TC4421VSM datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> Drivers and interfaces> TC4421VSM

TC4421VSM: Description9 A BUF OR INV BASED MOSFET DRIVER, PDSO8, 0.208 INCH, PLASTIC, SO-8; CategoryAnalog mixed-signal IC Drivers and interfaces; File Size263KB，18 Pages; ManufacturerMicrochip; Websitehttps://www.microchip.com; Environmental Compliance

Download Datasheet Parametric View All

TC4421VSM Overview

9 A BUF OR INV BASED MOSFET DRIVER, PDSO8, 0.208 INCH, PLASTIC, SO-8

TC4421VSM Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Parts packaging code	SOIC
package instruction	SOP, SOP8,.3
Contacts	8
Reach Compliance Code	compliant
ECCN code	EAR99
high side driver	YES
Interface integrated circuit type	BUFFER OR INVERTER BASED MOSFET DRIVER
JESD-30 code	R-PDSO-G8
JESD-609 code	e3
length	5.28 mm
Number of functions	1
Number of terminals	8
Maximum operating temperature	125 °C
Minimum operating temperature	-40 °C
Nominal output peak current	9 A
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Encapsulate equivalent code	SOP8,.3
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
power supply	4.5/18 V
Certification status	Not Qualified
Maximum seat height	2.03 mm
Maximum supply voltage	18 V
Minimum supply voltage	4.5 V
surface mount	YES
technology	CMOS
Temperature level	AUTOMOTIVE
Terminal surface	Matte Tin (Sn)
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	40
Disconnect time	0.08 µs
connection time	0.08 µs
width	5.21 mm
Base Number Matches	1

Preview

Download Datasheet

View All

TC4421/TC4422

9A High-Speed MOSFET Drivers

Features

• High Peak Output Current: 9A

• Wide Input Supply Voltage Operating Range:

- 4.5V to 18V

• High Continuous Output Current: 2A Max

• Fast Rise and Fall Times:

- 30 ns with 4,700 pF Load

- 180 ns with 47,000 pF Load

• Short Propagation Delays: 30 ns (typ)

• Low Supply Current:

- With Logic ‘1’ Input – 200 µA (typ)

- With Logic ‘0’ Input – 55 µA (typ)

• Low Output Impedance: 1.4Ω (typ)

• Latch-Up Protected: Will Withstand 1.5A Output

Reverse Current

• Input Will Withstand Negative Inputs Up To 5V

• Pin-Compatible with the TC4420/TC4429

6A MOSFET Driver

• Space-saving 8-Pin 6x5 DFN Package

General Description

The TC4421/TC4422 are high-current buffer/drivers

capable of driving large MOSFETs and IGBTs.

These devices are essentially immune to any form of

upset, except direct overvoltage or over-dissipation.

They cannot be latched under any conditions within

their power and voltage ratings. These parts are not

subject to damage or improper operation when up to

5V of ground bounce is present on their ground termi-

nals. They can accept, without damage or logic upset,

more than 1A inductive current of either polarity being

forced back into their outputs. In addition, all terminals

are fully protected against up to 4 kV of electrostatic

discharge.

The TC4421/TC4422 inputs may be driven directly

from either TTL or CMOS (3V to 18V). In addition,

300 mV of hysteresis is built into the input, providing

noise immunity and allowing the device to be driven

from slowly rising or falling waveforms.

With both surface-mount and pin-through-hole

packages and four operating temperature range offer-

ings, the TC4421/22 family of 9A MOSFET drivers fit

into most any application where high gate/line

capacitance drive is required.

Applications

•

Line Drivers for Extra Heavily-Loaded Lines

Pulse Generators

Driving the Largest MOSFETs and IGBTs

Local Power ON/OFF Switch

Motor and Solenoid Driver

Package Types

(1)

8-Pin PDIP/ TC4421 TC4422

SOIC

INPUT

GND

8 V

TC4421

7 OUTPUT

TC4422

6 OUTPUT

5 GND

OUTPUT

GND

INPUT

GND

8-Pin DFN

(2)

TC4421 TC4422

5-Pin TO-220

Tab is

Common

to V

TC4421

TC4422

OUTPUT OUTPUT

GND

TC4421

TC4422

Note 1:

Duplicate pins must both be connected for proper operation.

Exposed pad of the DFN package is electrically isolated.



2004 Microchip Technology Inc.

INPUT

GND

OUTPUT

DS21420D-page 1
