SAW Components
SAW filter
Double conversion
Series/type:
Ordering code:
Date:
Version:
B1619
B39172 B1619 U810
February 11, 2011
2.1
©
EPCOS AG 2011. Reproduction, publication and dissemination of this data sheet, enclosures
hereto and the information contained therein without EPCOS’ prior express consent is prohibited.
SAW Components
SAW filter
Data sheet
Application
s
Low–loss RF filter
s
Balanced to balanced operation
s
Low group delay ripple
B1619
1690.00 MHz
Features
s
s
s
s
s
s
s
Package size 3.0 x 3.0 x 1.1 mm
3
Package code QCC8D
RoHS compatible
Approximate weight 0.037 g
Package for
Surface Mount Technology
(SMT)
Ni, gold-plated terminals
Electrostactic Sensitive Device
(ESD)
0.6
1
3
1.5
1.5
7
bottom view
1.8
5
1.1
side view
3.0
top view
3.0
Pin configuration
s
s
s
s
s
s
1
2
5
6
3,7
4,8
Input
Input
Output
Output
To be grounded
Case - ground
Please read
cautions and warnings and
important notes
at the end of this document.
2
Feb 11, 2011
SAW Components
SAW filter
Data sheet
Characteristics
Operating temperature range:
Terminating source impedance:
Terminating load impedance:
T =
Z
S
=
Z
L
=
0 °C to +70 °C
190
Ω
190
Ω
min.
Center frequency
f
C
—
—
—
—
—
α
50.00
typ.
@ 25 °C
1690.00
4.00
0.50
33.00
40.00
53.00
max.
—
4.50
1.00
—
—
—
B1619
1690.00 MHz
MHz
dB
dB
MHz
MHz
dB
Maximum insertion attenuation
α
max
1681.20 ... 1698.80 MHz
Amplitude ripple in any 6.5 MHz band
1681.20 ... 1698.80 MHz
Pass bandwidth
α
rel
≤
3 dB
α
rel
≤
10 dB
Attenuation
1577.00 ... 1626.00 MHz
Group delay ripple
(p-p)
1681.20 ... 1698.80 MHz
—
15.00
—
ns
Maximum ratings
Operable temperature range
Storage temperature range
DC voltage
Source power
T
T
stg
V
DC
P
S
–45/+85
–45/+85
0
0
°C
°C
V
dBm
source impedance 190
Ω
Please read
cautions and warnings and
important notes
at the end of this document.
3
Feb 11, 2011
SAW Components
SAW filter
Data sheet
B1619
1690.00 MHz
References
Type
Ordering code
Marking and package
Packaging
Date codes
S-parameters
Soldering profile
RoHS compatible
B1619
B39172-B1619-U810
C61157-A7-A72
F61074-V8168-Z000
L_1126
B1619_NB_UN.s4p
B1619_WB_UN.s4p
S_6001
defined as compatible with the following documents:
"DIRECTIVE 2002/95/EC OF THE EUROPEAN PARLIAMENT
AND OF THE COUNCIL of 27 January 2003 on the restriction
of the use of certain hazardous substances in electrical and
electronic equipment. 2005/618/EC from April 18th, 2005,
amending Directive 2002/95/EC of the European Parliament
and of the Council for the purposes of establishing the maxi-
mum concentration values for certain hazardous substances in
electrical and electronic equipment."
For further information please contact your local EPCOS sales office or visit our webpage at
www.epcos.com .
Published by EPCOS AG
Surface Acoustic Wave Components Division
P.O. Box 80 17 09, 81617 Munich, GERMANY
©
EPCOS AG 2011. This brochure replaces the previous edition.
For questions on technology, prices and delivery please contact the Sales Offices of EPCOS AG or
the international Representatives.
Due to technical requirements components may contain dangerous substances. For information on
the type in question please also contact one of our Sales Offices.
Please read
cautions and warnings and
important notes
at the end of this document.
5
Feb 11, 2011
