ADSP-2183BST-160X: DescriptionIC,DSP,16-BIT,CMOS,QFP,128PIN,PLASTIC; CategoryThe embedded processor and controller Microcontrollers and processors; File Size2MB，28 Pages; ManufacturerADI; Websitehttps://www.analog.com

Download Datasheet Parametric Compare View All

ADSP-2183BST-160X Overview

IC,DSP,16-BIT,CMOS,QFP,128PIN,PLASTIC

ADSP-2183BST-160X Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Reach Compliance Code	unknown
bit size	16
Format	FIXED-POINT
JESD-30 code	R-PQFP-G128
JESD-609 code	e0
Number of terminals	128
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	QFP
Encapsulate equivalent code	QFP128,.63X.87,20
Package shape	RECTANGULAR
Package form	FLATPACK
power supply	3.3 V
Certification status	Not Qualified
RAM (number of words)	16384
Nominal supply voltage	3.3 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	GULL WING
Terminal pitch	0.5 mm
Terminal location	QUAD
Base Number Matches	1

Preview

Download Datasheet

View All

ADSP-2183BST-160X Related Products

	ADSP-2183BST-160X	ADSP-2183BST-210X	ADSP-2183KST-210X
Description	IC,DSP,16-BIT,CMOS,QFP,128PIN,PLASTIC	IC MIXED DSP, Digital Signal Processor	IC MIXED DSP, Digital Signal Processor
Is it Rohs certified?	incompatible	incompatible	incompatible
Reach Compliance Code	unknown	not_compliant	unknown
Format	FIXED-POINT	FIXED POINT	FIXED POINT
JESD-30 code	R-PQFP-G128	R-PQFP-G128	R-PQFP-G128
JESD-609 code	e0	e0	e0
Number of terminals	128	128	128
Maximum operating temperature	85 °C	85 °C	70 °C
Minimum operating temperature	-40 °C	-40 °C	-
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	QFP	LFQFP	LFQFP
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	FLATPACK	FLATPACK, LOW PROFILE, FINE PITCH	FLATPACK, LOW PROFILE, FINE PITCH
Nominal supply voltage	3.3 V	3.3 V	3.3 V
surface mount	YES	YES	YES
technology	CMOS	CMOS	CMOS
Temperature level	INDUSTRIAL	INDUSTRIAL	COMMERCIAL
Terminal surface	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)
Terminal form	GULL WING	GULL WING	GULL WING
Terminal pitch	0.5 mm	0.5 mm	0.5 mm
Terminal location	QUAD	QUAD	QUAD
Base Number Matches	1	1	-
Parts packaging code	-	QFP	QFP
package instruction	-	PLASTIC, TQFP-128	PLASTIC, TQFP-128
Contacts	-	128	128
Address bus width	-	14	14
barrel shifter	-	YES	YES
boundary scan	-	NO	NO
maximum clock frequency	-	20 MHz	20 MHz
External data bus width	-	24	24
Internal bus architecture	-	MULTIPLE	MULTIPLE
length	-	20 mm	20 mm
low power mode	-	YES	YES
Maximum seat height	-	1.6 mm	1.6 mm
Maximum supply voltage	-	3.6 V	3.6 V
Minimum supply voltage	-	3 V	3 V
width	-	14 mm	14 mm
uPs/uCs/peripheral integrated circuit type	-	DIGITAL SIGNAL PROCESSOR, MIXED	DIGITAL SIGNAL PROCESSOR, MIXED
