
41±1.5
40.5±1.5
40±1.5
40.5±1.5
—
—
—
—
25
25
25
24
26
25
24
20
25
24
23
20
24
20
20
20
—
Max.
2700
0.30
0.30
0.35
0.35
—
—
—
—
±0.8
±0.4
±0.2
±0.5
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
40
Unit
MHz
Outline Drawing
Frequency Range
Mainline Loss
dB
Coupling
1700 - 2000
2000 - 2300
2300 - 2700
1400 - 1700
dB
Coupling Flatness(±)
1700 - 2000
2000 - 2300
2300 - 2700
1400 - 1700
dB
Directivity
1700 - 2000
2000 - 2300
2300 - 2700
1400 - 1700
dB
Outline Dimensions (
inch
)
mm
A
2.00
50.80
H
0.39
9.91
B
2.00
50.80
J
1.00
25.40
C
0.75
19.05
K
0.50
12.70
D
1.00
25.40
L
1.00
25.40
E
0.25
6.35
F
1.500
38.10
G
0.125
3.18
wt
grams
170.0
Return Loss (Input)
1700 - 2000
2000 - 2300
2300 - 2700
1400 - 1700
1700 - 2000
2000 - 2300
2300 - 2700
1400 - 1700
dB
Return Loss (Output)
dB
Return Loss (Coupling)
1700 - 2000
2000 - 2300
2300 - 2700
1400 - 2700
dB
Electrical Schematic
Input Power
W
Typical Performance Data
Frequency
(MHz)
1400
1500
1600
1700
1800
1900
2100
2300
2500
2700
ZADC-40-27HP+
MAINLINE LOSS
COUPLING & DIRECTIVITY (dB)
Mainline Loss
(dB)
In-Out
0.11
0.12
0.11
0.11
0.12
0.12
0.14
0.16
0.17
0.17
ZADC-40-27HP+
COUPLING & DIRECTIVITY
Coupling
(dB)
In-Cpl
40.79
40.49
40.23
40.03
39.87
39.75
39.62
39.60
39.72
39.93
Directivity
(dB)
25.99
26.02
26.78
27.24
28.34
30.13
38.57
35.73
25.74
20.32
In
29.82
29.12
29.53
30.02
28.98
30.32
33.37
39.72
35.55
30.10
ZADC-40-27HP+
RETURN LOSS
Return Loss
(dB)
Out
27.84
27.68
28.06
28.78
29.66
31.38
36.95
39.94
32.18
27.69
Cpl
21.24
21.28
20.86
20.85
20.9
20.65
20.37
20.68
20.83
20.73
0.18
MAINLINE LOSS (dB)
0.16
0.14
0.12
0.10
0.08
0.06
0.04
1400
1600
1800
2000
2200
2400
2600
2800
45
RETURN LOSS (dB)
45
40
35
30
25
20
15
10
1400
1600
1800
IN
2000
OUT
2200
CPL
2400
2600
2800
40
35
30
25
20
15
10
1400
1600
1800
COUPLING
DIRECTIVITY
2000
2200
2400
2600
2800
FREQUENCY (MHz)
FREQUENCY (MHz)
FREQUENCY (MHz)
Notes
A.
Performance and quality attributes and conditions not expressly stated in this specification document are intended to be excluded and do not form a part of this specification document.
B.
Electrical specifications and performance data contained in this specification document are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
C.
The parts covered by this specification document are subject to Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled
to the rights and benefits contained therein. For a full statement of the Standard Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp
www.minicircuits.com
P.O. Box 350166, Brooklyn, NY 11235-0003 (718) 934-4500 sales@minicircuits.com
Clear chemical conversion coating, non-chrome or trivalent chrome based.
Refer to the individual model data sheet for the type of connectors available.
98-F Rev.: K (12/07/15) M153860 File: 98-F
This document and its contents are the property of Mini-Circuits.
Sheet 1 of 8
Mini-Circuits
Environmental Specifications
ENV28
All Mini-Circuits products are manufactured under exacting quality assurance and control standards, and are capable of meeting published specifications after being subjected to
any or all of the following physical and environmental test.
Specification
Test/Inspection Condition
Reference/Spec
Operating Temperature
-55° to 100°C
Ambient Environment
-55° to 100° C
Ambient Environment
100,000 Feet
90% RH, 65°C
Units may require bake-out after humidity to restore full
performance.
-65° to 125°C, 5 cycles
20g peak, 10-2000 Hz, 12 times in each of three
perpendicular directions (total 36)
Individual Model Data Sheet
Storage Temperature
Individual Model Data Sheet
Barometric Pressure
Humidity
MIL-STD-202, Method 105, Condition D
MIL-STD-202, Method 103
Thermal Shock
Vibration (High Frequency)
MIL-STD-202, Method 107, Condition B
MIL-STD-202, Method 204, Condition D
Mechanical Shock
100g, 6ms sawtooth, 3 shocks each direction 3 axes (total
18)
MIL-STD-202, Method 213, Condition I
ENV28
Rev: B
09/26/13
M143494
File: ENV28.pdf
Page: 1
This document and its contents are the property of Mini-Circuits.
