TEN8 Series
Nominal
Input Voltage
8 Watts Wide Input
Output
Voltage
3.3 VDC
5.0 VDC
12.0 VDC
15.0 VDC
±5.0 VDC
±12.0 VDC
±15.0 VDC
Output
Current
2000 mA
1500 mA
665 mA
535 mA
±800 mA
±335 mA
±265 mA
Efficiency
80%
82%
85%
83%
83%
84%
84%
Model
Number
TEN 8-XX10
TEN 8-XX11
TEN 8-XX12
TEN 8-XX13
TEN 8-XX21
TEN 8-XX22
TEN 8-XX23
9-18 VDC
18-36 VDC
36-75 VDC
NOTE: For 9-18 VDC input voltage, replace xx in model number with 12.
For 18-36 VDC input voltage, replace xx in model number with 24.
For 36-75 VDC input voltage, replace xx in model number with 48.
Input
●
No Load Input Current
●
Conducted Noise
12 V models 20 mA typ
24 V models 15 mA typ
48 V models 10 mA typ
EN55022A level A, FCC Part 15 Level A
±2.0%
±0.2% max Vin min to Vin max
±0.2% max single output
±1.0% max dual output balanced load
±3.0% max dual output unbalanced load
±0.02%/°C
>110% of Iout max, foldback
Indefinite (auto recovery)
50 mV pk-pk typ
-40 °C to +71 °C
1500 VDC input to output
300 kHz typ
ON = pin 1 to pins 2/3 open
OFF = pin 1 to pins 2/3 short
+250 °C/10 sec max
5-sided metal case (insulated baseplate)
Pin
1
2
3
9
11
14
16
22
23
Single
ROF
-Vin (GND)
-Vin (GND)
N/C
N/C
+Vout
-Vout
+Vin (Vcc)
+Vin (Vcc)
Dual
ROF
-Vin (GND)
-Vin (GND)
Common
-Vout
+Vout
Common
+Vin (Vcc)
+Vin (Vcc)
Output
●
Voltage Accuracy
●
Line Regulation
●
Load Regulation (25-100%)
●
Temperature Coefficient
●
Current Limitation
●
Short Circuit Protection
●
Ripple and Noise
(20 MHz bandwidth)
General
●
Operating Temperature
●
Isolation
●
Switching Frequency
●
Remote ON/OFF
●
Soldering Temperature
●
Case Material
