Fla t c a b l e Co nn ec tor
Flatcable connectors
Dip connector – 4 to 40 positions
Description
Insulation displacement termination (IDC)
Contact spacing 2.54 mm
Contact plating: gold or tin plated
RoHS compliant
Product drawing
PCB-hole pattern
pre-pressed
pressed
No. of Pos.
4
6
8
10
12
14
16
18
20
22
24
28
32
36
40
A
± 0.1
2.54
2x 2.54 = 5.08
3 x 2.54 = 7.62
4 x 2.54 = 10.16
5 x 2.54 = 12.70
6 x 2.54 = 15.24
7 x 2.54 = 17.78
8 x 2.54 = 20.32
9 x 2.54 = 22.86
10 x 2.54 = 25.40
11 x 2.54 = 27.94
13 x 2.54 = 33.02
15 x 2.54 = 38.10
17 x 2.54 = 43.18
19 x 2.54 = 48.26
B
± 0.2
8.41
10.95
13.49
16.03
18.57
21.11
23.56
26.19
28.73
31.35
33.60
38.97
44.05
49.13
53.90
C
± 0.1
7.62
7.62
7.62
7.62
7.62
7.62
7.62
7.62
7.62
10.16
15.24
15.24
15.24
15.24
15.24
D
− 0.1
10.7
10.7
10.7
10.7
10.7
10.7
10.7
10.7
10.7
13.2
18.3
18.3
18.3
18.3
18.3
(Dim. = mm)
Order data
No. of Pos.
4
6
8
10
12
14
16
18
gold plated
220 A 10019 X
220 A 10029 X
220 A 10039 X
220 A 10049 X
220 A 10059 X
220 A 10069 X
220 A 10079 X
220 A 10089 X
tin plated
220 F 10019 X
220 F 10029 X
220 F 10039 X
220 F 10049 X
220 F 10059 X
220 F 10069 X
220 F 10079 X
220 F 10089 X
No. of Pos.
20
22
24
28
32
36
40
gold plated
220 A 10099 X
220 A 10109 X
220 A 10119 X
220 A 10129 X
220 A 10139 X
220 A 10149 X
220 A 10159 X
tin plated
220 F 10099 X
220 F 10109 X
220 F 10119 X
220 F 10129 X
220 F 10139 X
220 F 10149 X
220 F 10159 X
