RoHS
Compliant
4:1 Flux Coupled Transformer
1-350MHz
Features
•
•
•
•
•
•
•
Surface Mount
4:1 Impedance
Excellent amplitude and phase balance
Can be used in both 50Ω and 75Ω systems
260°C Reflow Compatible
RoHS* Compliant
Available on Tape and Reel. Reel quantity 2000
MABACT0067
V1P
Schematic
Description
M/ACom’s MABACT0067 is a 4:1 RF flux coupled
step up transformer in a low cost, surface mount
package. Ideally suited for high volume CATV/
Broadband applications.
Case Style: SM-164
Pin Configuration
Pin No.
1
2
3
4
5
Function
Secondary Dot (output 1)
Centre Tap (ground)
Secondary (output 2)
Primary Dot (Input)
Primary (Ground)
Dimensions in inches [mm] Tolerance: .xx ± .02, .xxx ± .010
Ordering Information
Part Number
MABACT0067TR
Package
2000 piece reel
Note: Reference Application Note
M513
for reel size information.
* Restrictions on Hazardous Substances, European Union Directive 2002/95/EC.
1
ADVANCED:
Data Sheets contain information regarding a product M/A-COM Technology Solutions
•
North America
Tel: 800.366.2266 •
Europe
Tel: +353.21.244.6400
is considering for development. Performance is based on target specifications, simulated results,
•
India
Tel: +91.80.4155721
•
China
Tel: +86.21.2407.1588
and/or prototype measurements. Commitment to develop is not guaranteed.
Visit www.macomtech.com for additional data sheets and product information.
PRELIMINARY:
Data Sheets contain information regarding a product M/A-COM Technology
Solutions has under development. Performance is based on engineering tests. Specifications are
typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available.
M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make
Commitment to produce in volume is not guaranteed.
changes to the product(s) or information contained herein without notice.
RoHS
Compliant
4:1 Flux Coupled Transformer
1-350MHz
Electrical Specifications: T
A
= 25°C, Z
0
= 50Ω
Parameter
Insertion Loss 1 (pin 4-1)
MABACT0067
V1P
Test Conditions
1 - 5 MHz
5 - 200 MHz
200 - 350 MHz
1 - 5 MHz
5 - 150 MHz
150 - 350 MHz
1 - 250 MHz
250 - 350 MHz
1 - 150 MHz
150 - 350 MHz
1 - 5 MHz
5 - 200 MHz
200 - 350 MHz
Units
dB
Min
-
-
-
-
-
-
-
-
-
-
10
15
11
Typ
1.6
0.9
1.0
1.5
0.9
1.1
±0.1
±0.2
±1.0
±2.0
12
19
14
Max
2.0
1.0
1.5
2.0
1.0
1.5
±0.2
±0.3
±2.0
±5.0
-
-
-
Insertion Loss 2 (pin 4-3)
dB
Amplitude Unbalance (Nominal 0dB)
Phase Unbalance (Nominal 180º)
Input Return Loss
dB
º
dB
Absolute Maximum Ratings
1,2
Parameter
Max Input Power
DC current
Operating Temperature
Storage Temperature
Recommended PCB Configuration
Absolute Maximum
250mW
240mA
-40°C to +85°C
-55°C to +100°C
1. Exceeding any one or combination of these limits may cause
permanent damage to this device.
2. M/A-COM does not recommend sustained operation near
these survivability limits.
2
ADVANCED:
Data Sheets contain information regarding a product M/A-COM Technology Solutions
•
North America
Tel: 800.366.2266 •
Europe
Tel: +353.21.244.6400
is considering for development. Performance is based on target specifications, simulated results,
•
India
Tel: +91.80.4155721
•
China
Tel: +86.21.2407.1588
and/or prototype measurements. Commitment to develop is not guaranteed.
Visit www.macomtech.com for additional data sheets and product information.
PRELIMINARY:
Data Sheets contain information regarding a product M/A-COM Technology
Solutions has under development. Performance is based on engineering tests. Specifications are
typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available.
M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make
Commitment to produce in volume is not guaranteed.
changes to the product(s) or information contained herein without notice.
RoHS
Compliant
4:1 Flux Coupled Transformer
1-350MHz
Typical Performance Curves: T
A
= 25°C, Z
0
= 50Ω
Insertion Loss 1 (pin 4 to pin 1)
0.0
-0.2
-0.4
-0.6
-0.8
MABACT0067
V1P
Insertion Loss 2 (pin 4 to pin 3)
0.0
-0.2
-0.4
-0.6
-0.8
dB
-1.0
-1.2
-1.4
-1.6
-1.8
-2.0
1
51
101
151
200
250
300
350
dB
-1.0
-1.2
-1.4
-1.6
-1.8
-2.0
1
51
101
151
200
250
300
350
F re que nc y ( M H z)
F re que nc y (M H z)
Amplitude Unbalance
1.0
0.8
0.6
0.4
0.2
Phase Balance
185
184
183
182
degree
181
180
179
178
177
176
175
dB
0.0
-0.2
-0.4
-0.6
-0.8
-1.0
1
51
101
151
200
250
300
350
1
51
101
151
200
250
300
350
Frequency (M Hz)
F re quenc y ( M H z)
Input Return Loss
0
-5
-10
dB
-15
-20
-25
-30
-35
1
51
101
151
200
250
300
350
Fr e que nc y ( M H z )
3
ADVANCED:
Data Sheets contain information regarding a product M/A-COM Technology Solutions
•
North America
Tel: 800.366.2266 •
Europe
Tel: +353.21.244.6400
is considering for development. Performance is based on target specifications, simulated results,
•
India
Tel: +91.80.4155721
•
China
Tel: +86.21.2407.1588
and/or prototype measurements. Commitment to develop is not guaranteed.
Visit www.macomtech.com for additional data sheets and product information.
PRELIMINARY:
Data Sheets contain information regarding a product M/A-COM Technology
Solutions has under development. Performance is based on engineering tests. Specifications are
typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available.
M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make
Commitment to produce in volume is not guaranteed.
changes to the product(s) or information contained herein without notice.
