Axial Power Chokes
APC30
Dimensions:
Inches
(mm)
20 AWG
1.15
NOMINAL
(29)
0.92
(23.37)
1.15
NOMINAL
(29)
0.47
(11.94)
Allied
Part
Number
Inductance
(µh)
Tolerance
(%)
DCR
Max.
(Ω)
Saturation
Current
(A)
Rated
Current
(A)
Features
•
Axial pre-tinned leads.
•
Protected with UL shrink tubing.
•
Non standard values and tolerances
available.
•
High saturation core material used for
high inductance and low DCR.
Electrical
Inductance:
Measured at 1KHz with no
DC current.
Tolerance:
10% over entire inductance
range. Available in tighter tolerances.
Current Rating:
Based on Inductance drop
of < 10% of Initial value.
Operating Temp:
-55ºC to + 125ºC
Test Procedures:
L measured on CH-100
@ 1KHz DCR measured on CH-301.
Physical
Packaging:
200 pieces per tape and
reel. 50 pieces per bag
Marking:
EIA Inductance Code.
For Tape and Reel packaging please
add ”-TR” to the part number.
APC30-3R9K-RC
APC30-4R7K-RC
APC30-5R6K-RC
APC30-6R8K-RC
APC30-8R2K-RC
APC30-100K-RC
APC30-120K-RC
APC30-150K-RC
APC30-180K-RC
APC30-220K-RC
APC30-270K-RC
APC30-330K-RC
APC30-390K-RC
APC30-470K-RC
APC30-560K-RC
APC30-680K-RC
APC30-820K-RC
APC30-101K-RC
APC30-121K-RC
APC30-151K-RC
APC30-181K-RC
APC30-221K-RC
APC30-271K-RC
APC30-331K-RC
APC30-391K-RC
APC30-471K-RC
APC30-561K-RC
APC30-681K-RC
APC30-821K-RC
APC30-102K-RC
APC30-122K-RC
APC30-152K-RC
APC30-182K-RC
APC30-222K-RC
APC30-272K-RC
APC30-332K-RC
APC30-392K-RC
APC30-472K-RC
APC30-562K-RC
APC30-682K-RC
APC30-822K-RC
APC30-103K-RC
APC30-123K-RC
APC30-153K-RC
APC30-183K-RC
APC30-223K-RC
APC30-273K-RC
APC30-333K-RC
APC30-393K-RC
APC30-473K-RC
APC30-563K-RC
APC30-683K-RC
APC30-823K-RC
APC30-104K-RC
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
10000
12000
15000
18000
22000
27000
33000
39000
47000
56000
68000
82000
100000
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
.007
.008
.011
.011
.013
.017
.019
.022
.023
.026
.027
.032
.033
.035
.037
.047
.060
.090
.113
.129
.150
.162
.202
.212
.281
.380
.420
.548
.665
.884
1.04
1.18
1.56
2.00
2.06
2.63
2.75
3.19
3.92
5.69
6.32
7.30
9.99
11.2
15.2
16.8
18.6
26.7
29.0
31.8
42.6
46.9
64.9
71.7
15.5
13.9
12.6
11.6
9.89
8.70
8.21
7.34
6.64
6.07
5.36
4.82
4.36
3.98
3.66
3.31
3.10
2.79
2.54
2.22
1.98
1.89
1.63
1.51
1.39
1.24
1.17
1.05
0.97
0.87
0.79
0.70
0.64
0.58
0.53
0.47
0.43
0.39
.359
.322
.293
.266
.257
.230
.210
.190
.171
.155
.143
.131
.119
.108
.098
.089
4.00
4.00
4.00
4.00
4.00
4.00
4.00
4.00
4.00
4.00
4.00
4.00
4.00
4.00
3.20
2.50
2.00
1.60
1.60
1.60
1.60
1.60
1.60
1.60
1.60
1.20
1.00
1.00
0.80
0.80
0.60
0.60
0.60
0.50
0.40
0.40
0.40
0.40
.315
.250
.250
.250
.160
.160
.130
.130
.130
.100
.100
.100
.083
.083
.067
.067
