Engineering Development Model
RF Transformer
Impedance Ratio : 16
Important Note
ADT16-ED8075/1
This model has been designed, built and tested in our engineering
department. Performance data represents model capability.
At present it is a non-catalog model. On request, we can supply a
final specification sheet, part number and price/delivery information.
Please click "Back", and then click "Contact Us" for Applications support.
CASE STYLE : CD637
ELECTRICAL SPECIFICATIONS 50Ω @ +25°C
Parameter
Frequency
Insertion Loss *
Min.
0.03
3 dB Bandwidth
2 dB Bandwidth
1 dB Bandwidth
over 3dB Bandwidth
over 1dB Bandwidth
over 3dB Bandwidth
over 1dB Bandwidth
Typ.
0.03 - 75
0.04 - 51
0.063 - 37
0.5
0.1
5.0
1.00
Max.
75
Units
MHz
MHz
MHz
MHz
dB
dB
deg.
deg.
Ampitude Unbalance
Phase Unbalance
Note:
* Insertion Loss is referenced to mid-band loss, 0.22dB typ.
MAXIMUM RATINGS
-20°C to 85°C
Operating Temperature
-55°C to 100°C
Storage Temperature
0.25 W
RF Power
30 mA
DC Current
PIN CONNECTIONS
PRIMARY DOT
PRIMARY
SECONDARY DOT
SECONDARY
SECONDARY CT
ISOLATE
3
1
4
6
5
2
Configuration : A
REV. X1
ADT16-ED8075/1
060808
Page 1 of 1
