BCA Compact Sector Antennas
Compact sector antennas provide a solution for
customers who need to integrate to an existing radio
or who desire a low cost solution without sacrificing
performance.
Product Features
•
Compact size
•
15 dBi gain
•
Excellent broadband pattern performance
Elevation Pattern
15
12
•
Low VSWR across frequency band
•
Excellent intermodulation (IM) performance
•
Easily integrated to existing radio platforms
•
ETSI Class 1 compliant
Electrical Specifications
Polarization (specify at time of order)
Polarization discrimination, dB
Input power rating, watts
Horizontal or Vertical
>24
50
1.5 (14)
Waveguide cover flange
See Antenna Gain table.
Antenna Gain (dBi)
9
6
3
0
-3
-6
-9
-12
-15
-18
-21
-24
-45 -40
-35
-30
-25
-20 -15
-10
-5
0
5
10
15
20
25
30
35
40
45
VSWR max. (R.L., dB)
Input connector
Elevation Angle (degrees below horizontal)
Azimuth Pattern
-15
-30
-45
-60
0
15
Antenna Gain (dBi)
10
5
0
-5
-10
-15
-20
15
30
45
60
Mechanical Specifications
Survival wind velocity, mph (km/h)
Operating temperature °F (°C)
75
125 (200)
-40 to +140 (-40 to +60)
4.8 x 3.5 x 9.5 (122 x 89 x 241)
Gray per PMS420
1.1 (0.51)
-75
Size, approx. H x W x D, in (mm)
Color
Weight, lb (kg)
-90
90
-105
105
-120
-135
-150
-165
180
165
150
135
120
Horizontal and Vertical Polarization
Antenna Gain
Antenna Type
Number
BCAC090-285(*)
BCAC090-250(*)
Frequency
Band, GHz
26.35 - 31.3
24.25 - 26.5
Sector Size
Degrees (HPBW)
90
90
Gain, dBi, Nominal
15
15
Waveguide Type
WR28
WR42
* Specify H for horizontal polarization or V for vertical polarization
704
Customer Service Center - Call toll-free from: •
U.S.A., Canada and Mexico 1-800-255-1479
