ARE063.3K

Description
SLIDE SWITCH,STRAIGHT,6,PC TAIL TERMINAL
CategoryMechanical and electronic products    switch
File Size124KB，1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric Compare View All

ARE063.3K Overview

SLIDE SWITCH,STRAIGHT,6,PC TAIL TERMINAL

ARE063.3K Parametric

Parameter NameAttribute value
Brand NameAlcoswitch
Is it Rohs certified?incompatible
Reach Compliance Codecompliant
Actuator angle
Actuator materialPOLYBUTYLENE TEREPHTHALATE
Actuator typeSLIDE
center contact materialBERYLLIUM COPPER
Center contact platingGOLD
Contact (AC) maximum rated power R load0.4VA@20VAC
Contact resistance0.05 mΩ
Dielectric withstand voltage500VRMS V
Electrical life5000 Cycle(s)
End contact materialBRASS
Shell materialPOLYBUTYLENE TEREPHTHALATE
Insulation resistance1000000000 Ω
insulator materialENCAPSULATED CERAMIC
Manufacturer's serial numberAR
Installation featuresTHROUGH HOLE-STRAIGHT
Number of positions6
Maximum operating temperature85 °C
Minimum operating temperature-30 °C
SolderabilityWAVE
surface mountNO
Switch actionMAINTAINED
Terminal materialBRASS
Termination typeSOLDER
WashabilityWATER/STEAM
Base Number Matches1

Preview

Download Datasheet
My Account
Tyco Electronics
(C hange)
Se a rch by Ke yword or Pa rt #
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
Switches
>
Product Feature Selector
> Product Details
ARE063.3K Product Details
Live Product Chat
DIP, Rotary DIP, SIP Switches and DIP Shunts -
Standard
Not EU R oHS or ELV C om plia nt
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
ARE063.3K
(1437588-5)
T E I nternal N umber: 1 4 3 7 5 8 8 - 5
Product Highlights:
l
DIP Switch
l
PC B Mount Style = Through Hole
l
Single Pole - Single Throw C onfiguration (Pole-Throw)
l
Actuator Style = Extended
l
Not Sealed
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Obsolete
C ontact Product Information C enter
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type = DIP Switch
l
PC B Mount Style = Through Hole
l
C onfiguration (Pole-Throw)
= Single Pole - Single Throw
l
Actuator Style
= Extended
l
Sealed = No
l
Number of Switches
= 6
Electrical Characteristics:
l
Resistor Specification (?) = 3,300
Body Related Features:
l
Series = AR
l
C enterline (mm [in]) = 2.54 [0.100]
Contact Related Features:
l
Auto-Insertable = No
Housing Related Features:
l
Low Profile = Yes
l
Housing Material = Polyester
l
Housing Flammability Rating = UL 94V-0
Industry Standards:
l
RoHS/ELV C ompliance
= Not ELV/RoHS compliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C
Other:
l
Brand = Alcoswitch
Corporate Information
Who We Are
Investors
News Room
Supplier Portal
C areers
Quick Links
C heck Distributor Inventory
C ross Reference
Find Documents & Drawings
Product C ompliance Support C enter
Site Map
Priva cy Policy
Customer Support
Email or C hat with Us
Find a Phone Number
Search Knowledge Base
Manage Your Account
© 2009 Tyco Ele ctronics All R ights R e se rve d
Provide W e bsite Fe e dba ck

ARE063.3K Related Products

ARE063.3K 1437588-5
Description SLIDE SWITCH,STRAIGHT,6,PC TAIL TERMINAL DIP Switch, SLIDE DIP SWITCH-6SWITCHES, SPST, LATCHED,THROUGH HOLE-STRAIGHT
Brand Name Alcoswitch Alcoswitch
Is it Rohs certified? incompatible incompatible
Reach Compliance Code compliant unknown
Manufacturer's serial number AR 1437588
Installation features THROUGH HOLE-STRAIGHT THROUGH HOLE-STRAIGHT
surface mount NO NO
Switch action MAINTAINED LATCHED
Termination type SOLDER SOLDER
Base Number Matches 1 1
