BZX84B68/GS18 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> BZX84B68/GS18

BZX84B68/GS18: DescriptionZener Diode, 68V V(Z), 2%, 0.3W,; CategoryDiscrete semiconductor diode; File Size401KB，10 Pages; ManufacturerVishay; Websitehttp://www.vishay.com; Environmental Compliance

Download Datasheet Parametric View All

BZX84B68/GS18 Overview

Zener Diode, 68V V(Z), 2%, 0.3W,

BZX84B68/GS18 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Reach Compliance Code	compliant
ECCN code	EAR99
Configuration	SINGLE
Diode type	ZENER DIODE
Maximum dynamic impedance	240 Ω
JESD-609 code	e3
Number of components	1
Maximum operating temperature	150 °C
Maximum power dissipation	0.3 W
Nominal reference voltage	68 V
surface mount	YES
Terminal surface	Matte Tin (Sn)
Maximum voltage tolerance	2%
Working test current	2 mA
Base Number Matches	1

Preview

Download Datasheet

View All

VISHAY

BZX84-Series

Vishay Semiconductors

Zener Diodes

Features

• These diodes are also available in other case

styles and other configurations including: the

SOD-123 case with type designation BZT52

series, the dual zener diode common anode con-

figuration in the SOT-23 case with type designa-

tion AZ23

series and the dual zener diode common cathode

configuration in the SOT-23 case with type desig-

nation DZ23 series.

18078

• The Zener voltages are graded according to the

international E 24 standard. Standard Zener volt-

age tolerance is ± 5 %. Replace "C" with "B" for

± 2 % tolerance.

• Silicon Planar Power Zener Diodes

Mechanical Data

Case:

SOT-23 Plastic Package

Weight:

approx. 8.8 mg

Packaging Codes/Options:

GS18 / 10 k per 13" reel (8 mm tape), 10 k/box

GS08 / 3 k per 7" reel (8 mm tape), 15 k/box

Absolute Maximum Ratings

amb

= 25 °C, unless otherwise specified

Parameter

Power dissipation

Test condition

Symbol

tot

Value

300

Unit

Device on fiberglass substrate, see layout.

Thermal Characteristics

amb

= 25 °C, unless otherwise specified

Parameter

Thermal resistance junction to ambient air

Junction temperature

Storage temperature range

Test condition

Symbol

thJA

Value

420

150

- 65 to + 150

Unit

°C/W

°C

Device on fiberglass substrate, see layout.

Document Number 85763

Rev. 1.5, 19-Apr-04

www.vishay.com
