VFVX130-CE-19MHZ: DescriptionCMOS/TTL Output Clock Oscillator, 19MHz Nom, ROHS COMPLIANT, HERMETIC, SMD, 6 PIN; CategoryPassive components oscillator; File Size153KB，3 Pages; ManufacturerCTS [CTS Corporation]; Environmental Compliance

Download Datasheet Parametric Compare View All

VFVX130-CE-19MHZ Overview

CMOS/TTL Output Clock Oscillator, 19MHz Nom, ROHS COMPLIANT, HERMETIC, SMD, 6 PIN

VFVX130-CE-19MHZ Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Reach Compliance Code	unknown
Other features	ENABLE/DISABLE FUNCTION
Maximum control voltage	3.3 V
Minimum control voltage
maximum descent time	3 ns
Frequency Adjustment - Mechanical	NO
Frequency offset/pull rate	35 ppm
frequency stability	20%
linearity	10%
Manufacturer's serial number	VFVX130
Installation features	SURFACE MOUNT
Nominal operating frequency	19 MHz
Maximum operating temperature	60 °C
Minimum operating temperature	-10 °C
Oscillator type	CMOS/TTL
physical size	14.477mm x 9.651mm x 6.73mm
longest rise time	3 ns
Maximum supply voltage	3.45 V
Minimum supply voltage	3.15 V
Nominal supply voltage	3.3 V
surface mount	YES
maximum symmetry	55/45 %
Base Number Matches	1

Preview

Download Datasheet

View All

VFVX130

VCXO Low Jitter

9x14mm SMD, CMOS/TTL

Features

19 MHz to 200 MHz Frequency Range

Ultra Low Jitter and Phase Noise

RoHS Status

Applications

Optical Networking, SONET / SDH

10 Gigabit Ethernet

Broadband Access

Electrical Specifications

Parameter

Frequency

Range

Symbol

F

Vs. Operating Temperature

B:

0°C to +70°C

C: -10°C to +60°C

G: -40°C to +85°C

Vs. Supply Voltage

Vs. Aging / Year

0°

-10°

-40°

Signal

Vcc

Vc

Fm < 10Khz

@25°C

Overall

Monotonic positive

-10

>10KHz

Icc

No Load

50

mA

+10

%

3dB BW

@155MHz

±35

4.75

3.15

0

5.00

3.30

Condition

Min

19

±

10

±

12

±

18

±

3

±

1

Typ

Max

200

±

20

±

20

±

30

Unit

MHz

Note

Frequency

Stability

ppm

ppm/V

ppm

∆F/F

Operating

Temperature

Range

Output

Supply

Voltage

Control

Input

Impedance

K

VCO

APR

Deviation

slope

Linearity

Modulation

BW

Supply

Current

T

+70°

+60°

°C

+85°

CMOS / TTL

5.25

V

3.45

5

V

3.3

First Year

Order Code B

Order Code C

Order Code G

Order Code D

Order Code E

Vcc = 5.0V

Vcc = 3.3V

>50KΩ

35

ppm/V

ppm

Consult factory

for wider APR

75 South Street, Hopkinton, MA 01748 • 800-982-5737 • 508-435-6831 • FAX 508-497-6377 •

www.valpeyfisher.com

• RevC0209

1

VFVX130-CE-19MHZ Related Products

	VFVX130-CE-19MHZ	VFVX130-GE-FREQ	VFVX130-BE-200MHZ	VFVX130-BD-FREQ	VFVX130-GE-19MHZ	VFVX130-BD-19MHZ
Description	CMOS/TTL Output Clock Oscillator, 19MHz Nom, ROHS COMPLIANT, HERMETIC, SMD, 6 PIN	CMOS/TTL Output Clock Oscillator, 19MHz Min, 200MHz Max, ROHS COMPLIANT, HERMETIC, SMD, 6 PIN	CMOS/TTL Output Clock Oscillator, 200MHz Nom, ROHS COMPLIANT, HERMETIC, SMD, 6 PIN	CMOS/TTL Output Clock Oscillator, 19MHz Min, 200MHz Max, ROHS COMPLIANT, HERMETIC, SMD, 6 PIN	CMOS/TTL Output Clock Oscillator, 19MHz Nom, ROHS COMPLIANT, HERMETIC, SMD, 6 PIN	CMOS/TTL Output Clock Oscillator, 19MHz Nom, ROHS COMPLIANT, HERMETIC, SMD, 6 PIN
Is it lead-free?	Lead free	Lead free	Lead free	Lead free	Lead free	Lead free
Is it Rohs certified?	conform to	conform to	conform to	conform to	conform to	conform to
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknow
Other features	ENABLE/DISABLE FUNCTION	ENABLE/DISABLE FUNCTION	ENABLE/DISABLE FUNCTION	ENABLE/DISABLE FUNCTION	ENABLE/DISABLE FUNCTION	ENABLE/DISABLE FUNCTION
Maximum control voltage	3.3 V	3.3 V	3.3 V	5 V	3.3 V	5 V
maximum descent time	3 ns	3 ns	3 ns	3 ns	3 ns	3 ns
Frequency Adjustment - Mechanical	NO	NO	NO	NO	NO	NO
Frequency offset/pull rate	35 ppm	35 ppm	35 ppm	35 ppm	35 ppm	35 ppm
frequency stability	20%	30%	20%	20%	30%	20%
linearity	10%	10%	10%	10%	10%	10%
Manufacturer's serial number	VFVX130	VFVX130	VFVX130	VFVX130	VFVX130	VFVX130
Installation features	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT
Maximum operating temperature	60 °C	85 °C	70 °C	70 °C	85 °C	70 °C
Oscillator type	CMOS/TTL	CMOS/TTL	CMOS/TTL	CMOS/TTL	CMOS/TTL	CMOS/TTL
physical size	14.477mm x 9.651mm x 6.73mm	14.477mm x 9.651mm x 6.73mm	14.477mm x 9.651mm x 6.73mm	14.477mm x 9.651mm x 6.73mm	14.477mm x 9.651mm x 6.73mm	14.477mm x 9.651mm x 6.73mm
longest rise time	3 ns	3 ns	3 ns	3 ns	3 ns	3 ns
Maximum supply voltage	3.45 V	3.45 V	3.45 V	5.25 V	3.45 V	5.25 V
Minimum supply voltage	3.15 V	3.15 V	3.15 V	4.75 V	3.15 V	4.75 V
Nominal supply voltage	3.3 V	3.3 V	3.3 V	5 V	3.3 V	5 V
surface mount	YES	YES	YES	YES	YES	YES
maximum symmetry	55/45 %	55/45 %	55/45 %	55/45 %	55/45 %	55/45 %
Nominal operating frequency	19 MHz	-	200 MHz	-	19 MHz	19 MHz
Maker	-	-	CTS [CTS Corporation]	CTS [CTS Corporation]	CTS [CTS Corporation]	CTS [CTS Corporation]
