DS84LC Series
SURFACE MOUNT FIXED INDUCTOR
TYPE DS84LC
Inductance Range:
1.0 - 10µH
Frequency Range:
0.1 - 1MHz
Dimensions & Recommended Patterns:
Description
The TOKO DS84LC Series of magnetically shielded surface mount
fixed inductors are designed for general purpose DC-DC converter
applications in consumer electronics platforms.
Features
•
•
•
•
•
•
8.4mm x 8.3mm footprint
4.0mm maximum height
Magnetically shielded
Reflow solderable
Packaged on 500 piece reels
Lead-free terminations
3.5
8.7
3.6
Tolerance:
±0.3
Unit: mm
STANDARD PARTS SELECTION GUIDE
(1) Inductance is measured by LCR-meter 4284A (Agilent) or equivalent.
(2) DC resistance is measured by Digital Multimeter TR6871 (Advantest) or equivalent.
(3) Maximum allowable DC current is that which causes a 10% inductance reduction from the initial value,
or coil temperature to rise by 40°C, whichever is smaller. (Reference ambient temperature 20°C).
TYPE DS84LC
TOKO
Part
Number
B1015AS-1R0N=P3
B1015AS-1R5N=P3
B1015AS-2R2N=P3
B1015AS-3R0N=P3
B1015AS-3R9N=P3
B1015AS-4R7N=P3
B1015AS-5R6N=P3
B1015AS-6R8N=P3
B1015AS-8R2N=P3
B1015AS-100M=P3
Inductance
(1)
(µH)
Tolerance
(%)
DC
(2)
Resistance
(
Ω
) max.
0.011
0.014
0.018
0.024
0.033
0.038
0.041
0.051
0.062
0.071
Inductance
(3)
Decrease Current
-10%
(A) max.
8.0
6.6
5.6
4.8
4.2
3.8
3.5
3.2
2.9
2.7
Temperature
(3)
Rise Current
+40°C
∆T
(A) max.
6.9
6.2
5.1
4.3
3.6
3.3
3.1
2.7
2.5
2.2
1.0
1.5
2.2
3.0
3.9
4.7
5.6
6.8
8.2
10
±30
±30
±30
±30
±30
±30
±30
±30
±30
±20
Note:
=P3
is added to each part number to indicate tape and reel packaging.
The information furnished by TOKO, Inc. is believed to be accurate and reliable. However, TOKO reserves the right to make changes or improvements in the design, specification or manufacture
of its products without further notice. TOKO does not assume any liability arising from the application or use of any product or circuit described herein, nor for any infringements of patents
or other rights of third parties which may result from the use of its products. No license is granted by implication or otherwise under any patent or patent rights of TOKO, Inc.
TOKO America, Inc.
1250 Feehanville Drive, Mount Prospect, Illinois 60056
Tel: (847) 297-0070 Fax: (847) 699-7864 Web: http://www.tokoam.com
January 2005
© 2005 TOKO America, Inc.
All Rights Reserved
Printed in USA
CF-282-DS84LC
R-LOG0105A
