DESCRIPTION
INITIAL RELEASE
ECN 3194: UPDATE DWG FORMAT
2
REVISIONS
1
DATE
12/29/03
2/8/08
CHANGED BY
MCCORMICK
D.GRIFFIN
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE
PROPERTY OF L-COM, INC. ANY REPRODUCTION IN PART OR WHOLE
WITHOUT THE WRITTEN PERMISSION OF L-COM, INC. IS PROHIBITED.
D
D
1.59 [40.38]
.37 [9.39]
.16 [4.06]
.89 [22.6]
C
.72 [18.29]
.21 [5.33]
C
B
NOTES:
MATERIAL:
BODY: POLYETHYLENE
PLUGS: COPPER
FINISH:
PLUGS: GOLD PLATE
.63 [16]
B
A
ELECTRICAL:
CONTACT RESISTANCE: <20m
INSULATION RESISTANCE: >100m
WITHSTAND VOLTAGE: DC150V
CURRENT RATING: 2A/DC100V
OPERATING TEMPERATURE: -30 C TO 60 C
PACKAGING:
INDIVIDUALLY PACKAGE IN A POLYBAG
RoHS Compliant
APPROVALS
UNLESS OTHERWISE SPECIFIED,
DRAWN BY
DIMENSIONS ARE IN INCHES [mm]
C.MCCORMICK
TOLERANCES TO BE:
.X .1 [2.5]
ANGLES 2 CHECKED BY
.XX .01 [.25]
D.PARHAM
.XXX .005 [.13]
OVERALL CABLE LENGTH TOL:
≤
60 [1524] +3 [76.2] / - 0
> 60 [1524] +5% / -0%
PROJ
APPROVED BY
R.CARRICK
DATE
CATEGORY
12/29/2003
12/29/2003
12/29/2003
SIZE
PRODUCT DESCRIPTION
45 BEECHWOOD DRIVE
NORTH ANDOVER, MA
01845
COAXIAL
A
CONNECTOR DUAL BANANA PLUG
CONFIGURATION DETAILS OF
UNDIMENSIONED FEATURES
MAY VARY
SCALE: NONE CAD FILE:
A
43321
FSCM NO.
DWG. NO.
BP125209
1
REV.
SHEET 1 OF 1
BP125209.SLDDRW
