AIR CORE INDUCTORS
Aerospace Grade Air Core Inductors
AE536RAT
■
High Q over a wide range of frequencies
■
High temperature materials allow operation in ambient
temperatures up to 155°C.
■
Passes NASA low outgassing specifications
■
Tin-lead (63/37) terminations ensures the best possible
board adhesion
Terminations
Tin-lead (63/37) over copper
Ambient temperature
–55°C to +125°C with
Imax
current, +125°C
to +155°C with derated current
Storage temperature
Component: –55°C to +155°C.
Packaging: –55°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Temperature Coefficient of Inductance (TCL)
+5 to +70 ppm/°C
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Enhanced crush-resistant packaging
800 per 13″ reel
Plastic tape: 24 mm wide, 0.3 mm thick, 12 mm pocket spacing,
6.1 mm pocket depth
Part number
1
AE536RAT90N_SZ
AE536RATR11_SZ
AE536RATR13_SZ
AE536RATR17_SZ
AE536RATR21_SZ
AE536RATR22_SZ
AE536RATR25_SZ
AE536RATR31_SZ
AE536RATR38_SZ
AE536RATR42_SZ
AE536RATR49_SZ
AE536RATR54_SZ
Turns
9
10
11
12
13
14
15
16
17
18
19
20
Inductance
2
(nH)
90
111
130
169
206
222
246
307
380
422
491
538
Percent
tolerance
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
Q
3
typ
114
104
104
114
114
110
114
114
114
114
114
104
Q
3
min
95
87
87
95
95
92
95
95
95
95
95
87
SRF min
4
(GHz)
1.140
1.020
0.900
0.875
0.800
0.730
0.685
0.660
0.590
0.540
0.535
0.490
DCR max
5
(mOhm)
15
15
20
25
30
35
35
35
50
60
65
90
Imax
(A)
3.5
3.5
3.0
3.0
3.0
3.0
3.0
3.0
2.5
2.5
2.0
2.0
1. When ordering, specify
tolerance
and
testing
codes:
AE536RATR54GSZ
= 2%
J
= 5%
= Coilcraft Critical Products Environmental Stress Conditions Testing.
= Coilcraft Qual + Coilcraft Hi-Rel Burn-in
= Coilcraft Qual + MIL-STD-981 Class B Group A screening
= Coilcraft Qual + MIL-STD-981 Class S Group A screening + MIL-STD-981 Class S Group B qualification
Tolerance: G
Testing:
Z
H
N
C
2. Inductance measured at 50 MHz on an Agilent/HP 4286A or equivalent with a Coilcraft SMD-A test fixture and correlation.
3. Q measured at 50 MHz on an Agilent/HP 4291A or equivalent with a 16193-A test fixture or equivalent.
4. SRF measured on an Agilent/HP 8753D or equivalent with a Coilcraft SMD-D test fixture.
5. DCR measured on a Keithley 580 Micro-Ohmmeter or equivalent.
6. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
®
These parts are preproduction products for electrical evaluation only.
Specification subject to change without notice.
Document AE185-1
Revised 09/17/09
1102 Silver Lake Road
Cary IL 60013
© Coilcraft, Inc. 2009
Phone
800-981-0363
Fax
847-639-1508
E-mail
cp@coilcraft.com
Web
www.coilcraft-cps.com
