EMI/RFI
Environmental
Backshells
AS85049/8 and MS3188A
EMI/RFI Environmental Backshell
Glenair Connector
Designator A
M85049/8-21 W
A Thread
(Table I,
Page 39-12)
H
Basic Part No.
Dash No.
Finish
B = Black Cadmium, Stainless Steel
N = Electroless Nickel, Aluminum
S = Passivated Stainless Steel
W = 1,000 Hour Cad. Olive Drab Over
Electroless Nickel, Aluminum
MIL-DTL-5015 Series 3400,
MIL-DTL-26482 Series 2,
AS81703 Series 3,
MIL-DTL-83723 Series I &
III, 40M39569, DEF 5326-3,
C (Table I,
Page 39-12)
EN 2997, EN 3646,
ESC 10, ESC 11, LN 29504,
NFC93422 Series HE302,
PAN 6432-1, PAN 6432-2,
PATT 602
Superceded Part Number
J
MS3188A 21 C
Basic Part No.
Dash No.
Finish (Material is Aluminum Only)
A = Cadmium Olive Drab over Nickel
C = Cadmium Olive Drab
N = Electroless Nickel
1. For complete dimensions see applicable Military
Specification.
2. Metric dimensions (mm) are indicated in
parentheses.
3. When maximum cable entry is exceeded, Style 2
will be supplied.
4. Cable range is defined as the accommodations
range for the wire bundle or cable. Dimensions
shown are not intended for inspection criteria.
K
STYLE 2
Cable
Range
L
TABLE II
Dash
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
Shell
Size
3
3
8
10
10
12
12
12
14
14
16
16
18
18
20
20
22
22
24
24
28
H
Max
.761
(19.3)
1.511
(38.4)
.666
(16.9)
.761
(19.3)
.761
(19.3)
.766
(19.5)
.766
(19.5)
.766
(19.5)
.866
(22.0)
.866
(22.0)
1.051
(26.7)
1.051
(26.7)
1.141
(29.0)
(29.0)
1.141
1.141
(29.0)
1.141
(29.0)
1.291
(32.8)
1.291
(32.8)
1.291
(32.8)
1.291
(32.8)
1.391
(35.3)
J
Max
1.862
(47.3)
1.382
(35.1)
1.262
(32.1)
1.982
(50.3)
1.382
(35.1)
2.002
(50.9)
2.002
(50.9)
1.397
(35.5)
2.072
(52.6)
1.717
(43.6)
2.162
(54.9)
1.807
(45.9)
2.332
(59.2)
1.982
(50.3)
2.332
(59.2)
1.982
(50.3)
2.442
(62.0)
2.087
(53.0)
2.442
(62.0)
2.087
(53.0)
2.612
(66.3)
K
Ref.
1.544
(39.2)
1.544
(39.2)
1.544
(39.2)
1.544
(39.2)
1.544
(39.2)
1.544
(39.2)
1.544
(39.2)
1.844
(46.8)
1.544
(39.2)
1.844
(46.8)
1.544
(39.2)
1.916
(48.7)
1.844
(46.8)
2.000
(50.8)
1.844
(46.8)
2.000
(50.8)
(48.7)
1.916
2.230
(56.6)
1.916
(48.7)
(56.6)
2.230
2.000
(50.8)
L
Max
.957
(24.3)
1.145
(29.1)
.957
(24.3)
.957
(24.3)
1.145
(29.1)
.957
(24.3)
1.145
(29.1)
1.332
(33.8)
1.145
(29.1)
1.332
(33.8)
1.145
(29.1)
1.551
(39.4)
1.332
(33.8)
1.770
(45.0)
1.332
(33.8)
1.770
(45.0)
1.551
(39.4)
2.113
(53.7)
1.551
(39.4)
2.113
(53.7)
1.770
(45.0)
Cable Range
Min
Max
.125
(3.2) .250
(6.4)
.250
(6.4) .437
(11.1)
.125
(3.2) .250
(6.4)
.125
(3.2) .312
(7.9)
.250
(6.4) .375
(9.5)
.125
(3.2) .312
(7.9)
.250
(6.4) .437
(11.1)
.350
(8.9) .500
(12.7)
.250
(6.4) .437
(11.1)
.350
(8.9) .575
(14.6)
.250
(6.4) .437
(11.1)
.500
(12.7) .700
(17.8)
.350
(8.9) .625
(15.9)
.625
(15.9) .779
(19.8)
.350
(8.9) .625
(15.9)
.625
(15.9) .904
(23.0)
.500
(12.7) .750
(19.1)
(22.2) 1.029
.875
(26.1)
.500
(12.7) .750
(19.1)
.875
(22.2) 1.144
(29.1)
.625
(15.9) .937
(23.8)
M85049/42
Ref
4
6
4
4
6
4
6
10
6
10
6
12
10
16
10
16
12
20
12
20
16
Table II Continued on Page 39-11
