B0520LWF, B0530WF, B0540WF
Low V
F
SMD Schottky Barrier Diode
Small Signal Diode
SOD-123F
B
Features
Surface device type mounting
Moisture sensitivity level 1
Pb free version and RoHS compliant
Green compound (Halogen free) with suffix "G" on
packing code and prefix "G" on date code
C
A
D
E
F
Dimensions
A
B
C
D
E
F
Unit (mm)
Min
1.50
3.30
0.50
2.50
0.80
0.05
Max
Unit (inch)
Min
Max
Mechanical Data
Case : Flat lead SOD-123F small outline plastic package
Terminal: Matte tin plated, lead free., solderable
per MIL-STD-202, Method 208 guaranteed
High temperature soldering guaranteed: 260°C/10s
Polarity : Indicated by cathode band
Weight : 8.85±0.5 mg
1.70 0.059 0.067
3.90 0.130 0.154
0.70 0.020 0.028
2.70 0.098 0.106
1.15 0.031 0.045
0.20 0.002 0.008
Ordering Information
Part No.
B0530WF
B0540WF
B0530WF
B0540WF
Package
SOD-123F
SOD-123F
SOD-123F
SOD-123F
Packing Code
RH
RH
RH
RHG
RHG
RHG
Packing
3K / 7" Reel
3K / 7" Reel
3K / 7" Reel
3K / 7" Reel
3K / 7" Reel
3K / 7" Reel
Marking
SD
SE
SQ
SD
SE
SQ
B0520LWF SOD-123F
Pin Configuration
Suggested PAD Layout
0.91
0.036
1.22
0.048
B0520LWF SOD-123F
2.36
0.093
4.19
0.165
Maximum Ratings and Electrical Characteristics
Rating at 25°C ambient temperature unless otherwise specified.
Maximum Ratings
Type Number
Repetitive Peak Reverse Voltage
Reverse Voltage
Average Forward Current @ TL=100℃ (Lead Temperature)
Non-Repetitive Peak Forward Surge Current (Note 1)
Thermal Resistance (Junction to Lead)
Thermal Resistance (Junction to Ambient)
Operating Junction Temperature
Storage Temperature Range
Notes: 1. Device mounted on FR-4 PCB 0.013 mm.
2. 1 inch pad size ( 1 x 0.5 inch for each lead ) on FR4 board.
3. The suggested land pattern dimensions have been provided for reference only, as actual pad layouts
may vary despending on application.
Symbol B0520LWF
V
RRM
V
R
I
O
I
FSM
Rθ
JL
Rθ
JA
T
J
T
STG
150
340
125
-65 to + 125
20
20
B0530WF
30
30
500
5.5
150
206
118
206
150
-65 to + 150
B0540WF
40
40
Units
V
mA
A
°C/W
°C/W
°C
°C
Version :A10
B0520LWF, B0530WF, B0540WF
Low VF SMD Schottky Barrier Diode
Small Signal Diode
Maximum Ratings Electrical Characteristics
Rating at 25°C ambient temperature unless otherwise specified.
Type Number
Forward Voltage
Symbol
IF= 0.1 A
IF= 0.5 A
IF= 1.0 A
IF= 0.1 A, Ta = 100
o
C
IF= 0.5 A, Ta = 100
o
C
IF= 1.0 A, Ta = 100
o
C
V
R
= 10V
V
R
= 20V
V
R
= 10V, Ta = 100
o
C
V
R
= 20V, Ta = 100
o
C
V
R
= 15V
V
R
= 30V
V
R
= 40V
V
R
= 40V, Ta = 100
o
C
B0520LWF
0.300
0.385
-
0.220
0.330
-
75
250
5
8
-
-
-
-
B0530WF
0.375
0.5
-
-
-
-
-
-
-
-
20
130
-
-
B0540WF
-
0.51
0.62
-
0.46
0.61
Units
V
F
V
Reverse Leakage Current
-
10
-
5
-
-
20
13
μA
mA
I
R
μA
mA
Carrier & Reel specification
TSC label
Top Cover Tape
Carieer Tape
Any Additional Label (If Required)
Item
Carrier depth
Sprocket hole
Reel outside diameter
Reel inner diameter
Feed hole width
Sprocke hole position
Punch hole position
Sprocke hole pitch
Embossment center
Overall tape thickness
Tape width
Reel width
Symbol
K
D
A
D1
D2
E
F
P0
P1
T
W
W1
Dimension(mm)
2.40 Max.
1.50 +0.10
178 ± 1
50 Min.
13.0 ± 0.5
1.75 ±0.10
3.50 ±0.05
4.00 ±0.10
2.00 ±0.10
0.6 Max.
8.30 Max.
14.4 Max.
W1
User Direction of Feed
A
D2
D1
Note 1: A0, B0, and K0 are determined by component size. The clearance between the components and the cavity must be
within 0.05 mm min. to 0.5 mm max. The component cannot rote more than 10o within the determined cavity.
Note 2: If B1 exceeds 4.2 mm(0.165'') for 8 mm embossed tape, the tape may not feed through all tape feeders.
Version : A10
B0520LWF, B0530WF, B0540WF
Low VF SMD Schottky Barrier Diode
Small Signal Diode
Rating and Characteristic Curves
FIG. 1 Typical Forward Characteristics
1
0.75
B0530WF
FIG. 2 Forward Current Derating Curve
Instantaneous Forward Current (A)
Average Forward Current (A)
B0520LWF
B0540WF
0.5
B0540WF
0.1
0.25
B0530WF
B0520LWF
0.01
0
0.1
0.2
0.3
0.4
0.5
0.6
0
0
25
50
75
100
125
150
Instantanceous Forward Voltage (V)
Terminal Temperature (°C)
FIG. 3 Typical Junction Capacitance
1000
Junction Capacitance (pF)
100
10
1
0
5
10
15
20
25
Reverse Voltage (V)
Version : A10
