Surface Mount
Power Splitter/Combiner
4 Way-0° 50
Ω
Maximum Ratings
Operating Temperature
Storage Temperature
Power Input (as a splitter)
Internal Dissipation
-40°C to 85°C
-65°C to 150°C
1.5W max.
0.375W max.
BP4U+
2100 to 2500 MHz
Features
• low insertion loss, 0.7 dB typ
• excellent isolation, 23 dB typ.
• excellent VSWR, 1.15:1 typ.
• umplitude unbalance, 0.6 dB typ.
• aqueous washable
• excellent power handling, 1.5W
CASE STYLE: XX211
PRICE: $1.49 ea. QTY (25)
Permanent damage may occur if any of these limits are exceeded.
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The + suffix has been added in order to identify RoHS
Compliance. See our web site for RoHS Compliance
methodologies and qualifications.
Pin Connections
SUM PORT
PORT 1
PORT 2
PORT 3
PORT 4
GROUND
2
1
8
5
4
3,6,7
Applications
• bluetooth
• IEEE 802.11b, g
FREQ.
RANGE
(MHz)
f
L
-f
U
2100-2500
Electrical Specifications
INSERTION LOSS (dB)
ABOVE 6 dB
PHASE
UNBALANCE
(Degrees)
Max.
20
ISOLATION
(dB)
AMPLITUDE
UNBALANCE
(dB)
Max.
1.1
VSWR
(:1)
Typ.
Ports
S
1.15
Ports
1,2,3,4
1.15
Outline Drawing
PCB Land Pattern
Typ. Min.
23 17
Typ. Max.
0.7 1.2
Typical Performance Data
Freq.
(MHz)
S-1
2100.00
2120.00
2160.00
2180.00
2200.00
2240.00
2260.00
2280.00
2320.00
2340.00
2380.00
2400.00
2440.00
2480.00
2500.00
6.12
6.12
6.12
6.12
6.13
6.14
6.16
6.17
6.20
6.21
6.25
6.27
6.31
6.36
6.38
Total Loss
1
(dB)
S-2 S-3 S-4
6.78
6.76
6.73
6.72
6.70
6.69
6.68
6.67
6.67
6.67
6.67
6.67
6.68
6.70
6.70
6.84
6.82
6.78
6.77
6.76
6.74
6.73
6.73
6.72
6.72
6.72
6.72
6.72
6.74
6.74
6.82
6.80
6.78
6.78
6.77
6.76
6.76
6.76
6.77
6.77
6.78
6.79
6.82
6.84
6.85
Amp.
Unbal.
(dB)
0.72
0.70
0.66
0.65
0.64
0.62
0.61
0.60
0.57
0.56
0.54
0.53
0.51
0.48
0.47
Isolation
(dB)
1-2
2-3 3-4
27.06
27.15
27.19
27.14
27.02
26.61
26.42
26.23
25.74
25.49
25.01
24.75
24.23
23.80
23.57
35.82
34.37
31.79
30.68
29.67
27.99
27.29
26.62
25.43
24.91
23.96
23.51
22.72
22.02
21.69
27.14
26.51
25.38
24.87
24.40
23.53
23.12
22.75
22.06
21.74
21.14
20.86
20.34
19.86
19.64
Phase
Unbal.
(deg.)
8.09
8.47
9.15
9.52
9.88
10.62
11.00
11.37
12.10
12.46
13.17
13.53
14.30
15.02
15.39
VSWR VSWR VSWR VSWR VSWR
S
1
2
3
4
1.16
1.13
1.08
1.07
1.07
1.09
1.11
1.13
1.18
1.20
1.26
1.28
1.34
1.39
1.42
1.13
1.12
1.11
1.11
1.10
1.10
1.09
1.09
1.09
1.08
1.08
1.07
1.08
1.07
1.07
1.24
1.23
1.21
1.21
1.20
1.18
1.18
1.17
1.15
1.15
1.13
1.13
1.12
1.11
1.10
1.23
1.22
1.19
1.19
1.18
1.16
1.16
1.15
1.14
1.13
1.11
1.11
1.10
1.08
1.08
1.30
1.29
1.27
1.27
1.26
1.24
1.24
1.23
1.22
1.21
1.20
1.20
1.19
1.17
1.17
Suggested Layout,
Tolerance to be within
±.002
Outline Dimensions (
inch
)
mm
A
.163
4.14
H
.009
0.23
B
.210
5.33
J
.025
0.64
C
.077
1.96
K
.030
0.76
D
.250
6.35
M
.050
1.27
E
.220
5.59
N
.030
0.76
F
.050
1.27
G
.017
0.43
BP4U+
TOTAL LOSS
7.0
S-1
TOTAL LOSS (dB)
6.8
6.6
6.4
6.2
6.0
2100
S-3
1. Total Loss = Insertion Loss + 6dB splitter loss.
40
1-2
ISOLATION (dB)
35
30
25
20
15
2100
BP4U+
ISOLATION
2-3
3-4
P
wt
.270 grams
6.86
0.10
Demo Board MCL P/N: TB-231
Suggested PCB Layout (PL-113)
2200
2300
FREQUENCY(MHz)
BP4U+
VSWR
2400
2500
2200
2300
FREQUENCY(MHz)
2400
2500
1.6
1.5
1.4
VSWR
1.3
1.2
1.1
1.0
2100
2200
2300
FREQUENCY(MHz)
2400
2500
#S-VSWR
#1-VSWR
#3-VSWR
electrical schematic
ESD Rating
Human Body Model (HBM): Class 1A (250 v to <500 v) in accordance with ANSI/ESD STM 5.1 - 2001
Machine Model (MM): Class M1 (< 100 v) in accordance with ANSI/ESD STM 5.2 - 1999 (pass 50V)
ISO 9001 ISO 14001 AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
The Design Engineers Search Engine
IF/RF MICROWAVE COMPONENTS
Mini-Circuits
®
For detailed performance specs
& shopping online see web site
®
Provides ACTUAL Data Instantly at
minicircuits.com
Notes: 1.
Performance and quality attributes and conditions not expressly stated in this specification sheet are intended to be excluded and do not form a part of this specification sheet.
2.
Electrical specifications
and performance data contained herein are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
3.
The parts covered by this specification sheet are subject to
Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled to the rights and benefits contained therein. For a full statement of the Standard
Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp.
REV. B
M127604
ED-12348C/9+
BP4U+
HY/TD/CP/AM
100617
