F-211
CRH–08
BE25M–01BJ1–02.5–02–0305
CRH, CRM, BE25M, BE25S SERIES
HIGH PERFORMANCE TEST SYSTEMS
FEATURES
•
Lower production costs
by moving most of the
interface costs to the lab
tool/cable
•
SMA performance for
10% of the cost
•
Compression interface
to the board
•
Bayonet mechanical
latch for easy on/off
•
Probe cable adaptor
connects to existing
instrument cables via
SMA termination
•
Test boards available
for performance
verification. Contact
bullseye@samtec.com
ALLOWS FOR SMALLER BOARD, FEWER LAYERS!
BE25M or
BE25S Series
BAR Series,
22 positions
standard
High Density
Custom
pin counts
available
Field
replaceable
CRH
Series
4:1 density vs. SMA,
1:1 density to SMP at
10% of the cost
Quick
connect/
disconnect
Rugged
latching
Low cost
PCB
interface
CRM
Series
Flourosilicone-based
conductive elastomer
provides excellent
grounding
Eliminates mating
and de-mating problems
(Note: Shown with BE25M cable assembly. Order separately.)
MICROWAVE CABLE PERFORMANCE
9mm
bend radius
9mm
bend radius
Rugged solid
dielectric
construction
CCA-25M
Frequency
1 GHz
2 GHz
4 GHz
0.85
1.21
1.75
2.58
3.22
3.73
4.06
4.18
MWC-2550-01
0.86
1.20
1.70
2.49
3.13
3.60
3.87
4.06
Attenuation (dB/m)
High
performance,
air enhanced
dielectric
25 AWG, silver plated
copper conductor
8 GHz
12 GHz
16 GHz
MWC-2550-01
18 GHz
20 GHz
CCA-25M
(Cable for BE25M & BAR)
(Cable for BE25S)
WWW.SAMTEC.COM
BE25S–01SP1–01.0–02–0152
CRH–04
CRM–08
CRM–02
CRH Mates with:
CRM
(Requires BE25M or BE25S
and customer assembly)
CRM Mates with:
CRH/BE25M, CRH/BE25S
TYPE
NO. OF POSITIONS
OPTION
–02
= 2 Positions
(Only available with CRM)
SPECIFICATIONS
For complete specifications and
recommended PCB layouts
see www.samtec.com?CRH
or www.samtec.com?CRM
Insulator Material:
LCP
Housing Material (CRH):
Brass
Gasket Material (CRH):
MIL-DTL-83528C, Type D
Latch Material (CRM):
BeCu
CRH
= Ganged receptacle
–SD
= Screw Down
–04
= 4 Positions
CRM
= Ganged retention module
(33,01) 1.300
–08
= 8 Positions
(9,06)
.357
APPLICATION
SPECIFIC OPTION
• BAR-J-P-22
Bull’s Eye
®
array
receptacle.
Call Samtec.
BAR
(9,32)
2)
.367
7
(41,66) 1.64
(1,62) .064
(15 42)
(15,42)
.607
(8,90)
.350
CRM
CRH
Mates with:
CRH/CRM,
BAR (BE25M only)
CABLE
TYPE
END
OPTION
Specify
INSTRUMENT
END OPTION
from chart
ALSO
AVAILABLE
• Extraction Tool:
CAT-EX-SCC-01.
• Additional plating
options available.
Call Samtec.
PHASE
MATCHING
NO. OF PHASE
MATCHED
OVERALL
LENGTH
SPECIFICATIONS
For complete specifications
see www.samtec.com?BE25M
or www.samtec.com?BE25S
Cable Type:
Low Loss Microwave Coax
Gauge:
25 AWG Silver plated Copper
Dielectric:
Air enhanced FEP (BE25M),
Solid FEP (BE25S)
Jacket Material:
FEP
Impedance:
50Ω ±1Ω
Propagation Delay:
3.84 nsec/meter
Capacitance:
75.4 pF/meter
–01.0
= 1 Pico-second
(Not available
with -0457 & -0914
cable length)
–02
= 1 Pair
BE25M
= Air Enhanced
Dielectric 25 AWG,
CCA-25M
Microwave Cable
–0152
= (152,4mm)
6.00"
–04
= 2 Pairs
–0305
= (304,8mm)
12.00"
–02.5
= 2.5 Pico-second
(Not available with
-0914 cable length)
BE25S
= Solid FEP
Dielectric 25 AWG,
MWC-2550-01
Microwave Cable
–06
= 3 Pairs
–08
= 4
Pairs
–0457
= (457,2mm)
18.00"
–05.0
= 5.0 Pico-second
co-secon
–0914
= (914,4mm)
36.00"
XXXX = OAL (millimeters)
INSTRUMENT END OPTIONS
PTIONS
–01SP1 = SMA,
01SP1
Stra
Straight Plug
aight
–10.0
= 10.0 Pico-second
00
Note:
Cable lengths longer
hs
than 40.00" (1 meter) are not
er)
no
supported with S.I. test data.
data
Note:
Some lengths, styles
s,
and options are non-standard,
-stand
non-returnable.
–01BJ1 = SMA,
–01BJ1
Bulkhead Jack
Bulkhead
PROBE
END
–01SP1 SHOWN
INSTRUMENT
END
WWW.SAMTEC.COM
