REVISION AG
C2
BSW-1XX-XX-X-X-X
((No OF POS x .10[2.5])
+.03[.8])
2 MAX SWAY
(EITHER DIRECTION)
.060 1.52
(SEE NOTE 4)
No OF POSITIONS
-02 THRU -36 (PER ROW)
LEAD STYLE
-04: C-8-5-X
(STANDARD I/W FORCES)
-24: C-17-5-X
(LOW I/W FORCES)
OPTION
-S: STANDOFFS
(USE BSW-36-X-S,
SEE TABLE 1)
ROW SPECIFICATION
SEE TABLE 1
"D"±.010
AG
.350 8.89 REF
PLATING SPECIFICATION
(VALUES GIVEN ARE IN MICRO INCHES)
-G: GOLD, 20Au / 50 Ni MIN CONTACT, 3 AU / 50 Ni MIN
ON TAIL
-T: MATTE TIN CONTACT AND TAIL (STYLE -04 ONLY)
-S: SELECTIVE, 30 Au / 50 Ni MIN ON
CONTACT, MATTE TIN TAIL
-H: HEAVY GOLD, 30 Au / 50 Ni MIN ON
CONTACT, 3 Au / 50 MIN Ni ON TAIL (STYLE -04 ONLY)
-L: SELECTIVE GOLD, 10Au / 50 Ni MIN ON
CONTACT, MATTE TIN TAIL
-D/-S/-M
BSW-36-X-X
C C
L L
C C
L L
2 MAX SWAY
(EITHER DIRECTION)
.100 2.54
REF
C
L
C
L
.170 4.32
REF
.100 2.54 REF
CC
L L
.005 A
.100 2.54 REF
.100 2.54 REF
R.042 1.07
A
"B"
(SEE TABLE 1)
C1
C-08-5-X or
C-17-5-X
.30 7.6
.200 5.08
REF
-S
-M
.250 6.35
REF
-D
.400 10.16
REF
CONTACT
SCALE 1.5:1
CRITICAL 1 DIMMENSION MUST BE VERIFIED AT
BEGINNING, MIDDLE, AND END OF EACH LOT
NOTES:
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. MINIMUM PUSHOUT FORCE: 3lbs.
3. MAXIMUN ALLOWABLE BOW: .003[.08] INCH/INCH
AFTER ASSEMBLY
4. "END WALLS" AFTER CUTTING SHOULD BE .023[.58]
5. MAXIMUM CUT FLASH: .010[.25].
6. THE IDENTIFICATION SIDE IS TO BE DOWN OR AGAINST
THE FORM TOOLING.
FINAL ASSEMBLY
POSITION NUMBER LAYOUT
72
02
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
DECIMALS
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
.XX: .01 [.3]
2
.XXX: .005 [.13]
.XXXX: .0020 [.051]
ANGLES
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
01
-S/-S-S
50
01
-M
50
71
-D/-D-S
01
MATERIAL:
INSULATOR: PET, UL 94 VO, COLOR: BLACK
CONTACT: PHOS BRONZE
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
.100 BOTTOM MOUNT SOCKET ASSEMBLY
BSW-1XX-XX-X-X-X
03/31/1998
SHEET
1
OF
2
F:\DWG\MISC\MKTG\BSW-1XX-XX-X-X-X-MKT.SLDDRW
BY:
PURVIS
BSW-1XX-XX-X-X-X
REVISION AG
C2
((No OF POS x .10[2.5])
+.03[.8])
2 MAX SWAY
(EITHER DIRECTION)
.060 1.52
(SEE NOTE 4)
SEE NOTE 6
STANDOFFS
(-S OPTION)
"C"
.365 9.27 REF
-D-S/-S-S
BSW-36-X-X
C C
L L
.100 2.54
REF
.100 2.54 REF
CC
L L
C C
L L
.100 2.54 REF
.100 2.54 REF
-S-S
.200 5.08
REF
-D-S
.400 10.16
REF
FINAL ASSEMBLY
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
SHEET SCALE: 2:1
.100 BOTTOM MOUNT SOCKET ASSEMBLY
BSW-1XX-XX-X-X-X
03/31/1998
SHEET
2
OF
2
F:\DWG\MISC\MKTG\BSW-1XX-XX-X-X-X-MKT.SLDDRW
BY:
PURVIS
