Notes) 1. Regarding ordering units: During production, Please make orders in 1-reel units. Samples for mounting confirmation: Please consult us. Samples: Small lot orders
are possible. Please consult us.
2. The standard type comes without positioning bosses. Connectors with positioning bosses are available for on-demand production.
For this type of connector, 9th digit of the part no. changes from 4 to 3. e.g. 10 contacts for sockets: AXK5L10337G
SPECIFICATIONS
1. Characteristics
Item
Rated current
Rated voltage
Electrical
characteristics
Breakdown voltage
Insulation resistance
Contact resistance
Composite insertion force
Mechanical
characteristics
Composite removal force
Holding force of terminal
securing section
Ambient temperature
Soldering heat resistance
Specifications
0.5A/contact (Max. 10 A at total contacts)
60V AC/DC
150V AC for 1 minute
Min. 1,000MΩ (initial)
Max. 90mΩ
Max. 0.981N {100gf}/contacts
×
contacts (initial)
Min. 0.0588N {6gf}/contacts
×
contacts
Min. 0.981N {100gf}/contact
–55°C to +85°C
Max. peak temperature of 245°C
300°C within 5 seconds
350°C within 3 seconds
5 cycles,
insulation resistance min. 100MΩ,
contact resistance max. 90mΩ
Measures the maximum load in the post axial direction
until removal
No freezing at low temperatures
Infrared reflow soldering
Soldering iron
Sequence
0
1. –55
–3
°C,
30 minutes
2. ~ , Max. 5 minutes
3. 85
+3
°C,
30 minutes
0
4. ~ , Max. 5 minutes
Bath temperature 40±2°C,
humidity 90 to 95% R.H.
Bath temperature 35±2°C,
saltwarter concentration 5±1%
Bath temperature 40±2°C, gas concentration 3±1 ppm,
humidity 75 to 80% R.H.
Repeated insertion and removal speed of
max. 200 times/hours
Detection current: 1mA
Using 500V DC megger
Measured based on the HP4338B measurement method
of JIS C 5402
Conditions
Environmental
characteristics
Thermal shock resistance
(header and socket mated)
Humidity resistance
(header and socket mated)
Saltwater spray resistance
(header and socket mated)
H
2
S resistance
(header and socket mated)
120 hours, insulation resistance min. 100MΩ,
contact resistance max. 90mΩ
24 hours, insulation resistance min. 100MΩ,
contact resistance max. 90mΩ
48 hours, contact resistance max. 90mΩ
50 times
20 contacts; Socket: 0.05g; Header: 0.02g
Lifetime
characteristics
Unit weight
Insertion and removal life
2. Material and surface treatment
Part name
Molded portion
Contact/Post
Material
Heat-resistant resin (UL94V-0), Ivory white
Copper alloy
Surface treatment
—
Contact portion: Ni plating on base, Au plating on surface
Terminal portion: Ni plating on base, Au plating on surface (Except for thick of terminal)
However, the area adjacent to the terminal on Ni barrier models is
