BCM1113R
®
IP PHONE CHIP
FEATURES
SUMMARY OF BENEFITS
•
The BCM1113R is a highly integrated silicon solution
specifically targeted at the cost-sensitive residential, Small
Office Home Office (SOHO), and Small-to-Medium sized
Business (SMB) market.
•
The BCM1113R integrates:
•
87.5-MHz MIPS32™ CPU (96 DMIPS) with 8K I-cache and
4K D-cache
•
Superscalar 87-MHz ZSP DSP with dual-MAC (174 MIPS),
48K instruction, and 32K data RAM
•
Three-port 10/100BASE-T Ethernet switch with 64K buffer
memory
•
Two 10/100BASE-T Ethernet PHYs with in-line power over
Ethernet support
•
Three wideband audio ADCs and DACs
•
9 x 9 keyscan controller
•
Ethernet status LED driver
•
TDM IOM-2
®
port
•
Two UARTs
•
Two high-speed serial ports
•
General purpose I/O
•
Interrupt control unit
•
DMA support unit
•
SDRAM interface
•
External bus interface
•
IEEE 1149.1 (JTAG)
•
0.18µ process technology, 1.8/3.3V
•
1.1W peak, 0.3W – 0.8W standby modes
•
10/100BASE-T Ethernet Switch with 802.1p/Q support
•
802.1p priority queuing ensures QoS for voice packets and
minimizes latency
•
Supports modification of 802.1p priority tags on packets to
enforce priority tagging rules
•
802.1Q VLAN support allows for segmenting physical
networks into multiple logical networks
•
MIPS32 CPU not burdened by data packet processing, leaving
more cycles for application program
•
Enables wire-speed non-blocking operation
•
Blocks unnecessary traffic by learning local MAC addresses
•
Segments network, preventing any restriction on number of
hops
•
87.5-MHz MIPS32 CPU and 87-MHz DSP Support
•
VxWorks Operating System
•
SIP, H.323, H.248/Megaco, and MGCP
•
Narrowband Vocoders: G.711, G.726, G.729A/AB, G.723.1/A
and BroadVoice16™
•
Wideband Vocoders: G.722.1 and BroadVoice32™
•
Full-duplex speakerphone operation
•
Handset echo suppression
•
Enhanced Packet Loss Concealment
•
User application software
•
10/100BASE-T Ethernet MACs and PHYs
•
Integrates support for Cisco in-line power specification
•
Compliant with 802.3af power over Ethernet standard
•
Provides auto-MDI/MDIX, enabling the use of straight or
crossover cables in either port
•
Wideband audio CODECs
•
Enables support of emerging wideband vocoding standards
•
256-pin PBGA package enables 4-layer PCB designs
•
Pin and software compatible with the BCM1101, BCM1113,
BCM1115, and BCM1115R ICs
HARDWARE PLATFORMS
•
BCM91101 reference platform
•
Ethernet IP phone reference platform for mid-range IP Phones
designs
OVERVIEW
BCM1113R VoIP Ethernet CPE Engine
Master SPI
Port
External
Interrupt
Controller
Keypad Scan Controller
[or 18 GPIOs]
UART 0
UART 1
18 GPIOs
Peripheral Bus
IPB
Bridge
Watchdog
Timer
Timers
MIPS JTAG
ZSP JTAG
MIPS32 CPU
+ 8K I-Cache
+ 4K D-Cache
High
Speed
Serial
Port 2
100-MHz CPU System Bus
Analog Processor Module
CODEC Channel 3
CODEC Channel 2
CODEC Channel 1
16-bit D/A
16-bit A/D
48 KB of
Program
Memory
ZSP DSP
32 KB of
Data
Memory
High
Speed
Serial
Port 1
TDM
(IOM-2)
Port
50-MHz
External Bus
Interface
Flash/
EPROM
10/100BASE-T
Auto-MDIX PHY
10/100BASE-T
Auto-MDIX PHY
port 0
Three-Port
Ethernet
Switch
port 1
port 2
SDRAM
Interface
SDRAM
Ethernet LED
Driver
64 KB of
Buffer Memory
DMA Arbiter
Broadcom's BCM1113R is a highly integrated IP phone chip specifically
targeted at the cost-sensitive consumer equipment market.
Key modules integrated in the BCM1113R include:
•
MIPS32™ 87.5 MHz processor with 8K 2-way set associative I-
cache and 4K 2-way associated D-cache. This MCU supports the
VoIP protocol stacks, VxWorks operating system, and customer
application software. Programming is done in C, on top of
Broadcom's object-oriented signal processing API.
•
ZSP 87-MHz DSP with 48-KB instruction and 32-KB data RAM.
The DSP can support narrowband voice communication using
G.711, G.726, G.723.1/A, G.729A, or BroadVoice16, and wideband
communications using G.722 or BroadVoice32. Full-duplex
speakerphone capability is supported in conjunction with any of
these voice compression techniques. The DSP also supports
enhanced Packet Loss Concealment, Jitter Buffer, and telephony
algorithms.
•
Analog codecs: integrated analog CODECs capable of supporting
both narrowband 8 Kilohertz (KHz) and wideband 16 KHz sampling,
which, in conjunction with wideband voice coders, such as
Broadcom's BroadVoice32, will enable IP phone networks to deliver
high fidelity voice transmission
•
10/100BASE-T Ethernet switch, media access controllers, and
transceivers. The three-port Ethernet switch integrates three full-
duplex capable Media Access Controllers (MACs), a serial
management port, an address resolution engine, a non-blocking
switch controller, 64K of internal switch memory, 802.1p
prioritization for voice packets, 802.1Q VLAN support for
segmenting physical networks into multiple logical networks, and a
set of Management Information Base (MIB) statistics registers. The
two transceivers perform all of the functions for 100BASE-T
Ethernet in full- or half-duplex mode over Category (CAT) 5 twisted-
pair cable and 10BASE-T Ethernet in full- or half-duplex mode over
CAT 3, 4, or 5 twisted-pair cable. They support auto-MDI/MDIX
detection to allow the use of any cable type in either port. The
transceivers also integrate support for in-line powering over Ethernet.
The BCM1113R is pin and software compatible with the BCM1101
Enterprise IP Phone chip and is suited for IP Phone products that require
basic application features sets, while still requiring the same voice
quality and reliability of higher end IP phone products.
