Part numbering system hermetic
DBC
DBC
Shell type
50 : Square flange mount receptacle
53 : Solder mount receptable
54 : Single hole mount receptable
Insert clocking position
Normal : N
Hermetic version
Insert arrangement
(see page 8)
Manufacturer Deutsch
9
DBC
50
H
22
55
P
N
Connector type
To MIL-C 26482 G serie 2
Shell size
08 - 10 - 12 - 14 - 16 - 18 - 20 - 22 - 24
Contact type
Male contact : P
Female contact (consult us) : S
31
Technical characteristics
I
Mechanical
Shell
Plating
:
:
:
:
:
:
:
:
:
:
DBC
Steel
Tin over nickel plating
Compression glass ; silicone gasket
The glass can withstand 70 bars of presure differential
without loss of mechanical on electrical characteristics
Solder type
Gold as per MIL-G 45204
500 full coupling and uncoupling cycles
– 55° C to + 200° C
Leakage inferior to
≤
1 x 10– 7 cm3 / hour under a 1 bar
differential pressure
50 G in the 3 axes
Materials
Insert
Insert retention in shell
Contacts
Durability
Temperature
Air leakage
Physical Shocks
Type
Finish
I
Electrical
at sea level
in altitude at 15000 m
in altitude at 21000 m
in altitude at 33000 m
: Service 1 : 1500 V 50 Hz (R.M.S)
Service 2 : 2300 V 50 Hz (R.M.S)
: Service 1 : 500 V
Service 2 : 750 V
: Service 1 : 375 V
Service 2 : 500 V
: Service 1 : 200 V
Service 2 : 200 V
: Higher than 5000 MΩ at 20° C at 65 % R.H
: Size 20 : 5 A.
Size 16 : 10 A.
Size 12 : 17 A.
: Size 20 : 75 mv at 5 A.
Size 16 : 100 mv at 10 A.
Size 12 : 100 mv at 17 A.
Withstanding voltage
Insulation resistance
Contacts maximum current
Contact millivolt drop
32
