UNSHIELDED SMD POWER INDUCTOR
AISC-1210H
FEATURES:
• Low DC resistance permits high current flow
• Exhibit low voltage drops and inductance variations
with respect to temperature rise and DC current level
• Excellent solder heat resistance allows both flow and
reflow soldering methods
• Excellent mechanical reliability suitable for automotive, safety application
Pb
RoHS
Compliant
APPLICATIONS:
3.2 x 2.5 x 2.0mm
| | | | | | | | | | | | | | |
• Excellent for power line DC/DC conversion applications
• Used in video, communications, notebook computer
and other electronic equipment
STANDARD SPECIFICATIONS:
PARAMETERS
ABRACON P/N:
Operating temperature:
Storage temperature:
AISC-1210H-xxx Series
-25°C to + 85°C
-25°C to + 85°C, 70% RH max.
SRF (MHz) Min
OPTIONS & PART IDENTIFICATION:
(Left blank if standard)
AISC - 1210H -
Inductance Code
Please refer to the
Table
-
Packaging
T
Tape & Reel
Tolerance Code
Please refer to the Table
Abracon
Inductance
Test
Frequency
Part Number
L (µH)
AISC-1210H-R15N
0.15
1.0 MHz
AISC-1210H-R27N
0.27
1.0 MHz
AISC-1210H-R39N
0.39
1.0 MHz
AISC-1210H-R56N
0.56
1.0 MHz
AISC-1210H-R82N
0.82
1.0 MHz
AISC-1210H-1R0N
1.0
1.0 MHz
AISC-1210H-1R2N
1.2
1.0 MHz
AISC-1210H-1R5N
1.5
1.0 MHz
AISC-1210H-1R8N
1.8
1.0 MHz
AISC-1210H-2R2N
2.2
1.0 MHz
AISC-1210H-2R4N
2.4
1.0 MHz
AISC-1210H-2R7N
2.7
1.0 MHz
AISC-1210H-3R3N
3.3
1.0 MHz
AISC-1210H-3R9N
3.9
1.0 MHz
AISC-1210H-4R7N
4.7
1.0 MHz
AISC-1210H-5R6N
5.6
1.0 MHz
AISC-1210H-6R8N
6.8
1.0 MHz
AISC-1210H-8R2N
8.2
1.0 MHz
AISC-1210H-100K
10.0
1.0 MHz
AISC-1210H-120K
12.0
1.0 MHz
AISC-1210H-150K
15.0
1.0 MHz
AISC-1210H-180K
18.0
1.0 MHz
AISC-1210H-220K
22.0
100 KHz
AISC-1210H-270K
27.0
100 KHz
AISC-1210H-330K
33.0
100 KHz
AISC-1210H-390K
39.0
100 KHz
AISC-1210H-470K
47.0
100 KHz
AISC-1210H-560K
56.0
100 KHz
AISC-1210H-680K
68.0
100 KHz
AISC-1210H-820K
82.0
100 KHz
AISC-1210H-101K
100.0
100 KHz
AISC-1210H-121K
120.0
100 KHz
AISC-1210H-151K
150.0
100 KHz
AISC-1210H-181K
180.0
100 KHz
AISC-1210H-221K
220.0
100 KHz
AISC-1210H-271K
270.0
100 KHz
AISC-1210H-331K
330.0
100 KHz
AISC-1210H-391K
390.0
1 KHz
AISC-1210H-471K
470.0
1 KHz
AISC-1210H-561K
560.0
1 KHz
AISC-1210H-681K
680.0
1 KHz
Inductance tolerance: N:
±30%;
K: ±20%
ABRACON IS
ISO 9001 / QS 9000
CERTIFIED
400
250
200
180
150
100
90
80
72
64
62
60
53
45
43
38
32
30
26
26
26
20
19
18
17
16
15
13
12
12
10
8
7
7
6.8
6
5.6
5
4
4
3.2
Rdc(mΩ)
Max
21
22
33
50
53
63
92
100
110
124
130
132
167
222
247
359
392
450
509
674
760
978
1000
1240
1940
2000
3200
3640
4060
4580
6880
7470
8320
13160
14400
15000
18900
20400
27500
29800
40000
Rated DC
Current (A)
4.40
4.00
3.10
2.90
2.60
2.30
2.10
1.70
1.50
1.30
1.30
1.20
1.15
1.00
0.90
0.78
0.75
0.70
0.65
0.61
0.55
0.45
0.43
0.38
0.35
0.33
0.30
0.25
0.21
0.20
0.18
0.16
0.14
0.12
0.10
0.08
0.06
0.06
0.06
0.05
0.04
Ir: Rated current that will cause initial inductance value
approximately 10% rolloff or coil temperature rise by 40ºC
without core loss, which ever is smaller. (Reference ambient
temperature 20ºC).
L: measured with CH-1061 with 1320
SRF: measured with HP-8714C RF network analyzaer
Revised: 12.19.08
30332 Esperanza, Rancho Santa Margarita, California 92688
tel 949-546-8000
|
fax 949-546-8001
| www.abracon.com
Visit www.abracon.com for Terms & Conditions of Sale
UNSHIELDED SMD POWER INDUCTOR
AISC-1210H
OUTLINE DRAWING:
Pb
RoHS
Compliant
3.2 x 2.5 x 2.0mm
| | | | | | | | | | | | | | |
Series
AISC-1210H
A
0.126±0.012
B
0.098±0.008
C
0.079±0.012
D(ref)
0.039
(1.0)
E
0.098±0.008
a(ref)
0.118
(3.0)
b(ref)
0.051
(1.3)
c(ref)
0.039
(1.0)
(3.2 ±0.3)
(2.5 ±0.2)
(2.0 ±0.3)
(2.5 ±0.2)
Dimensions: inch
(mm)
TAPE & REEL:
Tape and reel 4,000pcs/reel
ABRACON P/N
AISC-1210H
A (mm)
2.84 ± 0.1
B (mm)
3.71 ± 0.1
K (mm)
2.57 ± 0.1
P (mm)
4.0 ± 0.1
W (mm)
8.0 ± 0.3
PCS/REEL
1500
Series
AISC-1210H
A
330-0.5
C
8.4+1.5
A
Z
C
Z
100±1.0
Dimensions: mm
ABRACON IS
ISO 9001 / QS 9000
CERTIFIED
Revised: 12.19.08
30332 Esperanza, Rancho Santa Margarita, California 92688
tel 949-546-8000
|
fax 949-546-8001
| www.abracon.com
Visit www.abracon.com for Terms & Conditions of Sale
