BCM57765
®
Brief
SUMMARY OF BENEFITS
•
Single-chip solution for LAN and memory card reader on
motherboard applications
products
Integrated Gigabit Ethernet and Memory Card Reader
Controller
FEATURES
•
Integrated 10/100/1000BASE-T transceiver
•
10/100/1000BASE-T triple-speed MAC
•
Compliant with IEEE standards
•
Compliant with IEEE 802.3az draft standard for Energy
Efficient Ethernet™ (EEE)
•
State-of-the-art physical layer interface that exceeds IEEE
requirements
•
Jumbo frame support with up to 9.6 KB frame size
•
EthernetAV protocols with IEEE 802.1AS, 1588-2008,
IEEE P802.1Qat and IEEE P802.1Qav support
•
Proven technology built on twelve generations of controller
•
Wirespeed performance increases user performance.
•
PCI Express provides wirespeed non-blocking throughput.
•
TCP/IP checksum offload significantly reduces CPU usage
and increases network throughput for large file download.
friendly designs
•
Increases battery life in mobile applications and saves energy
in desktop implementations
•
Advanced power management capabilities with ASPM L0s,
L1, and PCIe CLKREQ
•
Eliminates false system wake-up with NIC proxy capabilities
•
Enables Energy Star
®
-compliant platforms
•
8 mm x 8 mm, 68-pin QFN package
•
Integrated 5-in-1 memory card reader
®
•
Extremely low power consumption enables environment-
•
SD Secure Digital -compliant with specification v3.0 (SD,
miniSD™, microSD™, SDHC, miniSDHC, SDXC, and
microSDXC)
•
MultiMedia Card-compliant with specification v4.4 (MMC,
MMCplus
®
, MMCmicro
®
, HS MMC, and MMCmobile
®
)
•
Memory Stick
®
-compliant with specification v1.43 and PRO
v1.03 (MS, MS PRO, MS PRO Duo, MS PRO-HG, MS PRO-
HG Duo, and Micro)
•
xD-Picture
a
-compliant with specification v1.2C (Type-M and
Type-H)
•
x1 PCIe™ v1.1
•
Active State Power Management (ASPM) capability
•
Message Signal Interrupt (MSI)
•
Centralized power management enables easy and efficient
control of various power modes.
•
Innovative implementation that optimizes power consumption
dynamically and transparently, depending on network and
system states.
TCP, IP, and UDP Checksum Offload (CSO)
Receive Side Scaling (RSS) for multicore client processors
IPV4 and IPV6 Microsoft
®
Large Send Offload (LSO)
Interrupt coalescing
Microsoft Windows
®
7 WoL and Proxy support
•
Small package enabling smaller and more portable designs
•
Lower BOM cost and chip cost, reducing overall cost of
®
•
PCI Express host interface
•
Intelligent power management
solution
•
65 nm process
•
Fully integrated power regulation with minimal external
discrete component
•
On-chip nonvolatile memory that eliminates the need for
external memory device
•
On-chip PLLs requiring a single input clock for both LAN
and card reader functions
•
Allows diskless implementations
•
Improved manageability and deployment with remote boot
•
ASF 2.0 support for standards-based alerting IT managers
receive automatic alerts when PC support issues occur.
•
Remote power-on/off features allow IT managers to power-
cycle PCs to address issues and save energy.
•
iSCSI boot capability
•
Performance features
•
•
•
•
•
•
System alerting and power cycling reduces IT costs
•
Robust ACPI-compliant WOL
•
Alert Standard Format (ASF) 2.0
•
On-chip voltage regulation using switching regulator
a. xD-Picture is only available on select SKUs.
OVERVIEW
TXDP/N
RXDP/N
REFCLK+/-
PCI Express
PERST
WAKE
CLKREQ
CR_DATA[7:0]
CR_CTRL
CARD_DETECT
MEDIA_SENSE
GRC Registers
DMA
Status
XTAL_I
XTAL_O
Memory Card
Reader
CPU
Buffer Memory
BIAS
RDAC
Ethernet
Transceiver
TRD[3:0]+/-
Media Access
Controller
(MAC)
LED
Control
SPD1000LED, SPD100LED
LINKLED, TRAFFICLED
I/O
Control
EECLK, EEDATA
SMBus CLK, SMBus data
Clock
Generation
Control
PCI Config
LOW_PWR
VMAIN_PRSNT
Power-On
Reset (POR)
PHY MII
Voltage Regulator
REGOUT12_IO
Functional Block Diagram
The BCM57765 is a Broadcom
®
NetXtreme
®
highly integrated
multifunction controller that integrates a single-port triple-speed 10/100/
1000BASE-T Ethernet LAN controller along with a 5-in-1 memory card
reader controller that supports the latest Flash™ memory cards for SD,
MMC, MS, MS PRO, and xD-Picture types. The device combines a
triple-speed IEEE 802.3™-compliant Media Access Controller (MAC)
with a triple-speed Ethernet transceiver, x1 PCIe bus interface, memory
card interface controller, and on-chip buffer memory in a single device.
The BCM57765 is fabricated using a 65 nm CMOS process, providing a
low-power system solution.
The device performs all the physical layer functions for 1000BASE-T,
100BASE-T, and 10BASE-T Ethernet on standard Category 5 UTP
cable. Based on proven DSP technology, the BCM57765 combines
digital adaptive equalizers, ADCs, PLLs, line drivers, echo cancellers,
crosstalk cancellers, and all other required support circuitry. A full-
featured MAC provides full-duplex/half-duplex capability at all speeds.
The on-chip high-performance processor enables custom frame
processing features. For a lower total solution cost and lower power
system-level power consumption, the BCM57765 integrates on-chip
switching regulators and nonvolatile memory that eliminates the need for
an external NVRAM device. The BCM57765 is truly a single-chip
solution for Gigabit Ethernet LOM and 5-in-1 memory card reader
packaged in a small 68-pin QFN package.
Target applications:
•
Desktop and mobile PC LOM and memory card reader
Software drivers available:
•
Windows
®
, 2000, XP, Vista
®
, and 7
•
Linux
®
2.4 and 2.6
