MAC Series
Industry Standard Package
RoHS Compliant Available
32.768KHz
CMOS OUTPUT
ELECTRICAL SPECIFICATIONS:
MECHANICAL DETAILS:
20.70 [.815]
MAX
5.08 [.200]
PIN CONNECTIONS
PIN 1 N/C OR TRI-STATE
PIN 7 CASE GROUND
PIN 8 OUTPUT
PIN 14 SUPPLY VOLTAGE
Frequency Range
Frequency Stability
(Inclusive of Temperature,
Load, Voltage and Aging)
Operating Temperature
Storage Temperature
Supply Voltage
Supply Current
Waveform
Logic “0”
Logic “1”
Duty Cycle
Load
Rise / Fall Time
10% to 90% of waveform
32.768KHZ
See Part Number Guide
See Part Number Guide
-55°C to +125°C
5.0VDC ±10%
200uA max
CMOS
10% Vdd max
90% Vdd min
See Part Number Guide
10K Ohms // 15pF
1uSec max
5.08 [.200]
MIN
.50 [.020]
15.24 [.600]
1
7
DIMENSIONS IN BRACKET ARE IN INCHES
EXTERNAL BYPASS CAPACITOR RECOMMENDED
13.10 [.516]
MAX
7.62 [.300]
14
8
TRI-STATE OPERATION
PIN 8
PIN 1
LOGIC "1" OR N/C
OSCILLATION
LOGIC "0" OR GRD HIGH IMPEDANCE
MARKING:
Line 1: MXX.XXX
XX.XXX = Frequency in MHz
Line 2: SYYMML
S = Internal Code
YYMM = Date Code (Year/Month)
L = Denotes RoHS Compliant
Line 3: XXXXX
Internal Manufacture Code
PART NUMBER GUIDE:
MAC
5
32.768KHZ
14 pin DIP
RoHS Compliant
Blank = Not Compliant
F = Is RoHS Compliant
Supply Voltage
5 = +5.0 VDC
Frequency
Stability
050 = ±50 ppm
100 = ±100 ppm
Symmetry
Blank = 40/60%
A = 45/55%
Value Added Options
Blank = No Added Options
G1 = Gull-Wing (option 1)
G = Gull-Wing (option 2)
CLXXX = Cut Leads
XXX = Lead Length Code
Pin 1 Connection
Blank = No Connect
H = Tri-state
Operating Temperature
Blank = 0°C to +70°C
27 = -20°C to +70°C
48 = -40°C to +85°C
PLEASE CONSULT WITH MMD SALES DEPARTMENT FOR ANY OTHER PARAMETERS OR OPTIONS
MMD Components,
30400 Esperanza, Rancho Santa Margarita, CA, 92688
Phone: (949) 709-5075, Fax: (949) 709-3536,
www.mmdcomp.com
Sales@mmdcomp.com
Specifications subject to change without notice
Revision 11/14/06 C
