Z8401306VSCXXXX datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> Z8401306VSCXXXX

PDF

Z8401306VSCXXXX: DescriptionMicrocontroller, 8-Bit, 6MHz, CMOS, PQCC84, PLASTIC, LCC-84; CategoryThe embedded processor and controller Microcontrollers and processors; File Size41KB，1 Pages; ManufacturerZilog, Inc.; Websitehttps://www.zilog.com/

Download Datasheet Parametric Compare View All

Z8401306VSCXXXX Overview

Microcontroller, 8-Bit, 6MHz, CMOS, PQCC84, PLASTIC, LCC-84

Z8401306VSCXXXX Parametric

Parameter Name	Attribute value
Parts packaging code	LCC
package instruction	QCCJ,
Contacts	84
Reach Compliance Code	unknown
Has ADC	NO
bit size	8
maximum clock frequency	6 MHz
DAC channel	NO
DMA channel	NO
JESD-30 code	S-PQCC-J84
length	29.3116 mm
Number of terminals	84
Maximum operating temperature	70 °C
Minimum operating temperature
Package body material	PLASTIC/EPOXY
encapsulated code	QCCJ
Package shape	SQUARE
Package form	CHIP CARRIER
Certification status	Not Qualified
Maximum seat height	4.57 mm
speed	6 MHz
surface mount	YES
technology	CMOS
Temperature level	COMMERCIAL
Terminal form	J BEND
Terminal pitch	1.27 mm
Terminal location	QUAD
width	29.3116 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER
Base Number Matches	1

Preview

Download Datasheet

Z8401306VSCXXXX Related Products

	Z8401306VSCXXXX	Z8401506FSCXXXX	Z84C1516ASCXXXX	Z84C1516FSCXXXX	Z84C0110VSC	Z8401310VSCXXXX	Z84C0110FSCXXXX	Z84C0110FSC	Z84C0110VSCXXXX
Description	Microcontroller, 8-Bit, 6MHz, CMOS, PQCC84, PLASTIC, LCC-84	Microcontroller, 8-Bit, 6MHz, CMOS, PQFP100, PLASTIC, QFP-100	Microcontroller, 8-Bit, 16MHz, CMOS, PQFP100, PLASTIC, VQFP-100	Microcontroller, 8-Bit, 16MHz, CMOS, PQFP100, PLASTIC, QFP-100	Microprocessor, 8-Bit, 10MHz, CMOS, PQCC44, PLASTIC, LCC-44	Microcontroller, 8-Bit, 10MHz, CMOS, PQCC84, PLASTIC, LCC-84	Microprocessor, 8-Bit, 10MHz, CMOS, PQFP44, PLASTIC, QFP-44	Microprocessor, 8-Bit, 10MHz, CMOS, PQFP44, PLASTIC, QFP-44	Microprocessor, 8-Bit, 10MHz, CMOS, PQCC44, PLASTIC, LCC-44
Parts packaging code	LCC	QFP	QFP	QFP	LCC	LCC	QFP	QFP	LCC
package instruction	QCCJ,	QFP,	LFQFP,	QFP,	QCCJ,	QCCJ,	QFP,	QFP,	QCCJ,
Contacts	84	100	100	100	44	84	44	44	44
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown
bit size	8	8	8	8	8	8	8	8	8
maximum clock frequency	6 MHz	6 MHz	16 MHz	16 MHz	10 MHz	10 MHz	10 MHz	10 MHz	10 MHz
JESD-30 code	S-PQCC-J84	R-PQFP-G100	S-PQFP-G100	R-PQFP-G100	S-PQCC-J44	S-PQCC-J84	S-PQFP-G44	S-PQFP-G44	S-PQCC-J44
length	29.3116 mm	20 mm	14 mm	20 mm	16.5862 mm	29.3116 mm	10 mm	10 mm	16.5862 mm
Number of terminals	84	100	100	100	44	84	44	44	44
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	QCCJ	QFP	LFQFP	QFP	QCCJ	QCCJ	QFP	QFP	QCCJ
Package shape	SQUARE	RECTANGULAR	SQUARE	RECTANGULAR	SQUARE	SQUARE	SQUARE	SQUARE	SQUARE
Package form	CHIP CARRIER	FLATPACK	FLATPACK, LOW PROFILE, FINE PITCH	FLATPACK	CHIP CARRIER	CHIP CARRIER	FLATPACK	FLATPACK	CHIP CARRIER
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum seat height	4.57 mm	3.1 mm	1.6 mm	3.1 mm	4.57 mm	4.57 mm	2.5 mm	2.5 mm	4.57 mm
speed	6 MHz	6 MHz	16 MHz	16 MHz	10 MHz	10 MHz	10 MHz	10 MHz	10 MHz
surface mount	YES	YES	YES	YES	YES	YES	YES	YES	YES
technology	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS
Terminal form	J BEND	GULL WING	GULL WING	GULL WING	J BEND	J BEND	GULL WING	GULL WING	J BEND
Terminal pitch	1.27 mm	0.65 mm	0.5 mm	0.65 mm	1.27 mm	1.27 mm	0.8 mm	0.8 mm	1.27 mm
Terminal location	QUAD	QUAD	QUAD	QUAD	QUAD	QUAD	QUAD	QUAD	QUAD
width	29.3116 mm	14 mm	14 mm	14 mm	16.5862 mm	29.3116 mm	10 mm	10 mm	16.5862 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROPROCESSOR	MICROCONTROLLER	MICROPROCESSOR	MICROPROCESSOR	MICROPROCESSOR
Has ADC	NO	NO	NO	NO	-	NO	-	-	-
DAC channel	NO	NO	NO	NO	-	NO	-	-	-
DMA channel	NO	NO	NO	NO	-	NO	-	-	-
Maximum operating temperature	70 °C	70 °C	70 °C	70 °C	70 °C	70 °C	-	70 °C	-
Temperature level	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	-	COMMERCIAL	-
Base Number Matches	1	1	1	1	1	1	-	-	-
Maker	-	Zilog, Inc.	Zilog, Inc.	Zilog, Inc.	Zilog, Inc.	-	Zilog, Inc.	Zilog, Inc.	Zilog, Inc.
