BAS/BS/SC SERIES
SPDT
FEATURES
1,2,5 Amp
File No.:E75887
・FCC
Pt 68
・Small
Package
・Fully
sealed
・PC
Pin
・Sensitive
type and standard type are available
CONTACT RATINGS
Contact Arrangement
Contact Resistance
Contact Material
Contact Rating(Resistive)
1C
100mΩ (1A 24VDC)
AgNi，Gold FLash，SiIver AIIoy
1A 125VAC/30VDC
1A 240VAC/30VDC
2A 125VAC,3A 120VAC
5A/120VAC
120VAC/30VDC
2A DC/AC BAS,BS,SC
5A DC/AC BAS 511
600VA/60W
5×10
6
operations
5×10
5
operations resistive load 24VDC,1A
1×10
5
operations resistive load 120VAC,0.5A
ORDERING INFORMATION
BAS 111 DC12 GF - 1 - XXX
Model
Coil Power:111=Standard type
511=Standard type heavy load
Coil Voltage
GF:Gold Flash Contacts NIL:No Gold Flash
1:Covered Nil:Sealed
Customer code
BS/SC 211 DC12 GF - 1 - XXX
Max. Switching Voltage
Max. Switching Current
Max. Switching Power
Mechanical Life
Electrical Life
Model
Coil Power:211=Sensitive type
Coil Voltage
GF:Gold Flash Contacts NIL:No Gold Flash
1:Covered Nil:Sealed
Customer code
COIL DATA
Standard Type
Nominal
Voltage
VDC
3
Pick-up
Voltage
(Max.)
VDC
2.1
3.5
4.2
6.3
8.4
16.8
33.6
Pick-up
Voltage
(Max.)
VDC
2.1
3.5
4.2
6.3
8.4
16.8
Drop-out
Voltage
(Min.)
VDC
0.3
0.5
0.6
0.9
1.2
2.4
4.8
Drop-out
Voltage
(Min.)
VDC
0.3
0.5
0.6
0.9
1.2
2.4
Max.
Allowable
Voltage
VDC
3.3
5.5
6.6
9.9
13.2
26.4
52.8
Max.
Allowable
Voltage
VDC
4.8
8.0
9.6
14.4
19.2
38.4
at 23°C
Coil
Resistance
Ω±10%
20
56
80
180
320
1280
5120
CHARACTERISTICS
Insulation Resistance
Dielectric
Strength
Between coil & contacts
Between open contacts
100MΩ (at 500VDC)
1000VAC 1min
500VAC 1min
≤10ms
≤5ms
35% ~ 85% RH
-25°C
~
+70°C
98m/s
2
980m/s
2
10Hz
~
55Hz 1.5mm DA
Approx. 4g
Sealed、Covered
5
6
9
12
24
48
Nominal
Voltage
VDC
3
5
6
9
12
24
Operate time (at nomi. volt.)
Release time (at nomi. volt.)
Humidity
Ambient temperature
Functional
Shock
Resistance
Destructive
Vibration resistance
Unit weight
Construction
Sensitive Type
Coil
Resistance
Ω±10%
45
120
180
400
700
2800
Notes:1) The data shown above are initial values.
2) Please find coil temperature curve in the characteristic curved below.
This datasheet is for customers' reference. All the specifications are subject to change without notice.
RELAYS & ELECTRONICS INT'L. CORP.
TEL:(516) 328-9292
FAX:(516)326-9125
www.hascorelays.com
email:info@hascorelays.com
4
BAS/BS/SC SERIES
COIL
Coil Power
Standard Type: 450mW
Sensitive Type: 200mW
SPDT
1,2,5 Amp
SAFETY APPROVAL RATINGS
UL&CUL
1A 125VAC/30VDC
1A 240VAC/30VDC
2A 125VAC,3A 120VAC
5A/120VAC
OUTLINE DIMENSIONS, WIRING DIAGRAM AND PC BOARD LAYOUT.
Outline Dimensions
.62 MAX
(15.7)
Unit: inch(mm)
Wiring Diagram
(Bottom view)
BAS/BS Series
.047(1.2)
PCB Layout
(Bottom view)
BAS/BS Series
6-Φ.039(1)
BAS/BS Series
.125
(3.2)
.4(10.16)
.1(2.54)
.4(10.16)
.1(2.54)
.62 MAX
(15.7)
SC Series
.047(1.2)
SC Series
SC Series
6-Φ.039(1)
.125
(3.2)
.4(10.16)
.1(2.54)
.4(10.16)
.1(2.54)
Remark:1)
In case of no tolerance shown in outline dimension: outline dimension
≤1mm,tolerance
should be ±0.2mm; outline dimension
＞1mm
and
≤5mm,tolerance
should be ±0.3mm;outline dimension
＞5mm,
tolerance should be ±0.4mm.
2)
The tolerance without indicating for PCB layout is always ±0.1mm.
CHARACTERISTIC CURVES
ENDURANCE CURVE
Temperature Rise (K)
Operations (×100000 OPS)
COIL TEMPERATURE RISE
Time (ms)
OPERATE TIME
Operate time
Release time
Switching Current (A)
Coil Power (W)
Coil Power (W)
This datasheet is for customers' reference. All the specifications are subject to change without notice.
RELAYS & ELECTRONICS INT'L. CORP.
TEL:(516) 328-9292
FAX:(516)326-9125
www.hascorelays.com
email:info@hascorelays.com
5
.3(7.62)
.44 MAX .43 MAX
(10.9)
(11.2)
.3
(7.62)
.3(7.62)
.44 MAX .43 MAX
(10.9)
(11.2)
.3
(7.62)
