Filters for power lines
16 to 100 A, 100 dB from 150 kHz
B84299*B001
B84299*E001
2- and 4-line-filters
Standard filters for measuring cabins
Single-stage
Stopband attenuation 150 kHz to 40 GHz
Features
General-purpose use through design with separate lines without intercoupling
Use of single chokes. Thus the insertion loss values are not reduced under all operating cur-
rent conditions and not when operated with artificial mains networks (AMN) or other equipment
with high leakage currents.
Insertion loss to CISPR 17
Design
The electrical components are incorporated in an RF-tight case of stainless steel. The cables
enter through glands. The RF-tight termination of the openings is produced by specially shaped
lids.
The conductors and equipment grounding conductor are connected by threaded bolts. The sur-
face around the fixing holes is left as bare metal (unpainted) to ensure good RF contact with met-
al surfaces (chassis, ground).
Protective measures (grounding)
The high capacitances between the lines and ground require special protective measures. If there
are no product-specific requirements, protection with a secondary ground wire (cross section min.
10 mm
2
) in accordance with EN 50178 is necessary. For this purpose the filter case have con-
necting bolts at each end.
Resistors are incorporated in the filter to discharge capacitors after turn-off.
Scope of supply
Filters are supplied complete with all parts required for RF-tight installation (fixing screws,
flanges, RF gaskets, cable glands) and installation instructions.
Installation
No welding is needed on the shielding wall, so any subsequent installation is quite simple.
Accessories and special versions
RF-tight flexible connector fittings are available for installation spaced away from the shielding
wall. Filters with an EMP protection add-on for surge currents up to 100 kA per line are available
on request. To match requirements, filters can be supplied with different kinds of EMC or shield-
ing cable glands.
Tests
All filters are 100% tested and the results are archived under a filter's serial number. If required, a
test report can be generated for the serial number.
2
Filters for power lines
16 to 100 A, 100 dB from 150 kHz
B84299*B001
B84299*E001
General technical data (continued)
Power dissipation
P
D
See characteristics
At rated current I
R
At 400/230 V and 50 Hz (typical
value)
% To EN 50160
25/+40
25/085/56
C
D
°C
25
°C/+85 °C/56
days damp
heat test
Cable glands at both ends or
flexible connector fitting
Direct connection to shielding
wall
Capacitive reactive current/line I
reactive
See characteristics
Max. permissible harmonic
distortion (THD)
Permissible ambient
temperature
Climatic category
(EN 60068-1)
Mechanical version
T
A
8
Characteristics and ordering codes
I
R
A
Mechanical R
max
version
mΩ
< 25
< 25
< 20
< 20
< 3.0
< 3.0
< 1.5
< 1.5
< 50
< 50
< 20
< 20
< 3.0
< 3.0
< 1.5
< 1.5
P
D
W
< 15
< 15
< 40
< 40
< 25
< 25
< 30
< 30
< 30
< 30
< 40
< 40
< 35
< 35
< 45
< 45
I
reactive
Dimensional Page Approx. Ordering code
drawing
weight
A
kg
0.7
0.7
1.0
1.0
1.0
1.0
1.0
1.0
0.7
0.7
1.0
1.0
1.0
1.0
1.0
1.0
1
2
3
4
5
6
7
8
9
10
11
12
5
6
7
8
6
7
8
9
10
11
12
13
14
15
16
17
10
11
12
13
8
8
15
15
18
18
18
18
16
16
20
20
20
20
20
20
B84299C2160B001
B84299D2160B001
B84299C2320B001
B84299D2320B001
B84299C1630B001
B84299D1630B001
B84299C1101B001
B84299D1101B001
B84299C2160E001
B84299D2160E001
B84299C2320E001
B84299D2320E001
B84299C1630E001
B84299D1630E001
B84299C1101E001
B84299D1101E001
2-line filters
16 C
16 D
32 C
32 D
63 C
63 D
100 C
100 D
4-line filters
16 C
16 D
32 C
32 D
63 C
63 D
100 C
100 D
5
