EMC filters
3-line filters
Sine-wave output filters
300/520 V AC; 400/690 V AC, 4 A ... 320 A, 40
°C
Series/Type:
Date:
B84143V*R227
December 2017
© EPCOS AG 2017. Reproduction, publication and dissemination of this publication, enclosures hereto and the
information contained therein without EPCOS' prior express consent is prohibited.
EPCOS AG is a TDK Group Company.
Line reactors, output chokes and output filters
Sine-wave output filters for 3-phase systems
B84143V*R227
Sine-wave output filters for 3-phase systems
Rated voltage V
R
: 300/520 V AC and 400/690 V AC
Rated current I
R
: 4 A to 320 A
Construction
3-line filters
Features
Reduction of motor noise and eddy current losses
Generation of sinusoidal phase-to-phase voltage with low
ripple
dv/dt reduction
Easy to install
Compact design
Degree of protection: IP20 up to 95 A
1)
Optimized for long motor cables and operation under full
load
2)
Natural cooling
Wiring between inverter and filter must be shorter than
10 meters! Up to 180 A: tube clip for convenient shield
bonding
UL approved insulation system T-EIS-CF1
Typical applications
Frequency converters for motor drives, e.g.
elevators
pumps
traction and conveyer systems
HVAC systems (heating, ventilation and air conditioning)
Terminals
Up to 180 A: Finger-safe terminal blocks
250 A and 320 A: Copper busbars
Marking
Marking on component:
Manufacturer’s logo, ordering code, rated voltage, rated
current, rated motor frequency, rated switching frequency,
rated temperature, climatic category, date code, approvals
Minimum data on packaging:
Manufacturer's logo, ordering code, quantity, date code
1) According to IEC 60529
2) The maximum permissible motor cable length depends on the application and must be checked.
Please read
Cautions and warnings
and
Important notes
at the end of this document.
Page 2 of 16
Line reactors, output chokes and output filters
Sine-wave output filters for 3-phase systems
B84143V*R227
Typical circuit diagrams
Filters 4 A ... 33 A
Filters 50 A ... 320 A
Please read
Cautions and warnings
and
Important notes
at the end of this document.
Page 3 of 16
Line reactors, output chokes and output filters
Sine-wave output filters for 3-phase systems
B84143V*R227
Technical data and measuring conditions
Rated voltage V
R
Rated current I
R
Test voltage V
test
Filters 4 A ... 132 A:
300/520 V AC (50/60 Hz)
Filters 180 A ... 320 A:
400/690 V AC (50/60 Hz)
Referred to 40
°C
rated temperature
1500 V DC, 2 s (line/line)
2500 V DC, 2 s (lines/case)
0 ... 100 Hz
See table "Characteristics and ordering codes"
1.5 I
R
for 1 min per hour
At I
R
and 50 Hz
Converter output frequency f
M
Pulse frequency (switching)
Overload capability (thermal)
Voltage drop
ΔV
(Input to
output)
Max. dv/dt on filter input
5 kV/μs (higher values can be approved individually)
Climatic category (IEC 60068-1) Filters 4 A ... 33 A:
25/90/21
Filters 50 A ... 95 A:
25/55/21
Filters 132 A ...320 A:
25/70/21
Insolation class
Approvals
F (155
°C)
Insulation system class F (155
°C);
T-EIS-CF1 UL 1446
Characteristics and ordering codes
I
R
*
A
Terminal
f
res
cross section
mm
2
Hz
L
R
mH
ΔV
f
P1)
f
P
R
typ
min. max.
% kHz kHz mΩ
3
3
3
3
3
3
3
3
3
3
3
3
3)
2.4
2.4
16
16
16
10
10
10
10
8
8
8
8
6
6
6
390
290
70
37
28
20
12
9
7
6.3
3.7
P
L2)
W
40
45
55
60
100
150
190
250
320
330
380
Approx. Ordering code
weight
kg
3.3
3.5
5.3
8.5
16
20
25
26
38
52
67
74
91
145
B84143V0004R227
B84143V0006R227
B84143V0011R227
B84143V0016R227
B84143V0025R227
B84143V0033R227
B84143V0050R227
B84143V0066R227
B84143V0075R227
B84143V0095R227
B84143V0132R227
B84143V0180R227
B84143V0250R227
B84143V0320R227
V
R
= 520 V AC
4
4
4
6
4
11
6
16
25 10
33 10
50 35
66 35
75 35
95 35
132 95
V
R
= 690 V AC
180 95
250 40
×
3
320 40
×
3
1000 12.0
5
1170 8.5
5
1300 4.5
5
1230 3.0
7
1100 2.5
7
1190 1.8
8
1330 1.2
8
1210 0.95 8
1050 0.86 9
1120 0.75 10
910 0.52 10
870
890
780
0.40 10
0.32 11
0.25 11
3.8 480
1.4 560
1.2 750
1) For lower frequencies please contact EPCOS.
2) Typical value. Varies with type and length of motor cable, pulse frequency and modulation.
3) 4 kHz in case the filter is mounted vertically on the wall.
* Higher current values upon request
Please read
Cautions and warnings
and
Important notes
at the end of this document.
Page 4 of 16
Line reactors, output chokes and output filters
Sine-wave output filters for 3-phase systems
B84143V*R227
Dimensional drawings
B84143V0004R227 ... B84143V0011R227 (4 A ... 11 A)
Ordering code
B84143V0004R227
B84143V0006R227
B84143V0011R227
B
85
85
100
B
1
60
60
75
General tolerances according to ISO 2768 cL
Dimensions in mm
Please read
Cautions and warnings
and
Important notes
at the end of this document.
Page 5 of 16
