THRU-HOLE RADIAL SHIELDED INDUCTORS
AISR-01, AISR-04
| | | | | | | | | | | | | | |
FEATURES:
• Ferrite shielded
• Lowest EMI Emission
STANDARD SPECIFICATIONS:
Part
Number
AISR-01
102J
122J
152J
182J
222J
272J
332J
392J
472J
562J
680J
772J
822J
103J
123J
153J
183J
223J
273J
333J
363J
393J
473J
563J
683J
104J
124J
AISR-01
14,0Max
5,0
Ø10,8Max
OPTIONS:
• Bulk Packaging is standard
• Other tolerance available
APPLICATIONS:
• Electronic Appliances
• Band Pass Filters
L
(mH)
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
7.7
8.2
10
12
15
18
22
27
33
36
39
47
56
68
100
120
R
DC
Max
(Ω)
3.4
3.7
4.0
4.5
5.2
5.8
6.1
7.2
7.5
8.4
9.7
10.0
10.4
12.1
13.0
15.0
17.0
19.5
22.0
26.0
27.0
45.0
52.0
58.0
67.0
82.0
97.0
I
DC
Max
(mA)
90
75
70
65
60
55
50
45
40
40
35
30
30
25
25
22
22
21
18
17
16
15
13
12
11
9
8
Part
Number
AISR-04
100M
120M
150M
180M
220M
270M
330L
390L
470L
560L
680L
820L
101L
121L
151L
181L
221L
271L
331L
391L
471L
561L
681L
821L
102L
L
(µH)
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
R
DC
Max
(Ω)
0.023
0.024
0.036
0.039
0.042
0.045
0.057
0.076
0.10
0.11
0.15
0.16
0.19
0.21
0.23
0.26
0.29
0.36
0.51
0.69
0.98
1.10
1.20
1.30
1.50
I
DC
Max
(A)
3.9
3.6
3.2
2.9
2.6
2.4
2.1
2.0
1.8
1.6
1.5
1.4
1.2
1.1
1.0
0.92
0.83
0.75
0.68
0.62
0.57
0.52
0.47
0.43
0.39
PHYSICAL CHARACTERISTICS:
AISR-04
5,0
Ø0,7
TECHNICAL INFORMATION:
• Ordering Code: AISR-XXXX(size)-xxx(value)
• Tolerance: J=±5%, K=±10%, L=15%, M=±20%
• Letter suffix indicates standard tolerance
• Operating Temperature: -40°C to +85°C
Note:
All specifications subject to change without notice.
ABRACON IS
ISO 9001 / QS 9000
CERTIFIED
REVISED: 1.1.07
30332 Esperanza, Rancho Santa Margarita, California 92688
tel 949-546-8000
|
fax 949-546-8001
| www.abracon.com
