Crystal oscillator
Epson Toyocom
Product Number (please contact us)
VOLTAGE -CONTROLLED CRYSTAL OSCILLATOR (VCXO)
Q3603CA0xxxxx00
VG - 1201CA
•Frequency
range
•Supply
voltage
•Function
•External
dimensions
:
:
:
:
1 MHz to 60 MHz
3.3 V(**C) or 5.0 V(**H)
Output enable(OE)
7.0 × 5.0 × 1.4 t (mm) Typ.
Actual size
Specifications (characteristics)
Item
Output frequency range
Supply voltage
Storage temperature
Temperature
range
Operating temperature
Frequency tolerance
Current consumption
Disable current
Frequency control range
Modulation characteristics
Input resistance
Frequency change polarity
Symmetry
High output voltage
Low output voltage
Output load condition(CMOS)
Output enable /
disable input voltage
Rise time and Fall time
Start-up time
Frequency aging
Symbol
f
0
V
CC
T_stg
T_use
f_tol
I
CC
I_dis
f_cont
BW
R
in
-
*1
50 MHz < f
0
≤
60 MHz :
±15 ×
10
-6
Max.
*
Please keep V
C
pin open or ground while powering up V
CC
.
.
SYM
V
OH
V
OL
L_CMOS
V
IH
V
IL
t
r
/
t
f
t_str
f_aging
Specifications
ANH
/
AKH
/
BNH
/
BKH
ANC
/
AKC
/
BNC
/
BKC
1.000 MHz to 60.000 MHz
H:5.0 V
±0.5
V
C:3.3 V
±0.3
V
-40
°C
to +125
°C
As per below table
As per below table
30 mA Max.
25 mA Max.
15 mA Max.
12 mA Max.
As per below table
20 kHz Min.
5 MΩ Min.
Positive polarity
40 % to 60 %
V
CC
-0.4 V Min.
0.4 V Max.
15 pF Max.
70 %V
CC
Min.
30 % V
CC
Max.
4 ns Max.
10 ms Max.
*1
±10 ×
10
-6
Max.
Remarks
Store as bare product after unpacking
No load condition
OE=GND
V
C
=2.5 V
±2.0
V(**H ) , 1.65 V
±1.50
V(**C )
±
3 dB (at 1 kHz)
DC level
V
C
=0.5 V to 4.5 V(**H ),0.15 V to 3.15 V(**C )
CMOS load:50 % V
CC
level
I
OH
= -4 mA
I
OL
= 4 mA
CMOS load
OE Terminal
CMOS load: 20 % V
CC
to 80 % V
CC
level
Time at 90 % V
CC
to be 0 s
+25
°C,
10 years
Frequency tolerance / Temperature range
A
B
Frequency tolerance
±20 ×
10
-6
±25 ×
10
-6
Temperature range
-20
°C
to +70
°C
-40
°C
to +85
°C
Frequency control range
K
N
Frequency control range
±75 ×
10
-6
Min.
±100 ×
10
-6
Min.
Output frequency range
41 MHz <
f
0
≤
60 MHz
1 MHz
≤
f
0
≤41
MHz
External dimensions
1.4
(Unit:mm)
Footprint (Recommended)
(Unit:mm)
#6
#5
#4
#4
#5
#6
1.1
±0.2
E 35.328 T
ANC181A
#1
#2
±0.2
7.0
#3
1.8
2.6
5.0
C(ex. 0.01 µF) #6
#5
#4
#3
2.54
#2
5.08
#1
C
±0.1
1.4
Pin map
Pin
1
2
3
4
5
6
Connection
F Type
T Type
V
C
N.C.
OE
GND
OUT
OE
N.C.
V
CC
Resist
#1
#2
5.08
#3
5.08
Note.
OE Pin
OE pin = "H" or "open" : Specified frequency output.
OE pin = "L" : Output is high impedance.
To maintain stable operation, provide by-pass capacitor with
more than 0.1
µF
at a location as near as possible to the power
source terminal of the crystal products (between V
CC
- GND).
