7.0 mm x 5.0 mm VCXO
Description:
The V85G Voltage-controlled
Crystal Oscillator (VCXO) Series
products provide a wide range of
options in temperature stability,
operating frequency range, and ultra
low phase jitter in a 7.0 x 5.0 mm
ceramic package with PECL or
LVDS outputs..
•
•
•
•
•
•
V85G series
Features:
Available in frequencies from 1.5
to 200 MHz
Tri-state Enable/Disable
Hermetically sealed ceramic SMD
package
PECL / LVDS outputs
RoHS-6/Leadfree compliant
Integrated jitter 0.3 pS max.
Frequency Range
Frequency
Operating Temperature
Frequency Stability
Product Code
Product Code
Operating Temperature
Freq. Stability
A
A
-10 to +60C
+/- 25 ppm
B
B
1.5 to 200.5 MHz
0 to +70C
+/- 50 ppm
C
-20 to 70C
D
-40 to 85C
Frequency stability is inclusive of calibration at 25C, operating temp. range, input voltage variation, load variation,
aging, shock, and vibration
Not all combinations of stability and temperature ranges available.
Aging:
(typical at 20MHz after 30 days continuous operation)
Frequency
20 MHz
Timeframe
1st Year
Aging
+/- 5.0ppm
Product Code
N/A
Supply Voltage (Vs):
Power Supply (Vs)
Product Code
2.5 Vdc +/-10%
A
3.3 Vdc +/-10%
B
Frequency versus Voltage:
3.3 volt
5.0 volt
0 to 3.3v
Product Code
0.5v to 4.5v
Product Code
on Pin 1
on Pin1
+/-100 ppm min
N/A
+/-100 ppm min
N/A
Current Consumption ( I
DD
):
I
DD
( at 2.5V )
Frequency Range ( MHz )
1.500 to 64.999
65.000 to 200.000
www.bliley.com
I
DD
( at 3.3V )
PECL / LVDS
mA
75 / 45
100 / 80
Tel
(814) 838-3571
Rev 1.2 A
PECL / LVDS
mA
75 / 45
100 / 80
2545 West Grandview Blvd Erie, PA. 16506
Page 1 of 4
7.0 mm x 5.0 mm VCXO
Environmental:
Storage Temperature
-55 to +125
°C
V85G series
Output Waveform:
LVDS
Product Code
A
B
At 2.5 V
At 3.3 V
At 2.5 V At 3.3 V
Output Logic 1
1.475 Vmin 2.275Vmin 1.6Vmax 1.6Vmax
Output Logic 0
1.095 Vmax 1.680Vmax 0.9Vmin 0.9Vmin
Rise/Fall Time ( nS ) 1 max
1 max
1 max
1 max
PECL
PECL
LVDS
Tri-state function Pin 2:
Pin 2 = Ouput Active with 0.5 volts max on Pin 2
Pin2 = Output in high impedance state when 2.0 volts min. on Pin 2 or 2.5 volts min ( for 3.3v supply )
Ordering Options:
Product Family
Operating
Temperature
V85G
A
V85G
B
V85G
C
V85G
D
Temperature
Stability
A
B
Supply
Voltage
A
B
Output
Type
A
B
Operating
Frequency
XXX.XXXMHz
XXX.XXXMHz
XXX.XXXMHz
XXX.XXXMHz
V85G A B B A
Part Number Build Example
**Consult Bliley sales if other options required
155.520MHz
RoHs compliant ; -20 to 70C; +/- 50ppm; a 3.3 volt supply;PECL outputs and 155.520 MHz nominal
operating frequency.
How to Order This Product:
Contact Bliley Technologies with Product Selection Code from Ordering Options Section above.
www.bliley.com
2545 West Grandview Blvd Erie, PA. 16506
Page 2 of 4
Tel
(814) 838-3571
Rev 1.2 A
